IP-DECT Installation Guide
NDA-31472
Issue 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UNIVERGE SV8300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NEC UNIVERGE SV8300

Summary of Contents for NEC UNIVERGE SV8300

  • Page 1 ® IP-DECT Installation Guide NDA-31472 Issue 1.0...
  • Page 3 NEC Corporation of America reserves the right to change the specifications, functions, or features at any time without notice. NEC Corporation of America has prepared this document for use by its employees and customers. The information contained herein is the property of NEC Corporation of America and shall not be reproduced without prior written approval of NEC Corporation of America.
  • Page 5 Preface This manual is valid for Business Mobility IP DECT Software Release 6.0. IMPORTANT: This manual gives information for setting up a Business Mobility IP DECT system. However, the Business Mobility IP DECT is normally part of an IP network. The success of the installation depends on the structure and components in the IP network.
  • Page 6 At www.nec-unified.com/weee you can find information about separate disposal and environmentally sound recycling. For countries outside the European Union Disposal of electrical and electronic products in countries outside the European Union should be done in line with the local regulations.

  • Page 7: Table Of Contents

    Call Quality Control.................. 1-9 Subscription and De-Subscription ............1-10 Secondary Access Right Identifier (SARI)..........1-12 Chapter 2 DECT In An IP Network Section 1 System Architecture ..................2-1 Section 2 Handset Subscription/Registration ............... 2-4 ___________________________________________________________________________________ NEC IP DECT SV8300 Installation Guide...
  • Page 8 Issue 1.0 UNIVERGE SV8300 ___________________________________________________________________________________ Section 3 Automatic Distribution When A DAP Is Down ..........2-7 Section 4 Handset Registration in the SV8300 .............. 2-7 Section 5 Handover Mechanism ..................2-7 Section 6 Is DAP Manager Required? ................2-11 Section 7 Radio Synchronization..................
  • Page 9 Network Configuration ................4-10 Settings in the DAP Configurator............4-12 Chapter 5 DAP Installation Items Section 1 General ......................5-1 Section 2 DAP Power Provision..................5-1 ___________________________________________________________________________________ ___________________________________________________________________________________ NEC IP DECT SV8300 Installation Guide NEC IP DECT SV8300 Installation Guide - iii...
  • Page 10 Issue 1.0 UNIVERGE SV8300 ___________________________________________________________________________________ Section 3 DHCP and TFTP Requirements ..............5-2 DHCP Server ...................5-2 TFTP Server ....................5-3 Operation without DHCP or TFTP Server..........5-3 Using other DHCP and/or TFTP Servers..........5-4 Chapter 6 Preparing Your DAP Manager PC Section 1 Hardware Requirements .................
  • Page 11 Network Settings, tab “Boot options” ............. 9-17 Section 5 System Configuration .................. 9-18 Simple Configuration ................9-19 Multiple Subnets ..................9-19 Routed Headquarter ................9-22 Section 6 SIP Settings ....................9-23 ___________________________________________________________________________________ ___________________________________________________________________________________ NEC IP DECT SV8300 Installation Guide NEC IP DECT SV8300 Installation Guide...
  • Page 12 Section 8 PBX Settings ....................9-28 PBX Settings, tab “Handset Sharing” ............9-28 PBX Settings, tab “Three Party Conference Settings”......9-29 PBX Settings, tab “NEC PBX Settings” ..........9-30 Section 9 Performance / E-mail Settings..............9-32 Performance / E-mail Settings, tab “PCR Settings” ......9-32 Performance / E-mail Settings, tab “Alarm Settings”...
  • Page 13 Portable Sharing and the DAP Manager ..........13-11 Section 5 “Recall” Button Simulation in Shuttle Condition ........13-11 Section 6 LED Indication on Handset................ 13-12 ___________________________________________________________________________________ ___________________________________________________________________________________ NEC IP DECT SV8300 Installation Guide NEC IP DECT SV8300 Installation Guide - vii...
  • Page 14 Issue 1.0 UNIVERGE SV8300 ___________________________________________________________________________________ General ....................13-12 LED Indication for Incoming Call ............13-12 LED Indication for Voice Message Waiting..........13-12 Chapter 14 IP DECT Mobility In SV8300 Section 1 General ......................14-1 Section 2 Setting up the Configuration in SV8300 ............. 14-2 Section 3 Setting Up User Mobility in IP DECT ............
  • Page 15 Broadcast Messaging ..................D-3 General....................D-3 Additional Broadcast Message Types ............ D-4 How about Normal, Urgent, Emergency Messages ....... D-5 Appendix E Overview Of Default IP Ports ___________________________________________________________________________________ ___________________________________________________________________________________ NEC IP DECT SV8300 Installation Guide NEC IP DECT SV8300 Installation Guide - ix...
  • Page 16 Issue 1.0 UNIVERGE SV8300 ___________________________________________________________________________________ THIS PAGE INTENTIONALLY LEFT BLANK ___________________________________________________________________________________ Table of Contents...

  • Page 17: List Of Figures And Tables

    Example of a Simple IP DECT Network Configuration ........4-2 Figure 4-2 IP DECT System Simple Configuration Screen ..........4-3 Figure 4-3 Example of an IP DECT Configuration With a Branch Office ......4-4 Figure 4-4 Branch Office Settings ..................4-5 ___________________________________________________________________________________ NEC IP DECT SV8300 Installation Guide...
  • Page 18 Issue 1.0 UNIVERGE SV8100/SV8300 ___________________________________________________________________________________ Figure 4-5 Example of an IP DECT Routed Head Quarter Configuration ......4-6 Figure 4-6 Routed Headquarter System Configuration Screen ..........4-7 Figure 4-7 Example of an IP DECT Routed Head Quarter Configuration with Branch Office .....................4-8 Figure 4-8 Example of Setup for a Routed Head Quarter with Branch Office Configuration .....................4-9...
  • Page 19 Figure 9-24 PCR Settings ....................9-32 Figure 9-25 Alarm Settings ....................9-34 Figure 9-26 Alarm Notification .................... 9-35 Figure 9-27 Archive Settings ....................9-36 ___________________________________________________________________________________ ___________________________________________________________________________________ NEC IP DECT SV8300 Installation Guide NEC IP DECT SV8300 Installation Guide - xiii xiii...
  • Page 20 Issue 1.0 UNIVERGE SV8100/SV8300 ___________________________________________________________________________________ Figure 9-28 E-Mail Settings ....................9-37 Figure 9-29 Miscellaneous Settings ..................9-39 Figure 9-30 Customer Information ..................9-40 Figure 9-31 Import License File ..................9-42 Figure 9-32 License Information ..................9-43 Figure 9-33 License Information Window ................9-44 Table 9-1 License Information ..................9-45 Table 10-1 Overview of TFTP Servers ................
  • Page 21 Figure D-1 Message Path in IP DECT - Messaging Server Configuration ......D-2 Table E-1 Default Ports Used in Business Mobility IP DECT ..........E-1 ___________________________________________________________________________________ ___________________________________________________________________________________ NEC IP DECT SV8300 Installation Guide NEC IP DECT SV8300 Installation Guide - xv...
  • Page 22 Issue 1.0 UNIVERGE SV8100/SV8300 ___________________________________________________________________________________ THIS PAGE INTENTIONALLY LEFT BLANK ___________________________________________________________________________________ List of Figures and Tables...

