RENON Flex LV-EU Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual of Flex LV-EU
User Manual of Flex LV-EU
Email: support@renonpower.com
Official website: www.renonpower.com
Address: 5900 Balcones Drive STE 100, Austin, TX 78731, United States
Series Inverter
Series Inverter
I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Flex LV-EU Series and is the answer not in the manual?

Questions and answers

Related Manuals for RENON Flex LV-EU Series

Summary of Contents for RENON Flex LV-EU Series

  • Page 1 User Manual of Flex LV-EU User Manual of Flex LV-EU Series Inverter Series Inverter Email: support@renonpower.com Official website: www.renonpower.com Address: 5900 Balcones Drive STE 100, Austin, TX 78731, United States...
  • Page 2 DECLARATION The right to modify the frame dimensions, functionality, technical data, parameters, standards without prior notice. The contents of this manual have been checked for accordance with its described hardware and software. However, the contents of this manual may be subject to appropriate modification as a result of product upgrade, specification change and update of the manual, we cannot guarantee full accordance all the time.

  • Page 3: Other Rights

    OTHER RIGHTS Using data contained in firmware or software, in part or in full, for commercial purposes by any means is prohibited. Reverse engineering, cracking or any other operation that destroys the original programming design of software is prohibited.
  • Page 4 PREFACE Thank you for choosing Renon Flex LV-EU Series inverter ( hereinafter referred to as "inverter" ) . This user manual presents a detailed description of with respect to product features, structural characteristics, functions, installation, parameter settings, troubleshooting, commissioning and daily maintenance, etc. Be sure to carefully read through the safety precautions before use and keep it properly at a place for easy access.
  • Page 5 This manual is valid for the following model of Energy Storage Inverters: • R-IFL03-EU01 • R-IFL03a-EU01 • R-IFL04-EU01 • R-IFL04a-EU01 • R-IFL05-EU01 • R-IFL06-EU01 • R-IFL08-EU01 It will be referred to as "inverter" hereinafter unless otherwise specified. The inverter must only be installed by professional technicians. The professional technician is required to meet requirements as follows: •...

  • Page 6: Technical Support

    TECHNICAL SUPPORT Before installation, wiring, operation, and repair to the inverter, please read carefully and strictly comply with all its Safety Precautions in this manual. Please ensure all the warning marks on the inverter are clear and distinct. Replace or add the obscure or missed warning marks. The information from following sources is all effective.

  • Page 7: Table Of Contents

    Content 1 Safety Precautions 1.1 Target Group 1.2 Symbols Used 1.3 Safety Precautions 1.4 Battery Maintenance 1.5 Low Voltage Earthing system 1.6 Battery Maintenance 1.7 Low Voltage Earthing System 2 Introduction 2.1 Model Description 2.2 Basic Features 2.3 Work Modes 2.4 Dimensions 2.5 Terminals 2.6 Parameters...
  • Page 8 5.1 LCD Operation 5.2 Italy self-testing (Auto test Fast) 6 Fault Diagnosis and Solutions Figure Figure 2-1 Symbols on the product Figure 2-2 System diagram:R-IFL03-EU01~R-IFL08-EU01 Figure 2-3 Wiring diagram Figure 2-4 Dimensions Figure 2-5 Terminals Figure 3-1 Space requirement Figure 4-1 Battery connection Figure 4-2 BMS PIN definition...
  • Page 9 Table Table 1-1 Symbols on the Product Table 2-1 Terminals Table 2-2 Parameters Table 2-4 Parts list Table 4-1 Max. DC Voltage Limitation Table 4-2 Recommended cables - GRID Table 4-3 Recommended breakers Table 4-4 Recommended cables - LOAD Table 4-5 Recommended non-polar DC breaker-breaker Table 4-6 Recommended cables - Battery...
  • Page 10 History Version Release Date Description Reviser V1.00 2024.1.23 First edition Vivid V1.01 2024.3.11 Second edition Vivid...

  • Page 11: Safety Precautions

    1 Safety Precautions 1.1 Target Group This manual is for qualified electricians. The tasks described in this manual only can be performed by qualified electricians. 1.2 Symbols Used The following types of safety instructions and general information appear in this document as described below: DANGER indicates high-risk potential hazards that, if not avoided, may lead to death or serious injury.

  • Page 12: Safety Precautions

    1.3 Satety Precautions • Danger to life due to high voltages in the inverter! DANGER • All work must be carried out by qualified electrician. • The appliance is not to be used by children or persons with reduced physical sensory or mental capabilities, or lack of experience and •...
  • Page 13 • Ensure input DC voltage ≤Max. DC voltage. Over voltage may cause damage. WARNING • Permanent damage to inverter or other losses, which will not be included in warranty! • Authorized service personnel must disconnect both AC and DC WARNING power from inverter before attempting any maintenance or cleaning or working on any circuits connected to inverter.
  • Page 14 • Make sure that existing wiring is in good condition and that wire is not undersized. Do not disassemble any parts of inverter which are not mentioned in installation guide. It contains no user-serviceable parts. See Warranty for instructions on obtaining service. Attempting to service the inverter yourself may result in a risk of electric shock or fire and will void your warranty.
  • Page 15 • Over-voltage protection with surge arresters should be provided WARNING when installing PV power generation system. • The grid connected inverter does not have SPDs installed on both PV input side and MAINS side. • Lightning will cause a damage either from a direct strike or from surges due to a nearby strike.
  • Page 16 • an additional SPD type 3 required for surge protection for electrical devices. • To protect the AC system, surge suppression devices (SPD type2) should be fitted at the main incoming point of AC supply (at the consumer’s cutout), located between the inverter and the meter/ distribution system.
  • Page 17 1.3.3 PE Connection and Leakage Current • The end-use application shall monitor the protective conductor by residual current operated protective device (RCD) with rated fault current Ifn≤240mA which automatically disconnects the device in case of a fault. The device is intended to connect to a PV generator with a capacitance limit of about 700nf.
  • Page 18 1.3.5 Battery Safety Instructions Energy storage inverter should be worked with low voltage battery, for the specific parameters such as battery type, nominal voltage and nominal capacity etc., please refer to section 4. As accumulator batteries may contain potential electric shock and short- circuit current danger, to avoid accidents that might be thus resulted, the following warnings should be observed during battery replacement: 1: Do not wear watches, rings or similar metallic items.

  • Page 19: Explanation Of Symbol

    1.4 Explanation of Symbol This section gives an explanation of all the symbols shown on the inverter and on the type label. Table 1-1 Symbols on the Product Symbol Explanation This symbol indicates that you should wait at least 5mins after disconnecting the inverter from the utility grid and from the PV panel before touching any inner live parts.

  • Page 20: Battery Maintenance

    1.5 Maintenance Related Information The maintenance instructions should include the following content: • Intervals and instructions for any Preventive maintenance required to maintain safety.(For example, replacing the air filter or regularly retightening the terminals). • Instructions for accessing the operator's access area (if present), including warning not to enter other areas of the equipment.

  • Page 21: Low Voltage Earthing System

    • The following precautions should be observed when using batteries: 01. Remove watches, rings, or other metal items. 02. Using tools with insulated handle. 03. Wear rubber gloves and boots. 04. Do not place tools or metal parts on the battery. 05.
  • Page 22 high current, which can cause the fuse to quickly fuse or the protective device to act to cut off the power supply. In the TN system, there are three types of systems: TN-C, TN-S, and TN-C-S. • TN-C system The N line and PE line are integrated throughout the entire system. Grounding point (power supply side) Exposed conductive parts...
  • Page 23 Grounding point (power supply side) Exposed conductive parts 1.7.2 TT system A TT system is one in which the neutral point of the power supply is directly grounded, and the exposed conductive parts of electrical equipment are also directly grounded. The grounding of the power supply's neutral point is commonly referred to as working grounding, while the grounding of the exposed conductive parts of the equipment is known as protective grounding.
  • Page 24 equipment are directly grounded. Although an IT system can include neutral wires, it's worth noting that the International Electrotechnical Commission (IEC) does not recommend their use. If a neutral line is introduced and a ground fault occurs at any point along the neutral line in the IT system, the system will cease to function as an IT system.

  • Page 25: Introduction

    The model description is as follows (take R-IFL×××-EU01 as an example): Figure 2-1 Symbols on the product R-IFL×××-EU01 R: Renon Brand I: Inverter F: Renon Flex series inverter L: support low voltage batteries.(Voltage range: 40-58V) ×××: single-phase output EU: European Union 01: Single phase 2.2 Basic Features The energy storage inverter is a high-quality inverter that can convert solar energy to AC energy and store them in the battery.
  • Page 26 Figure 2-2 System diagram: R-IFL03-EU01~R-IFL08-EU01 INVERTER GRID LOAD Figure 2-3 System diagram: R-IFL03-EU01-AC~R-IFL08-EU01-AC INVERTER GRID LOAD Introduction...
  • Page 27 Figure 2-3 Wiring diagram All switches and RCD devices shown in the figure are for reference only, and specific installations should comply with local regulations. • Please control the home loads and ensure that they are within the "BACK-UP output rating" under BACK-UP mode. Otherwise, the inverter will shut down with an "overload fault"...