  • Page 23: Dect System Characteristics

    Figure 1-2 DECT System Parts in an IP Solution as Add-On to a PBX shows a general IP DECT Solution. It shows the basic system setup for the Business Mobility IP DECT system. NEC IP DECT SV8300 Installation Guide 1 - 1...
  • Page 24 Issue 1.0 SV8300 Figure 1-1 DECT System Parts (General) Figure 1-2 DECT System Parts in an IP Solution as Add-On to a PBX The radio area covered by a single RFP (DAP) is called a cell. The RFPs (DAPs) are located so that the cells overlap slightly and the PP can remain in contact with the DECT system when moving from one cell to another.

  • Page 25: Rfp-Pp Communication

    The modulated date rate is 1152 kb/s. DECT uses in the OSI physical layer the following multiplexing techniques: FDMA (Frequency Division Multiple Access);  TDMA (Time Division Multiple Access);  TDD (Time Division Duplex).  NEC IP DECT SV8300 Installation Guide 1 - 3...
  • Page 26 Issue 1.0 SV8300 The RFP-PP communication radio signal carries time division multiplexed frames; each frame is 10ms long. Each frame contains 12 time slots which carry data from RFP to the PPs, and 12 time slots which carry data from PPs to the RFP.

  • Page 27: Beacon Signal

    The PP uses the signal to synchronize its timing with the central system, and then it monitors the information transmitted via that RFP for calls to itself. NEC IP DECT SV8300 Installation Guide 1 - 5...

  • Page 28: Call Handling Procedures Between Pp And Rfp

    Issue 1.0 SV8300 If the PP detects too many errors in the received signal (due to interference or weak signal) the PP tries to find another better signal and locks onto another RFP. In this way, the PP user can move around the area from cell to cell and remain in contact with the DECT system via a radio link with a very good quality.

  • Page 29: Cluster Arrangement

    RFP. The PP selects a channel which is not being used. It uses this channel to set up the call. NEC IP DECT SV8300 Installation Guide 1 - 7...

  • Page 30: Handover

    Issue 1.0 SV8300 The PP alerts the PP user, who can then answer the call. In case the PP user wants to make a call (own initiative), he/she presses the off-hook button. It starts setting up a connection with the RFP.

  • Page 31: Call Quality Control

    PP. It can temporarily block the data stream from PP to the opposite party. (Note that muting is done on both ends of the connection independently.) NEC IP DECT SV8300 Installation Guide 1 - 9...

  • Page 32: Subscription And De-Subscription

    Issue 1.0 SV8300 Subscription and De-Subscription Before a PP can be used, it must be subscribed (registered) to the system. That means that a relation must be defined between the DECT System and the PP. There are three identifiers used to define the relation between the system and the PP: IPUI (International Portable User Identity) ...
  • Page 33 Management has been put on the blacklist in the DAP Controller/Manager. When the PP is or becomes within reach of the radio signals, the DAP Controller/Manager and the PP exchange information which results in the de- NEC IP DECT SV8300 Installation Guide 1 - 11...

  • Page 34: Secondary Access Right Identifier (Sari)

    Issue 1.0 SV8300 subscription of that PP. It is no longer recognized by the DECT system and it is free to be subscribed again. This is the normal way to de-subscribe a portable set. If a portable has been disabled, but the DECT System cannot reach the PP and complete the de-subscription, the "terminated"...
  • Page 35 SV8300 Issue 1.0 Figure 1-7 Using SARI in Three DECT Systems NEC IP DECT SV8300 Installation Guide 1 - 13...
  • Page 36 Issue 1.0 SV8300 THIS PAGE INTENTIONALLY LEFT BLANK 1 - 14 DECT System Characteristics...

  • Page 37: Dect In An Ip Network

    AP400. The AP400 is the latest model. All DAP Types supports up to 12 simultaneous calls. For the AP400, functionality licenses are applicable. The power provision is done via the Ethernet interface (PoE). NEC IP DECT SV8300 Installation Guide 2 - 1...
  • Page 38 Issue 1.0 SV8300 Besides radio traffic, the DAPs take care of subscription control and call control data handling to/from the SV8300. The AP300 and AP400 are equipped with internal antennas. DAP Controller/Manager  The DAP Controller/Manager performs the following main functions: WEB Server for management (based on IIS = Internet Information Services) ...
  • Page 39 However, before you can establish a call, the handset must have been subscribed and registered in the SV8300. In the following sections, the processes in the system are explained in more detail. NEC IP DECT SV8300 Installation Guide 2 - 3...

  • Page 40: Handset Subscription/Registration

    Issue 1.0 SV8300 ANDSET UBSCRIPTION EGISTRATION ECTION Before you can use a handset, the handset must be subscribed to the DECT system. Besides that the handset must be registered in the SV8300. Subscription requires manual intervention, registration is done automatically. Figure 2-2 Phases in the Subscription Process in the SV8300 Environment shows the phases in the...
  • Page 41 The DAP Manager contains subscription data of all handsets in the system. If the DAP Manager is disconnected, the system remains operational. The subscription records in the DAPs are stored in Flash Memory. NEC IP DECT SV8300 Installation Guide 2 - 5...
  • Page 42 Issue 1.0 SV8300 Figure 2-3 Subscription Locations (in SV8300 Environment) 2 - 6 DECT In An IP Network...