  • Page 28: Work Modes

    2.3 Work Modes The inverter offers multiple working modes according to different requirements. Work mode: self-use When PV, Grid, Battery is available: Solar energy provides power to the loads as GRID first priority. If solar energy is sufficient to power all connected loads, solar energy excess power will provides to charge battery, and then reduntant power will feed to grid.
  • Page 29 Solar energy provides power to the loads as GRID first priority, if solar energy is not sufficient to power all connected loads, Grid energy will supply power to the loads at the same time. III. When PV, Battery is available (Grid is disconnected): Solar energy provides power to the loads as first priority .if solar energy is sufficient to power all connected loads, solar energy will...
  • Page 30 there's still some extra energy.then the excess power will feed the power to grid. On charge time,solar energy will charge battery GRID as first priority.then the excess solar energy will supply power to loads.If solar energy is not sufficient to charge battery and supply loads,grid will supply all the connected loads with solar energy together.
  • Page 31 On discharge time,if load power is more than GRID battery power.battery and grid will supply power to the loads at the same time. Work mode: BAT priority When PV, Grid, Battery is available: Solar energy will charge battery as first priority, GRID if solar energy is excess.
  • Page 32 In addition to the above three basic modes, there is also an “Advanced Mode”. Please refer to Chapter 5.1.3 for details. Introduction...

  • Page 33: Dimensions

    2.4 Dimensions R-IFL03-EU01~ R-IFL06-EU01: Dimensions Mounting hole dia. 454.5 Unit, mm Introduction...
  • Page 34 R-IFL08-EU01: Dimensions Mounting hole dia. 484.5 Unit, mm Introduction...

  • Page 35: Terminals

    2.5 Terminals Figure 2-5 Terminals BAT Port PV String Input COM1 PV1+ PV2+ PV3+ COM2 PV1- PV2- PV3- BAT+ BAT- INSIDE LOAD GRID CAN1 LEAD CAN2 CAN_BMS /485_BMS LOAD / GRID Ports Signal Line/Communication Interfaces Introduction...
  • Page 36 Table 2-1 Terminals PV1+ PV string 1 positive input PV1- PV string 1 negative input PV2+ PV string 2 positive input PV2- PV string 2 negative input PV3+ PV string 3 positive input PV3- PV string 3 negative input COM1 GPRS port or WIFI port (Choose one) COM2 GPRS port or WIFI port (Choose one, not available...

  • Page 37: Parameters

    2.6 Parameters Table 2-2 Parameters PV input R-IFL03- R-IFL03a- R-IFL04- R-IFL04a- Model EU01 EU01 EU01 EU01 MAX. DC Input Power(kW) No. of MPPT Tracker/No. of PV strings per MPPT tracker MPPT Range / Nominal (V) 80-500/360 Full Power MPPT Voltage 250-425 Range (V) MAX.
  • Page 38 Model R-IFL03- R-IFL03a- R-IFL04- R-IFL04a- EU01 EU01 EU01 EU01 MAX. Battery Output Power/ Duration (kW/min) Battery Voltage Range(V) 40-58 Battery Type Lithium or Lead Acid Battery Charging Strategy for Li-Ion Self-adaption to BMS Battery Model R-IFL05-EU01 R-IFL06-EU01 R-IFL08-EU01 Nominal voltage (Vdc) MAX.Charging/Discharging 100/100 120/120...
  • Page 39 Model R-IFL03- R-IFL03a- R-IFL04- R-IFL04a- EU01 EU01 EU01 EU01 Maximum output fault 42.9 57.3 current(A@3um) Model R-IFL05-EU01 R-IFL06-EU01 R-IFL08-EU01 Nominal output power Output to Grid (kVA/kW) MAX. Apparent Power Output to Grid(kVA) Output Voltage Range(Vac) Output Frequency(Hz) 50/60 Max. AC Current Output to 21.7 28.7 38.3...
  • Page 40 Model R-IFL05-EU01 R-IFL06-EU01 R-IFL08-EU01 Nominal Output Voltage(Vac) 230 Nominal Output 50/60 Frequency(Hz) Output THDU < 2% Efficiency Model R-IFL03- R-IFL03a- R-IFL04- R-IFL04a- EU01 EU01 EU01 EU01 Battery Charge / Discharge DC Max. Efficiency 98.0% MPPT Efficiency 99.9% Model R-IFL05-EU01 R-IFL06-EU01 R-IFL08-EU01 Battery Charge / Discharge DC Max.
  • Page 41 Model R-IFL05-EU01 R-IFL06-EU01 R-IFL08-EU01 Island Protection √ √ √ Battery Reverse Polarity √ √ √ Insulation Resistor Detection √ √ √ Residual Current Monitoring √ √ √ Unit Output Over Current √ √ √ Protection Back-up Output Short √ √ √...
  • Page 42 Model R-IFL03- R-IFL03a- R-IFL04- R-IFL04a- EU01 EU01 EU01 EU01 IEC/EN 62109-1/-2, IEC/EN61000-6-1/-6-3, VDE-AR-N 4105:2018/DIN VDE V 0124-100:2020, NRS 097-2-1:2017, EN50549-1, Certificates EN50549-1/Rfg:2016/NC Rfg:2018/PTPiREE:2021, EN50549-1+EN50438, EN50549-1(France), CEI 0-21:2022, C10/11 Pollution degree Topology Non-isolated Model R-IFL05-EU01 R-IFL05-EU01 R-IFL08-EU01 Grid and off grid switching time (ms) Operating Temperature -25 ~ +60...
  • Page 43 Model R-IFL05-EU01 R-IFL05-EU01 R-IFL08-EU01 IEC/EN 62109-1/-2, IEC/EN61000-6-1/-6-3, VDE-AR-N 4105:2018/DIN VDE V 0124-100:2020, NRS 097-2-1:2017, EN50549-1, Certificates EN50549-1/Rfg:2016/NC Rfg:2018/PTPiREE:2021, EN50549-1+EN50438, EN50549-1(France), CEI 0-21:2022, C10/11 Pollution degree Topology Non-isolated Introduction...

  • Page 44: Installation

    3 Installation 3.1 Check for Physical Damage Make sure that the inverter is intact during shipment. If there is any visible damage, such as cracks, please contact your dealer immediately. 3.2 Packing List Open the package and take out the product, please check the accessories first.

  • Page 45: Mounting

    3.3 Mounting 3.3.1 Installation Precaution The inverter is designed for outdoor installation (IP 65). Please ensure that the installation location meets the following conditions: • Not in direct sunlight. • Not in areas where highly flammable materials are stored. • Not in potential explosive areas.

  • Page 46: Installation Procedure

    No direct sunlight No rain exposure No snow accumulation Direct sunlight Snow accumulation Rain exposure 3.3.2 Space Requirement Figure 3-1 Space requirement FRONT BOTTOM Directions BOTTOM LEFT RIGHT FRONT Min. size (mm) 1000 3.3.3 Installation Procedure Tools: Terminal blocks, RJ45 crimping pliers, screwdrivers, hand wrenches and drills, etc.
  • Page 47 Step 1: Mounting the hanging rack on the wall Place the hanging rack on the wall, mark the location of the 3 holes and then remove it. Drill holes with an drill, making sure they are deep enough (about 50~60 mm) to support the inverter. Then install the expansion pipes into the hole with a proper hammer, and fix the hanging rack with self-tapping screws.
  • Page 48 Step 3: Tighten the fixing screws on the right side of the inverter. Table 4-1 Max. DC Voltage Limitation Step 4: Use a screwdriver to remove the waterproof box under the lower part of the machine. Step 5: After installation, to ensure that the machine does not fall off, please double check if the machine is fixed to the rack.The installation steps for the non-touchscreen model are the same as those for the touchscreen model.

  • Page 49: Electrical Connection

    4 Electrical Connection Loads 4.1 PE Cable Installation An external ground connection is provided at the right side of inverter. Prepare OT terminals: M4. Use proper tooling to crimp the lug to the terminal.Cable Size: 8AWG. Connect the OT terminal with ground cable to the right side of inverter. The torque is 2Nm.

  • Page 50: Pv Input Cable Installation

    4.2 PV Input Cable Installation Energy storage inverters can be connected in series with 2/3-strings PV modules for 3kW, 3.6kW, 4kW, 4.6kW, 5kW, 6kW, 8kW. Select PV modules with excellent function and reliable quality. The open- circuit voltage of module arrays connected in series should be less than Max.
  • Page 51 Connection steps: Step 1 : Inspect PV modules Measure the module array voltage with a voltmeter. Check the PV+ and PV- from the PV string combiner box correctly. Please make sure the impedance between the positive pole and negative pole of PV to ground should be MΩ level. Step 2: Separate DC Connector Plug Pin contact...
  • Page 52 Step 4 : Insert the pin contact through the nut and into the male or female plug, when a "click" is felt or heard, the pin contact assembly is properly seated. Then tighten the nut. Insert Step5 : Plug the PV connector into the corresponding interface on the inverter.

  • Page 53: Ac Cable Installation (On Grid)

    • Caution! • If it is above 0.5A, please wait for the solar irradiance reduces until the current decreases to below 0.5A. • Only after the current is below 0.5A, you are allowed to turn off the DC switches and disconnect the PV strings. •...
  • Page 54 Step3 : Disassemble the waterproof connector and waterproof cover, and thread the cable through the waterproof connector. Step4: Wiring Connect the wire to the cold crimp terminal. Remove 18mm of insulation from the end of the wire. Insert the stripped end into the cable lug and clamp it with crimping pliers.

  • Page 55: Ac Cable Installation (Back-Up)

    4.4 BACK-UP : Load Connection The inverter has both on-grid and off-grid functions. When the grid is on, the inverter delivers output power through the AC port. When the grid is off, it delivers output power through the backup port. Auto &...
  • Page 56 GRID LOAD GRID LOAD GRID LOAD GRID LOAD If there are any discrepancies between the local policy's wiring mode and the operation guide given above, particularly regarding the wiring of the neutral line, grounding, and RCD, please contact us before conducting any operations.
  • Page 57 Table 4-3 Recommended breakers Model R-IFL03-EU01 R-IFL03a-EU01 R-IFL04-EU01 Micro breaker(A) 19.5 23.5 Model R-IFL04a-EU01 R-IFL05-EU01 R-IFL06-EU01 Micro breaker(A) 30 32.6 Model R-IFL08-EU01 Micro breaker(A) 43.5 The absence of an AC breaker on the back-up side may result in inverter damage in case of an electrical short circuit. Step1: Select the appropriate cable and wire connector Table 4-4 Recommended cables - LOAD...
  • Page 58 Step2 : Disassemble the waterproof connector and waterproof cover, and thread the cable through the waterproof connector. Step3: Wiring Connect the wire to the cold crimp terminal. Remove 18mm of insulation from the end of the wire. Insert the stripped end into the cable lug and clamp it with crimping pliers.