  • Page 43: Handover Mechanism

    DAP in a multi DAP (radio) environment. So in other words, when a handset is in an existing voice call, it can move between the DAPs without losing the connection or hearing a click. NEC IP DECT SV8300 Installation Guide 2 - 7...
  • Page 44 Issue 1.0 SV8300 Figure 2-4 Call Connection Before Handover (in SV8300 Environment) the speech path is a peer-to-peer VoIP connection between the IP extension and a DAP. Figure 2-4 Call Connection Before Handover (in SV8300 Environment) However, handset 200 moves from DAP 1 to DAP 2. Refer to Figure 2-5 Handover Action Started (in SV8300 Environment) on page 2-9.
  • Page 45 Figure 2-6 Handover Taken Place, New Connection Active (in SV8300 Environment) on page 2-10. Note that the original connection is not removed from the DAP 1, but this DAP "relays" the connection to the second DAP. DAP 1 cannot NEC IP DECT SV8300 Installation Guide 2 - 9...
  • Page 46 Issue 1.0 SV8300 release the IP voice connection, because the IP voice connection between the IP extension (350) and DAP 1 is established, based on a combination of sockets. This combination is fixed during the connection. Figure 2-6 Handover Taken Place, New Connection Active (in SV8300 Environment) When a second handover takes place from DAP 2 to DAP 3, DAP 1 will setup a second ...

  • Page 47: Is Dap Manager Required

    The subscription data is stored in the DAPs. The DAP Manager is temporary needed in the following cases: During installation  During installation the DAP Manager is needed to enter licence information, extension numbers, to subscribe handsets etc. NEC IP DECT SV8300 Installation Guide 2 - 11...

  • Page 48: Radio Synchronization

    Issue 1.0 SV8300 Management  For any system management action the DAP Manager is needed Replacing a DAP  When you replace a DAP be aware that it may contain subscription data. Therefore, you need to open the DAP Manager WEB interface and execute a delete DAP.
  • Page 49 The receiving DAP checks the radio signals on PARI, to make sure that it belongs to the same DECT system. If they belong to the same DECT system, the DAPs will synchronize with each other according to predefined rules. NEC IP DECT SV8300 Installation Guide 2 - 13...

  • Page 50: Synchronization Hierarchy

    Issue 1.0 SV8300 The DAPs are always transmitting via a minimum of two bearers. If there are no voice calls via a DAP, the DAP will transmit two dummy bearers. If there is one or more voice calls via the DAP, there will be one dummy bearer plus the voice call(s).

  • Page 51: Coverage And Signal Strength Calculation

    -10 dBm for fast fading -dips.) Synchronization is possible if the strength of the received signal from  another DAP is -80 dBm ... -85 dBm (this is adjustable). NEC IP DECT SV8300 Installation Guide 2 - 15...
  • Page 52 Issue 1.0 SV8300 In open area, the distance is doubled if the received signal strength is 6  dB lower. This means that at a minimum signal strength for good voice quality of -72 dBm and a distance “X”, the signal strength at the double distance (2X) is -78 dBm.

  • Page 53: Ip Port Number Assignments

    DECT Low Rate Messaging Service (LRMS) (Max. number of  characters depends on the type of handset used.) CLIP and Name Display.  Enquiry  Call Progress tones.  DTMF tones.  Message Waiting indication.  NEC IP DECT SV8300 Installation Guide 2 - 17...

  • Page 54: Environmental Conditions

    Issue 1.0 SV8300 DAP Software downloadable.  Capacity Max. number of simultaneous calls: 12  Please note that this maximum number of calls is only applicable when the DAP is synchronization source/master. If the DAP is not the synchronization master, the maximum number of simultaneous calls is 11.

  • Page 55: Ap300 (Not Available Anymore)

    The AP300E is the same as the AP300 but allows you to connect external antenna’s. When used in an AP200S configuration it does not support G.729. 8.1.5 AP400 (Currently available) This is the generic AP400, NEC branded. AP300/AP400 P OWER ROVISION ECTION The AP300/AP400 is powered via PoE.
  • Page 56 Issue 1.0 SV8300 The Branch office DAPs are not allowed to “see” DAPs of other Branch Offices or the Head Quarter. Because the RPN number range is related to the Head Quarter or to Branch Offices, the RPN number range is related to an IP network segment. The DAP Configurator lets you set up the configuration in a very simple way, by means of assigning RPN numbers to a Branch Office.

  • Page 57: Chapter 3 Licenses

    This license is required to have a redundant DAP Controller configuration in the Central site. Branch Office Survivability  You need this license to allow Local DAP Controllers in one or more Branch Office locations. NEC IP DECT SV8300 Installation Guide 3 - 1...

  • Page 58: Project Based Licenses

    Issue 1.0 SV8300 Software Upgrade Allowance  To upgrade a Release 6.0 to a higher version, you need an Upgrade License. When the license is activated, it provides a window of one month to install a higher version. Please note that this license is made dependant on the system size. The steps are: 10 DAPs ...

  • Page 59: System Assurance License

    It will cover all existing system configuration.  It is Free of Charge.  You must send the license file that is generated to NEC for registration. For new features, you must order a new license. NEC IP DECT SV8300 Installation Guide 3 - 3...

  • Page 60: Dmls Licenses

    Issue 1.0 SV8300 DMLS L ICENSES ECTION From Release 6 onwards, the DMLS is licensed in the DAP Controller License mechanism. You don’t need a dedicated license for the DMLS anymore. The license is based on the number of DAPs. In the DAP Controller, there is a license for “DECT Messaging”...

  • Page 61: Network Configurations

    IP switches. If the switches serve more than one VLAN, all IP DECT devices are put in one VLAN (therefore behaving as one subnet). The general characteristics of a simple configuration are as follows: NEC IP DECT SV8300 Installation Guide 4 - 1...
  • Page 62 Issue 1.0 SV8300 Seamless handover is supported between all DAPs.  Figure 4-1 Example of a Simple IP DECT Network Configuration 4 - 2 Network Configurations...