  • Page 59: Battery Connection

    Requirements for BACK-UP loads Make sure the rated load power of the BACK-UP is within its rated output WARNING range, otherwise the inverter will shut down with an "overload" warning. When an "overload" occurs, adjust the load power to ensure it is within the BACK-UP output power range before turning on the inverter.

  • Page 60: Battery Connection Diagram

    Battery connection diagram Figure 4-1 Battery connection BATTERY BMS PIN Defination The communication interface between the inverter and the battery is RJ45, and its protocol is RS485 or CAN. Figure 4-2 BMS PIN definition × RS485 × × × × BMS_485A BMS_485B ×...
  • Page 61 The battery communication can only work when the battery BMS is compatible with the inverter. Battery connection steps: Step1: Select the appropriate cable and O-terminal with an M4 bore. Table 4-6 Recommended cables - Battery Model R-IFL03-EU01 R-IFL03a-EU01 R-IFL04-EU01 Cable(AWG) ≥5 ≥5 ≥4...
  • Page 62 18mm Insert & Crimp BMS connection steps: Step 1: Disassembly of waterproof connector and waterproof cover. Step 2: Prepare a communication cable (without sheath) and pass the cable through the waterproof connector. Step 3: Insert the RJ45 connector into the BMS port of the inverter. Step 4: Assemble waterproof connectors and waterproof cover.

  • Page 63: Ct Installation Instructions

    4.6 CT Installation instructions CT stands for "current transformer" and is used to detect grid current. • If CT is not installed or installed incorrectly, the "Anti-reflux", "Self- use", "Peak-shift" functions will not be realized. • The direction of the arrow on the CT should point from this inverter to the GRID! •...

  • Page 64: Wifi Connection (Optional)

    CT connection steps: Step 1: Disassembly of waterproof connector and waterproof cover. Step 2: Prepare a communication cable (without sheath) and pass the cable through the waterproof connector. Step 3: Insert the RJ45 connector into the CT port of the inverter. Step 4: Assemble waterproof connectors and waterproof cover.

  • Page 65: Gprs Connection (Optional)

    WIFI connection steps: Step 1: Assemble WIFI adaptor to COM1 or COM2(WIFI) port at the bottom of the inverter. Step 2: Establish the connection between the inverter and the router. Step 3: Create a user account online. (Please check the “ WIFI adaptor user manual”...

  • Page 66: Bluetooth Connection (Optional)

    GPRS connection steps: Please refer to the “ Smart Plug user manual” for detailed connection steps. RS485_B 4.9 Bluetooth Connection (optional) If you need to set a mode or check the device status, you can connect locally via Bluetooth. The inverter provides a WiFi (including Bluetooth) port that can collect data from the inverter and transmit it to a mobile terminal via Bluetooth.

  • Page 67: Inverter System Guide

    9:41 AM 9:41 AM 9:41 AM Smart SetApp English Scan Local mode Change API Monitoring & Configuration Solar Grid Wi-Fi Configuration Logger Diagnosis Battery Load Other Inversion Local Mode Refactory DEBUG HomeLoad Parallel3Phase Grid Settings Battery Set Enter SN Turn on Logger SN: 1724389835 V1.2.0 Connection status:...
  • Page 68 For parallel communication, CAT 6 cables are needed. The units should be connected hand by hand. When using common batteries, BMS cable needs to be connected to the master unit. THE inverter shares the BMS information by inter -unit parallel communication cable. For details about how to configure the parallel system, see 5.1.3 Setting Options (1).
  • Page 69 4.10.2 Parallel precautions for use 1.Make sure all the units in parallel are with the same software version. Information Module : SN : ARM Ver : 0.0000 00.00 DSP Ver : 0.0000 00.00 HMI Version : 1.0004 2.Connect the loads of the two inverters together first. It should be noted that the grid power line and the load line of the two inverters should be roughly the same length.If user wants to add grid /load ac breaker, please make sure the lines are paralleled/jointed before connected to breaker.
  • Page 70 4.10.3 Inverter Configuration Start inverter after checking all the following: • Ensure all the devices are accessible for operation, maintenance and service. • Check and confirm that the inverter is firmly installed. • Space for ventilation is sufficient for one inverter or multiple inverters. •...
  • Page 71 Shut down inverter: • Disconnect the external AC circuit breaker and secure it against reconnection. • Rotate the DC switch to the "OFF" position for disconnecting all of the PV string inputs. • Wait about 10 minutes until the capacitors inside the inverter completely discharge.