  • Page 63: Settings In Dap Configurator

    The DAP Configurator is described in Configuration - DAP Configurator Tool. However, in this section you will find an example of a setup for a simple configuration. Figure 4-2 IP DECT System Simple Configuration Screen NEC IP DECT SV8300 Installation Guide 4 - 3...

  • Page 64: Branch Office Solution

    Issue 1.0 SV8300 RANCH FFICE OLUTION ECTION Network Configuration Figure 4-3 Example of an IP DECT Configuration With a Branch Office shows an example of a Branch Office configuration with a main office (head quarter) and two Branch Offices. Main Office and Branch Offices are in different subnets connected via routers.

  • Page 65: Settings In Dap Configurator

    Multicast TTL = 1, which means that IP multicast packages does not  cross a router. Settings in DAP Configurator Refer to Figure 4-4 Branch Office Settings for configuring the Branch Office settings. Figure 4-4 Branch Office Settings NEC IP DECT SV8300 Installation Guide 4 - 5...

  • Page 66: Routed Head Quarter

    Issue 1.0 SV8300 OUTED UARTER ECTION Network Configuration Figure 4-5 Example of an IP DECT Routed Head Quarter Configuration shows an example of a Routed Head Quarter configuration with a head quarter and two subnets connected via one or more routers. The subnets in the network are part of one company network.

  • Page 67: Settings In Dap Configurator

    Head Quarter. So, this is NOT the IP subnet mask on the Network adaptors on the IP Network segments. Please do not mix up the Aggregated Subnet Mask and the normal IP Subnet mask. NEC IP DECT SV8300 Installation Guide 4 - 7...

  • Page 68: Routed Head Quarter With Branch Offices

    Issue 1.0 SV8300 OUTED UARTER WITH RANCH FFICES ECTION Network Configuration Figure 4-7 Example of an IP DECT Routed Head Quarter Configuration with Branch Office shows an example of a Routed Head Quarter configuration with a head quarter, one subnet connected via one or more routers and a Branch Office.

  • Page 69: Settings In The Dap Configurator

    Figure 4-8 Example of Setup for a Routed Head Quarter with Branch Office Configuration shows an example of a setup for a Routed Head Quarter with Branch Office configuration. Figure 4-8 Example of Setup for a Routed Head Quarter with Branch Office Configuration NEC IP DECT SV8300 Installation Guide 4 - 9...

  • Page 70: Routed Head Quarter With Routed Branch Offices

    Issue 1.0 SV8300 OUTED UARTER WITH OUTED RANCH FFICES ECTION Network Configuration shows an example of a Routed Head Quarter configuration with a head quarter, one subnet connected via one or more routers and a Branch Office. The subnets in the network are part of one company network, the Branch Office is connected over the WAN (or low throughput LAN).
  • Page 71 Head Quarters subnetworks (e.g. 255.255.252.0 for in this example.). Also in the Routed Branch Office, you must calculate the Aggregated subnet mask that covers all subnets in the Routed Branch Office. NEC IP DECT SV8300 Installation Guide 4 - 11...

  • Page 72: Settings In The Dap Configurator

    Issue 1.0 SV8300 Settings in the DAP Configurator Figure 4-10 Routed Head Quarter with Routed Branch Office Configuration show an example of a setup for a Routed Head Quarter with Routed Branch Office configuration. Figure 4-10 Routed Head Quarter with Routed Branch Office Configuration The Netmask Length in both items in the screenshot above is the ...

  • Page 73: Dap Installation Items

    Voltage at the DAP: minimum 36 Volts, maximum 57 Volts.  Connector: Standard RJ45 connector, using the spare wires pins  (wires). Refer to Figure 5-1 RJ45 Pinout. Maximum cable length: 100 meters.  Figure 5-1 RJ45 Pinout NEC IP DECT SV8300 Installation Guide 5 - 1...

  • Page 74: Dhcp And Tftp Requirements

    Issue 1.0 SV8300 DHCP TFTP R EQUIREMENTS ECTION The DAPs must get their IP addresses, configuration file and firmware from the IP network using a DHCP Server and a TFTP Server. DHCP Server When a DAP starts up, it tries to contact a DHCP server on the network. It should get the following items from the DHCP server: IP Address Subnet Mask...

  • Page 75: Tftp Server

    The DHCP server must issue an “Infinite” lease time. (The DHCP server  that comes with the DAP Controller issues such a lease time by default!) NEC IP DECT SV8300 Installation Guide 5 - 3...

  • Page 76: Using Other Dhcp And/Or Tftp Servers

    Issue 1.0 SV8300 In the configuration setup, you must select “Replace” from the drop down  menu for DAP Configuration in the boot options in the DAP Configurator screen. Refer to Section 3 IP Settings on page 9-3. When IP configuration and configuration file are stored in the DAP, the DAP does not need to have a DHCP server nor TFTP server anymore in the startup processes.

  • Page 77: Preparing Your Dap Manager Pc

    The DAP Controller/Manager supports the International  (English US) version of the above mentioned MS Windows operating systems. Other MS Windows language versions are not explicitly tested but are not expected to show any NEC IP DECT SV8300 Installation Guide 6 - 1...

  • Page 78: Iis And Internet Explorer

    Issue 1.0 SV8300 problems. In case of problems please contact your IP DECT Supplier, and clearly indicate which MS Windows version is used and the nature of the problem. IIS and Internet Explorer Besides the operating system, the Windows WEB server, called IIS (Internet Information Services) is required.

  • Page 79: Virtualization

    IP DECT Release 6 supports working on a Marathon platform, to provide fault tolerance. For more information on the Marathon software, please consult the NEC Unified web page. Please note, that IP DECT supports Redundancy on the DAP Controller, without Marathon.
  • Page 80 Issue 1.0 SV8300 THIS PAGE INTENTIONALLY LEFT BLANK 6 - 4 Preparing Your DAP Manager PC...

  • Page 81: Installing - The Dap Controller/Manager

    Depending on the version of your Windows operating system, you will now see a security screen from Windows saying "Do you want to allow the following program to make changes to your computer?" Click Yes. NEC IP DECT SV8300 Installation Guide 7 - 1...
  • Page 82 Issue 1.0 SV8300 You will see the following window. Figure 7-1 System Configuration Check Screen It indicates that the DAP Controller software supports your version of Windows. Click Next to proceed. Now the installation of "Prerequisites" takes place. Note that this can take several minutes! 7 - 2 Installing - The DAP Controller/Manager...
  • Page 83 Figure 7-2 Install Prerequisites Screen In case of Windows XP or Windows 2003, the system may ask for the Windows Operating System CD/DVD-ROM. If asked for, insert the CD/DVD-ROM. Click Next to continue. NEC IP DECT SV8300 Installation Guide 7 - 3...
  • Page 84 Issue 1.0 SV8300 Now the following screen is displayed, indicating that the system is ready to start the installation of the DAP Controller. Figure 7-3 DAP Controller Installation Wizard Click Next to continue. 7 - 4 Installing - The DAP Controller/Manager...
  • Page 85 Windows boots up. If you select “Single System”, the Services will be installed with startup parameters “Automatic”. You can always change the settings from Multiple System to Single System and  vice versa later on. NEC IP DECT SV8300 Installation Guide 7 - 5...
  • Page 86 Issue 1.0 SV8300 The following window is displayed. Figure 7-5 Setup Type Screen In this window “InstallShield Wizard” you should specify the “Setup Type”. Select Standard and click Next. Note that if you want to fine tune the installation you should select “Custom”.and click "Next".
  • Page 87 SV8300 Issue 1.0 10. The system has collected sufficient info to start the actual installation. Figure 7-6 Ready to Install Screen Click Install to start the installation. NEC IP DECT SV8300 Installation Guide 7 - 7...
  • Page 88 Issue 1.0 SV8300 11. When the installation is finished, you will see the window "InstallShield Wizard Completed". Figure 7-7 InstallShield Wizard Completed Screen When the checkbox "Launch DAP Configurator is checked, the DAP Configurator will start after clicking Finish. If not, the installation will finish, but the DAP Configurator will not be started.

  • Page 89: Configuration - Dap Configurator Tool

    3 in this procedure. If not, continue with the next step in this procedure. Start the DAP Configurator tool, via Start, All programs, DAP Controller, DAP Applications, DAP Configurator. NEC IP DECT SV8300 Installation Guide 8 - 1...
  • Page 90 Issue 1.0 SV8300 Figure 8-1 DAP Configurator Selection If there is a problem with your network card (e.g. no cable connection), you will get a message. Please solve the problem. If you do not see this message, continue with the next step in this procedure. 8 - 2 Configuration - DAP Configurator Tool...
  • Page 91 If you start-up the DAP Configurator for the first time, the system asks you for the license file. Figure 8-2 Select Licence File Screen Select the license file and click open. For IP DECT on the SV8300, you must always have a License file. NEC IP DECT SV8300 Installation Guide 8 - 3...
  • Page 92 Issue 1.0 SV8300 You will see the following window displayed. Figure 8-3 Setting Buttons Note that there are three sections in this window: System Control section at the left side.  Settings Buttons at the top part of the window. ...

  • Page 93: System Control Section

    The system status button leads you to a window in which you can control the system status. Refer to 3.2 System Status Window on page 8-6. Note that you must select a System (configuration) first, using the “Modify System” button. NEC IP DECT SV8300 Installation Guide 8 - 5...

  • Page 94: System Status Window

    Issue 1.0 SV8300 Export System  Allows you to export a system configuration. The exported file is always a .zip file and contains all relevant system configuration files, including subscription data, DAP configuration, DHCP data etc. The generated file can be imported later or can be imported on another PC that you want to use as DAP Controller/ Manager PC.
  • Page 95 The TFTP Service refers to the TFTP server that was automatically installed with the DAP Controller/Manager software. Note that this is not the MS Windows TFTP server. A TFTP Server must be running when one or more NEC IP DECT SV8300 Installation Guide 8 - 7...

  • Page 96: Single Site / Multi Site

    Issue 1.0 SV8300 DAPs start-up. The TFTP server supplies the DAPcfg.txt configuration file to the DAP(s). Note that there can be only one TFTP server running on your PC. If you start the TFTP service make sure that there is no other TFTP server running on your PC.
  • Page 97 Figure 8-7 About Screen You can switch to “Multiple system Support” or “Single System” by means of the check box in the window. Click Apply or OK to activate your selection. NEC IP DECT SV8300 Installation Guide 8 - 9...
  • Page 98 Issue 1.0 SV8300 THIS PAGE INTENTIONALLY LEFT BLANK 8 - 10 Configuration - DAP Configurator Tool...

  • Page 99: Dap Configurator Settings

    In the following subsections these settings are explained. ENERAL ETTINGS ECTION When you click the “General Settings” the following window is displayed: Figure 9-1 General Settings Screen NEC IP DECT SV8300 Installation Guide 9 - 1...
  • Page 100 Issue 1.0 SV8300 The following items must be entered: System Name  Can be any given name. Note that this name will be used for a directory on the hard disk. This means that the name must comply with the requirements for Windows directory names.

  • Page 101: Ip Settings

    Specify a Multicast IP address. If the network for your IP DECT system is used for other purposes than IP DECT as well or if the network has a connection to the company network or external network(s), you must ask NEC IP DECT SV8300 Installation Guide 9 - 3...

  • Page 102: Ip Settings, Tab "Dap Controller Ip Configuration

    Issue 1.0 SV8300 the local IT manager for a multicast address. If your IP DECT system is in a closed network, you can click the button “Default IP” to use the default IP multicast address. Port range from  By default the port range on the DAPs will start at port 3000. Please note that you cannot change port range.
  • Page 103 SV8300 Issue 1.0 Figure 9-4 DAP Controller IP Configuration (Continued) NEC IP DECT SV8300 Installation Guide 9 - 5...
  • Page 104 Issue 1.0 SV8300 Figure 9-5 DAP Controller IP Configuration (Continued) You fill in the data of all DAP Controllers in the DAP Configurator of the  Primary DAP Controller. DAP Controller IP Address  DAP Controller/Manager PC IP address. You can easily click the button “This PC IP”...

  • Page 105: Ip Settings, Tab "Pbx Ip Configuration

    Enter DRS (D-term Registration) port number on the SV8300. The default port is 3456. Multiple gatekeepers.  When you click this radio button, are able to enter more than one DRS address. This is can be useful for redundancy reasons. NEC IP DECT SV8300 Installation Guide 9 - 7...
  • Page 106 Issue 1.0 SV8300 Multiple Gatekeeper settings: When you select “Multiple Gatekeepers, the table in which you can add gatekeepers is activated. Right mouse click inside the table and select “new” to add a gatekeeper. The following items needs to be entered. Index ...