  • Page 72: Operation

    5 Operation 5.1 LCD Operation 5.1.1 Home page Figure 5-1 Homepage 14 : 38 : 19 0.0 kW 0.0 kW 0.0 % 0.0 kW 0.0 kW Energy storage inverter Click to enter the working status interface of the energy storage inverter, refer to section 5.1.2 (1) for more details.
  • Page 73 5.1.2 (3) for more details. Battery Display the real-time battery power and the percentage of remaining battery capacity. Click to enter the working status interface of battery, Refer to section 5.1.2 (4) for more details. Load Display the real-time load power. Click to enter the working status interface of load.
  • Page 74 System Settings: Date & Time Year Hour Month Minute Second (1) Energy storage inverter Figure 5-2 Data panel of energy storage inverter Inverter VpBUS System State STANDBY VnBUS INV State STANDBY INV-T(℃) DCDC State STANDBY Inside-T(℃) Leak Current DCDC-T(℃) Voltage Current Power Users can click on the icon above to switch device status data...
  • Page 75 NOTE: The real-time bus voltage of this model is the sum of positive and negative buses. INT-T( ℃ ): Temperature of the inverter. Inside-T ( ℃ ): Internal temperature of the device. DCDC-T ( ℃ ): Internal temperature of DCDC. Display status information, including System status, Inverter status, DCDC status and Parallel State.
  • Page 76 Display the cumulative charging capacity of the PV, including daily and total accumulated energy. Figure 5-3 Data panel of PV Solar Voltage Current Power Energy Total (3) Grid Figure 5-4 Data panel of grid Grid Frequency 0.00 Voltage Current Power Sell Total Operation...
  • Page 77 Displays the operating parameters of the grid, including frequency, real-time voltage, real-time current and real-time power. Accumulated energy from the grid to the device (buy) and from the device to the grid (sell), including daily energy and total accumulated energy. (4) Battery Figure 5-5 Data panel of battery...
  • Page 78 (5) Load Figure 5-6 Data panel of load Load Voltage Current Power Energy Total Home load Power Click to go to the next page; Click to go back to the previous page. When set Home load EN to "ENABLE", if you have a load connected to the mains port, you can see its Home load power.
  • Page 79 Displays the operating parameters of the load, including real-time voltage, current and power. The accumulated power used by the load, including daily and total accumulated energy. Displays the real-time power of the homeload. (6) Generator (Not applicable to models listed in this manual) Figure 5-7 Data panel of generator (Not applicable to models listed in this manual) Generator...
  • Page 80 Power on,The energy storage inverter works. Power of The energy storage inverter stops working. 5.1.3 Setting (1) How to enter setting page? Click to access the settings page. The default password to enter the settings page is 11111. Click OK to proceed to the settings page.
  • Page 81 Step 3 11111 Step 4 Password 11111 At this point, as shown below, the settings page is activated. System Setting Work Mode Self Consumption Peak Shift Batt Priority Backup Enable Homeload EN Insulation Detection Advanced Settings Operation...