  • Page 107: Ip Settings, Tab "Cda Ip Configuration

    Corporate directory IP Address  The IP address of the Central Directory Server (if applicable) Corporate Directory port number  Port number on the Central Directory server. Default port number is 30160. NEC IP DECT SV8300 Installation Guide 9 - 9...

  • Page 108: Network Settings

    Issue 1.0 SV8300 ETWORK ETTINGS ECTION Network Settings, tab “Network Card Settings” Please click the tab: Network card settings. Now the following fields can be edited: Figure 9-8 Network Card Settings Select network card connected to the IP DECT system. ...

  • Page 109: Network Settings, Tab "Dhcp Settings

    DAPs only”. In that case it will ignore other DHCP requests. When you use the DHCP Server it will issue addresses in the range that you specify in the “DAP IP Range”. NEC IP DECT SV8300 Installation Guide 9 - 11...
  • Page 110 Issue 1.0 SV8300 When enabled, it runs as an Application under MS Windows. The settings are stored in the file dhcpsrv.ini in the system directory. DAP IP Range  Specify IP address range that will be issued to the DAPs. DAP IP Address range exclusive for DAPs only.

  • Page 111: Network Settings, Tab "Tftp Settings

    If you select the “3Com TFTP Server on this PC” it enables the TFTP server that is part of the DAP Controller/Manager software package. When enabled, it runs as “Service” under MS Windows. The settings are stored in the file 3CTftpSvc.ini NEC IP DECT SV8300 Installation Guide 9 - 13...
  • Page 112 Automatically filled in. The TFTP folder is the folder where all system information is stored. Default folder is: C:\Documents and Settings\All Users\Application data\Nec\DAP Controller\<system name>. When you are using Windows 7 or Windows 2008, the directory is C:\ProgramData\Nec\DAP Controller\<system name> TFTP Server IP Address. ...

  • Page 113: Network Settings, Tab "Leased Ip Addresses

    In this window, you can delete/change/add the relationship between MAC addresses and leased IP addresses. You have access to these settings by means of right mouse clicking a line in the Leased IP Addresses window. NEC IP DECT SV8300 Installation Guide 9 - 15...

  • Page 114: Network Settings, Tab "Qos Settings

    Issue 1.0 SV8300 Network Settings, tab “QoS Settings” Please click the tab: QoS Settings. Now the following fields can be edited: Figure 9-12 QoS Settings QoS on Layer 2  When you check this checkbox, the IEEE802.1p/q field in the layer 2 data package will be used.

  • Page 115: Network Settings, Tab "Boot Options

    This allows you to store the IP address data and Configuration data into Flash memory in the DAP. When stored, a DAP does not need a DHCP/ TFTP server anymore. Note that you can “Store” or “Erase” data. NEC IP DECT SV8300 Installation Guide 9 - 17...

  • Page 116: System Configuration

    Issue 1.0 SV8300 Data is stored when you have selected to store data AND when the DHCP  server issues an “Infinite” lease time. When finished, click “Apply” and continue with clicking button “System Configuration”. YSTEM ONFIGURATION ECTION When you click the “System Configuration” button, the following window is displayed: Figure 9-14 System Configuration Settings You can select the type of system that you want to use.

  • Page 117: Simple Configuration

    The window “Multiple Subnets” offers the possibility to specify a certain RPN range per Branch Office Subnet. Note that you should set the RPN range wide enough to allow future system expansion. NEC IP DECT SV8300 Installation Guide 9 - 19...
  • Page 118 Issue 1.0 SV8300 You will see the following screen: Figure 9-16 Multiple Subnets Settings In this window you can right mouse click a line in the shown table. Then you can add, edit or delete a Branch Office configuration. The following items must be specified: Subnet ...
  • Page 119 If you are using an Aggregated subnet (see bullet “Subnet” above), multicast routing is required between the different Subnets and therefore the TTL must be set to a value higher than 1 (advised 32). NEC IP DECT SV8300 Installation Guide 9 - 21...

  • Page 120: Routed Headquarter

    Issue 1.0 SV8300 If the subnet that you have filled in, is a real subnet, not Aggregated, you must make sure that the Time to Live is always 1. Gate Keeper  This is the Proxy address for the DAPs in this Subnet. Subnet name ...

  • Page 121: Sip Settings

    This is applicable for the “Routed Head Quarter” network solution either with or without Branch Offices, refer to and . SIP S ETTINGS ECTION Button is greyed out, due to the SV8300 being Protims-based. NEC IP DECT SV8300 Installation Guide 9 - 23...

  • Page 122: Dect Settings

    Issue 1.0 SV8300 DECT S ETTINGS ECTION DECT Settings, tab “DECT Settings” Please click the tab: DECT Settings. Now the following fields can be edited: Figure 9-18 DECT Settings Country Code  The Country code specifies the tone plan for IP DECT and also selects the correct frequency range and transmitter output power.

  • Page 123: Dect Settings, Tab "Handset Settings

    Please click the tab: Handset Settings. Now the following fields can be edited: Figure 9-19 Handset Settings Handset Page Timer  The Page Timer specifies the time in seconds between two page requests (retries). NEC IP DECT SV8300 Installation Guide 9 - 25...

  • Page 124: Dect Settings, Tab "Dap Settings

    Issue 1.0 SV8300 Page timer retry value  The Page Retry Value specifies the maximum number of paging retries that are issued, if paging a handset fails. Send date and time to handset  Self explaining. Display handset name in DAP Manager INT ...
  • Page 125 G.729. Therefore we advise not to apply G.729 on sites with a background noise. When finished, click “Apply” and continue with clicking button “PBX Settings”. NEC IP DECT SV8300 Installation Guide 9 - 27...

  • Page 126: Dect Settings, Tab "Synchronization Settings

    Issue 1.0 SV8300 DECT Settings, tab “Synchronization Settings” When you see a tab called “Synchronization Settings”, it indicates that you have a license for IP DECT in an environment with a lot of metal causing reflections. The license offers additional functionality to reduce the effects of the reflections.