  • Page 82: Setting Option

    • Click on the top icon to switch between different sets of setting parameters. • After the modification is completed, you need to click in the bottom right corner to confirm ( ! important ; This description will not be repeated in subsequent sections.). System setting Generator setting Machine information...
  • Page 83 Backup Enable: When the Grid and PV are powered off, Enable the battery to supply power to the load, default option is enable. Homeload EN: Enable home load statistics. Insulation Detection: Insulation detect (The default option is enabled). When the insulation detection function is enabled in the grid connected state, the insulation detection is performed once a day when the photovoltaic energy comes in, and the inverter switches to the By-pass band load.
  • Page 84 when you check it. TOU Enable: Users need to check TOU Enable to enter the work mode of Time-of-use Enable. Advanced Mode: There are three options here: Disable Mode,Sell First Mode and BatCharge First Mode. The advanced mode takes effect only in automatic self Consumption mode. Disable: When the user selects "Disable", the two working modes, are invalid.Only if the other two options are selected, the two working modes (Sell Fiest,BatCharge First) take effect and work.
  • Page 85 • Time-of-use Enable : There are 6 slots which can be programmed. If grid charge is enabled, the grid is used to power the load and charge the battery to target SOC at specific bat power attribute value. If selling electricity to the grid enable, the battery will discharge to target SOC at specific battery power attribute value.
  • Page 86 Users can set PV types, including Independent,Parallel and Constant Voltage. Independent: The factory setting defaults to Independent, when PV is input in parallel but set to standalone mode, PV generation will be unbalanced. Parallel: Commonly used for testing in parallel mode, two or three PVs are connected in parallel.
  • Page 87 • System setting (page 4) Peak Shift Time Charge Time Discharge Time 00 : 00 00 : 02 00 : 03 23 : 00 Time1 Time2 00 : 00 00 : 00 00 : 00 00 : 00 Time3 00 : 00 00 : 00 00 : 00 00 : 00...
  • Page 88 Time 1 charge 00:00 05:00 23:59 Time 2 discharge charge 00:00 07:00 10:00 11:00 13:59 23:59 Time 3 discharge charge 00:00 14:00 19:00 21:00 23:59 discharge charge charge discharge charge 00:00 05:00 07:00 10:00 11:00 13:5914:00 19:00 21:00 23:59 c) If you want to set a continuous charging time from the first night to the next morning.
  • Page 89 • Parallel setting Parallel Settings Parallel enable 3 Phase Parallel Master Phase A Slave Phase B Common Grid CT Phase C Common Battery Charge Curr Discharge Curr Parallel Num CT Ratio Parallel Addr Parallel enable: Start or disable the parallel function. Master/Slave: This interface is used for parallel, and the inverter is selected as the master or slave.
  • Page 90 CT Ratio: Set the detection ratio of CT.Set the CT ratio to 1000:1 by default. Charge Curr: Set the charging current of parallel machine. Discharge Cur: Set the discharge current of parallel machine. • Battery setting (page 1) Battery Type and Communications Bat Type Bat Com Type Lead-Acid / Cust...
  • Page 91 forcibly sucking relay by BMS, and the inverter will charge. The default option is disabled. (Partial battery support) If you want to use this feature, please consult the battery brand supported by the dealer. Use it only when the battery is too low. After the battery wakes up successfully, please turn off the function, otherwise it will affect the normal operation of the machine.
  • Page 92 used to set the lead acid battery discharging voltage. (The input value ranges from 40 to 51) Discharge cut-off voltage, as recommended by the battery manufacturer). Battery Cap AH: Battery capacity (This interface is used to set the lead acid Battery capacity. It is related to the input power. (The input value ranges from 50 to 1000) The battery capacity setting will affect the maximum charging current, for example, set 100Ah, the maximum charging current is 100A*0.2=20A).
  • Page 93 Off-grid DOD/Off-grid Eod Hyst: When a low-voltage alarm is generated, the alarm is cleared if the battery charge is higher than the specified amount. • Grid setting (page 1) Grid Settings AC Wiring TN-S CHINT TN-C ACRET Sell Enable Grid Power Limit Zero Export Power Limit Grid Protect Parameter Users can choose to use CT or electricity meter to detect the grid...
  • Page 94 Sell Enable: Whether the inverter is allowed to sell electricity to the grid. The option is checked, which means that the inverter can generate electricity to the grid. Grid Protect parameter: Users can click to Grid Protect Parameter > enter the advanced settings interface. •...
  • Page 95 time, and grid reconnection time.When grid standards are set, these values are automatically updated according to local safety regulations. Grid Parameters Fac HF1 Trip 0.00 Fac HF1 CIrTime 0.00 Fac HF2 Trip 0.00 Fac HF2 CIrTime 0.00 Fac HF3 Trip 0.00 Fac HF3 CIrTime 0.00...
  • Page 96 It is used to select the grid standard. You can set and switch the grid standard according to your needs. AU: Australia US: America AU-W: Western Australia ZA: South Africa NZ: New Zealand Custom: User defined UK: United Kingdom POL: Poland PK: Pakistan EN50549 KR: Korea...
  • Page 97 • REACT Power Parameter: REACT Power Parameter, including: Power Factor, React Power, QU Wave, QP Wave.(For specific country if required by the local grid.) • Power Factor:The input value should range between L0.80 and L0.99 or C0.8 and C1.00. • React Power: Reactive power control The input value should range between -60% and +60%, which varies with the standard.
  • Page 98 • Grid setting (page 4) Grid Function Active Island Leak Current LVRT Enable HVRT Enable • Anti-Island: Anti-Islanding(The default option is enable). When the grid goes down, inverter will detect the loss of power and disconnect from the grid within milliseconds. It prevents your solar panels from feeding electricity into a downed power line.
  • Page 99 • Generator setting GEN Set Gen Enable Gen Charge Enable Gen Manual Mode Gen Manual Start/Stop Gen Auto Start/Stop Gen Connect To Grid Start SOC Stop SOC Charge Current Gen Power 8000 Cooling Time Max Operating 10.0 Diesel generator enable settings: Gen Enable: Enable control of the Generator function.
  • Page 100 Start SOC: When the SOC of battery is lower than the setpoint, the Generator dry contact is enabled and Generator Manual operation is disabled, the connected Generator will be started. Stop SOC: When the SOC of battery is higher than the set point, the Generator dry contact is enabled and Generator Manual operation is disabled, the connected Generator will be stopped (START SOC ＜...
  • Page 101 Displays the inverter model Displays the inverter SN Displays software version Displays HMI version • Machine Information (page 2) This interface is used to reset the inverter. Information Factory Reset • Machine Information (page 3) Screen Setting Backlight Enable Backlight Brightness Backlight Time 180 s Operation...
  • Page 102 LCD backlight is enabled. It is enabled by default. Backlight brightness adjustment. The default value is 0, and the value ranges from 0 to 100%. Backlight time setting. The default value is 180s.and the value ranges from 5 to 250s. •...
  • Page 103 5.1.4 LED indicators Only for models without screen. INV Status Always on Normal Green Blinks INV Standby Always on Fault Blinks Alarm Blinks Blinks Alarm DCDC Status Always on Normal Green Blinks DCDC Standby Always on Fault Blinks Blinks Alarm Fault Status Error/Alarm Codes...
  • Page 104 Refer Chapter 6 for more informations about the error/alarm codes. Battery disconnection or (and) low battery voltage will cause the battery light to turn red. Operation...
  • Page 105 5.2 Italy self-testing (Auto test Fast) As shown in the picture below, the power grid standard is ITA. Ensure that the power grid is connected and the inverter is error-free, otherwise do not test. Grid Standard AU-W THAIL Custom EN50549 VDE4105 Click the setting icon in the upper left corner of the LCD screen to enter the password input interface, enter the password "33333", and...
  • Page 106 Enter the Italy self-test interface and click Start test, as shown in the picture below : Auto Test This function is only used for self inspection testing under the safety regulations of the Italian power grid. Start Test Wait until the test is complete, as shown in the picture below : AUTO TEST Test Step Set Value...