  • Page 127: Pbx Settings, Tab "Three Party Conference Settings

    When you click the "Three party conference Settings" tab, the following window is displayed: Figure 9-22 Three Party Conference Settings Initiation digit  Digit that must be dialled to start the three party conference. The default setting is: *. NEC IP DECT SV8300 Installation Guide 9 - 29...

  • Page 128: Pbx Settings, Tab "Nec Pbx Settings

    Issue 1.0 SV8300 PBX Settings, tab “NEC PBX Settings” When you click the "NEC PBX Settings" tab , the following window is displayed: Figure 9-23 NEC PBX Settings The following items can be set or changed: Handset rejects an incoming call: ...
  • Page 129 If you do not get speech between IP DECT and IP D-Terms from the years 2003 and 2004, you should check this box, in order to swap the aLaw and uLaw CODEC. values. Display own number when going off-hook.  NEC IP DECT SV8300 Installation Guide 9 - 31...

  • Page 130: Performance / E-Mail Settings

    Issue 1.0 SV8300 Self explaining. When finished, click “Apply” and continue with clicking button “Performance / Email Settings”. / E- ERFORMANCE MAIL ETTINGS ECTION Performance / E-mail Settings, tab “PCR Settings” When you click the “PCR Settings” tab, the following window is displayed: Figure 9-24 PCR Settings The following parameters are available: Interval UPM generation every:...
  • Page 131 Each day performance measurement should take place, the performance measurement will stop at the time specified here. Create Performance counters every:  Specify the days that performance counter retrieval should take place. NEC IP DECT SV8300 Installation Guide 9 - 33...

  • Page 132: Performance / E-Mail Settings, Tab "Alarm Settings

    Issue 1.0 SV8300 Performance / E-mail Settings, tab “Alarm Settings” When you click the “Alarm Settings” tab, the following window is displayed: Figure 9-25 Alarm Settings E-mails can be send automatically when a DAP goes down or when the channel occupation threshold is exceeded for more than a number of seconds or when the DDS goes down.
  • Page 133 Time interval for sending emails. Default 24 hours, which means that the time interval between two emails will be 24 hours. Note that this is not a repetition timer. Once an email is send, it will not be repeated anymore. NEC IP DECT SV8300 Installation Guide 9 - 35...

  • Page 134: Performance / E-Mail Settings, Tab "Archive Settings

    Issue 1.0 SV8300 Performance / E-mail Settings, tab “Archive Settings” When you click the “Archive Settings” tab, the following window is displayed: Figure 9-27 Archive Settings The following parameters can be adjusted: Max. attachment size  This is the maximum attachment size. If the archive is larger than the size specified here, it will be chopped into pieces of the specified size.

  • Page 135: Performance / E-Mail Settings, Tab "E-Mail Settings

    After this date, archives are not automatically sent anymore. Performance / E-mail Settings, tab “E-mail Settings” When you click the “E-mail Settings” tab, the following window is displayed: Figure 9-28 E-Mail Settings NEC IP DECT SV8300 Installation Guide 9 - 37...
  • Page 136 Issue 1.0 SV8300 The following items are available: SMTP Server  Enter the DNS name or the IP address of the SMTP mail server. E-mail from  Enter the originators email address. Note that normally the SMTP server does not check the originators email address, which means that you can enter any email address here.

  • Page 137: Performance / E-Mail Settings, Tab "Miscellaneous Settings

    This is a guarding timer for the ASP scripts. E.g. if the ASP web pages try to send an archive and it takes longer than the time specified here, it will be terminated. The time is specified in seconds. NEC IP DECT SV8300 Installation Guide 9 - 39...

  • Page 138: Section 10 Customer Information

    Issue 1.0 SV8300 Use client resolution  If you check this box, you cannot scroll anymore through lists but the available information is chopped up into pages. You can select pages using tabs. If this box is unchecked, information is presented in a way that you can scroll through it using the scroll bar.

  • Page 139: Section 11 Save System And Start System

    When the system is running correctly, generate a visadm.txt file (in the WEB Page http://<DAP Controller IP Address>/cds/perfform.aspx) and analyze the file, using the SyncAnalyser tool. If necessary, re-arrange the synchronization structure. NEC IP DECT SV8300 Installation Guide 9 - 41...

  • Page 140: Section 13 License Handling

    Issue 1.0 SV8300 ICENSE ANDLING ECTION 13.1 Install a new License File You can easily install a new license file by means of the “Import license file” which is available at the bottom side of the DAP Configurator. Figure 9-31 Import License File The license file should have a file extension: .txt 9 - 42 DAP Configurator Settings...

  • Page 141: Reading Out The Licenses

    You can read out the license data by means of the License button in the General Settings window. Figure 9-32 License Information When you click the button, you will see the licenses presented as shown in the following sub-section. NEC IP DECT SV8300 Installation Guide 9 - 43...

  • Page 142: License Information Window

    Issue 1.0 SV8300 13.3 License Information Window Below, two examples of the License information window. Figure 9-33 License Information Window 9 - 44 DAP Configurator Settings...
  • Page 143 When you have a DMLS license for the DMLS itself, (to import into the DMLS directly), you can enter that license into the DAP Controller, by means of the button “Add DMLS”. NEC IP DECT SV8300 Installation Guide 9 - 45...
  • Page 144 Issue 1.0 SV8300 THIS PAGE INTENTIONALLY LEFT BLANK 9 - 46 DAP Configurator Settings...

  • Page 145: Chapter 10 Using Other Tftp Server

    Therefore, you must know the path settings of the TFPT Server that you are using. In the following table an overview is given of the TFTP Servers and the path settings. NEC IP DECT SV8300 Installation Guide 10 - 1...
  • Page 146 Settings\All Users\Application Data\Nec\DAP Controller\<system name>\. OR when you are using Windows 7 or Windows 2008, the directory is C:\ProgramData\Nec\DAP Controller\<system name>. This is the default directory for the “3com TFTP” server that came with the installation of the IP DECT system. If you are using the “3com TFTP” server, no manual action is needed anymore.
  • Page 147 SV8300 Issue 1.0 Windows 7 or Windows 2008, the path is: C:\ProgramData\Nec\DAP Controller\<system name> Make sure that the option “Next Boot Server” in the DHCP Server that you are using, points to the IP address of the PC where your TFTP Server is running.
  • Page 148 Issue 1.0 SV8300 THIS PAGE INTENTIONALLY LEFT BLANK 10 - 4 Using Other TFTP Server...