  • Page 107: Fault Diagnosis And Solutions

    6 Fault Diagnosis and Solutions When an alarm occurs, the alarm code and description are shown on the home page of the display. Click on the alarm to go to the page for alarms, which will first display the Active Alarms page: Active Alarms A03-Bat Disconnect A28-BMS Comm Fail...
  • Page 108 Historic Alarms 10-23 09:31 A03-Bat Disconnect 10-23 08:08 A28-BMS Comm Fail 10-22 12:31 A03-Bat Disconnect 10-22 10:31 A28-BMS Comm Fail 10-21 09:00 A03-Bat Disconnect 10-21 08:31 A28-BMS Comm Fail The following table lists some basic problems that may occur in practice and the corresponding basic solutions.
  • Page 109 Codes: Solutions: • Check whether the load is in Content: Over Load compliance with the maximum Explanation: power of the inverter. The load power is greater than • Disconnect all power and turn off other power(PV,BAT). all inverters; disconnect the load, power up and restart the inverter, and if the fault has been cleared, check the load again for a short...
  • Page 110 Codes: Solutions: Content: Bat Low Volt Low battery setting Explanation: capacity(SOC<100%-DOD) The battery voltage is low. Codes: Solutions: Content: Bat Over Volt • Checking system settings, re- Explanation: power and restart. The battery voltage is over than • If the error/warning remains, the Inverter maximum voltage.
  • Page 111 Codes: Solutions: Content: Gfci over • Check PV string for direct or Explanation: indirect grounding phenomenon. Inverter GFCI exceeds standard. • Check peripherals of inverter for current leakage. • If the error/warning remains, please contact customer service. Codes: Solutions: Content: Bus under volt •...
  • Page 112 Codes: Solutions: Content: Charge over current Explanation: Restart the inverter and wait until it The battery charging current functions normally. exceeds the maximum current of the inverter. Codes: A19 / A20 Solutions: Content: INV under volt / over volt • Check if the INV voltage is Explanation: abnormal.
  • Page 113 Codes: Solutions: Content: BMS sys erro Explanation: Please contact customer service. BMS internal communication failure or BMS system error. Codes: Solutions: Content: Bat over temp Explanation: Disconnect the battery and Battery temperature is higher than reconnect it after an hour. the allowed value.
  • Page 114 Codes: Solutions: Content: BMS Comm fail • Check the cable, RJ45 header, Explanation: line sequence. Communication between lithium • Checking the Battery switch. battery and inverter is abnormal. Codes: Solutions: Content: Bat fail • Check whether the battery is Explanation: abnormal.
  • Page 115 Codes: A35 / A36 Solutions: Content: Bus short / Inv short • Restart the inverter and wait until Explanation: it functions normally. The inverter may be damaged. • If the error/warning remains, please contact customer service. Codes: Solutions: Content: Fan fault •...
  • Page 116 Codes: Solutions: Content: Grid Relay Fault • Restart the inverter and wait until Explanation: it functions normally. The inverter may be damaged. • If the error/warning remains, please contact customer service. Codes: Solutions: Content: EPS Relay fault • Restart the inverter and wait until Explanation: it functions normally.
  • Page 117 Codes: Solutions: Content: Reserved Explanation:Reserved Reserved Codes: Solutions: Content: System fault • Restart the inverter and wait until Explanation: it functions normally. The inverter may be damaged. • If the error/warning remains, please contact customer service. If an error occurs that is not listed in the table, please contact customer service.