  • Page 149: Chapter 11 Opening Dap Manager Web Interface

    Subscribe the handsets. Note, that you cannot make phone calls when the SV8300 is not yet setup for IP DECT. Therefore continue with the next Chapter to setup the SV8300. After that, check that you can make phone calls. NEC IP DECT SV8300 Installation Guide 11 - 1...
  • Page 150 Issue 1.0 SV8300 THIS PAGE INTENTIONALLY LEFT BLANK 11 - 2 Opening DAP Manager Web Interface...

  • Page 151: Chapter 12 Setting Up The Sv8300 Configuration

    Branch Office DAPs refer to the IPLA CPU) in the Remote PIM. Use the functionally of Multiple Gate Keepers. See Section 3.4 IP  Settings, tab “PBX IP Configuration” on page 9-7. NEC IP DECT SV8300 Installation Guide 12 - 1...

  • Page 152: Step-By-Step Procedure

    Issue 1.0 SV8300 ROCEDURE ECTION Setting Up SV8300 The following procedure guides you through setting up the SV8300 for Business Mobility IP DECT. PROCEDURE:Setting up the SV8300 Make sure that the "Nation Code Assignment" is set to "Asia/Africa/ Europe/Latin America/Middle East/Russia". Use the following command for assigning the Nation Code: CM 310>0>05<Execute>...
  • Page 153 When you assign a station number to a Virtual Port, the Prime line is assigned automatically. You don’t need to execute command 93 anymore, only if you want to check whether the Prime line is correctly assigned. NEC IP DECT SV8300 Installation Guide 12 - 3...
  • Page 154 Issue 1.0 SV8300 When you assign a station number to Virtual Ports, command 9000 automatically assigns the station number to line key 01. Because MyLine is automatically assigned to key 01 and IP DECT requires  MyLine to be assigned to key 16, you must remove the MyLine from key 01 and assign it to key 16 for all IP DECT extensions.
  • Page 155 The advised payload is 40 msec. Other payload settings are possible, however,  make sure that the payload is always equal for G.729 and G.711! The following commands show an example for Location Group 00 and CODEC list 0. NEC IP DECT SV8300 Installation Guide 12 - 5...
  • Page 156 Issue 1.0 SV8300 Use command 42 for the CODEC settings: CM42>100>02<Execute> set CODEC list "0" to G.711 and aLaw (first priority) CM42>101>04<Execute> set CODEC list "0" to G.729 (second priority) CM42>110>04<Execute> set CODEC list "0" to 40 msec. payload for G.711.
  • Page 157 Note that when you use Protected Login mode, the password must be the same as the station number! Note that when you use Automatic Login, a password is not required. 42>73>01>01-08, NONE=4 digits Figure 12-1 Login Structure in the SV8300 NEC IP DECT SV8300 Installation Guide 12 - 7...
  • Page 158 Issue 1.0 SV8300 THIS PAGE INTENTIONALLY LEFT BLANK 12 - 8 Setting Up The SV8300 Configuration...

  • Page 159: Chapter 13 Features (Sv8300)

    DAP Controller. The DAP Controller sends a Logout command to the SV8300. This removes the MAC address for the handset from the SV8300. Logout is now active for the handset. NEC IP DECT SV8300 Installation Guide 13 - 1...
  • Page 160 Issue 1.0 SV8300 This feature is only applicable on all handset types from 2008 and onwards. All  other types of DECT handsets are not capable of sending a detach signal and therefore do not support this feature. Call Forwarding on Logout (not Reachable) will not be activated when the ...

  • Page 161: Call Forwarding On Logout / Call Forwarding Not Reachable

    IP DECT extension in the SV8300. Assign MyLine 2000 to station number 2100 under key 8. (Key number must be in the range 1...8.) Use the following command: CM9000>2100,08>2000<Execute> NEC IP DECT SV8300 Installation Guide 13 - 3...
  • Page 162 Issue 1.0 SV8300 Assign MyLine 2100 to station number 2000 under key 8. (Key number must be in the range 1...8.) Use the following command: CM9000>2000,08>2100<Execute> Allow “ringing line pickup” in Service Restriction Class C (in this example the default Service Restriction Class, 15). Use the following command: CM15082>15>0<Execute>...

  • Page 163: Twinning Relation Between Dect Handset And (Ip) Dterm

    If one of the extensions sets up a call to a destination, the destination will show one Calling Line ID, NEC IP DECT SV8300 Installation Guide 13 - 5...
  • Page 164 Issue 1.0 SV8300 independently from which extension the call is made. The following gives an example of a twinning relation between a DECT handset and an IP Dterm (or Dterm) as if they are one extension. PROCEDURE:Twinning between DECT handset and (IP) Dterm, as if they are one extension.
  • Page 165 Station number 2000 should be handled as dummy number. Calls to 2000 will get ringback tone but cannot be answered. MyLine number display should be disabled, otherwise number 2000 will be displayed on the (IP) Dterm. NEC IP DECT SV8300 Installation Guide 13 - 7...

  • Page 166: Three/Four Party Conference

    Issue 1.0 SV8300 HREE ARTY ONFERENCE ECTION IP DECT supports three or four party conference. It makes use of the three/four party conferencing as available in the SV8300. Therefore, make sure that your SV8300 configuration/setup supports three/four party conference for IP phones. PROCEDURE:How to setup a three party conference call 1.
  • Page 167 Portable Sharing. The numbers in this range may NOT exist as station numbers in the 2000IPS/SV8300. These numbers must start with the same “prefix”. This prefix must be specified in the DAP Configurator and could be e.g. “00”. NEC IP DECT SV8300 Installation Guide 13 - 9...

  • Page 168: How To Implement

    Issue 1.0 SV8300 How to Implement The numbers that you use for Portable Sharing may never be existing  (subscription) handsets numbers. So you must always create extra Station numbers which can be used as a pool of Station numbers for handsets using Portable Sharing.

  • Page 169: Portable Sharing And The Dap Manager

    Party “A”. In case of a DECT phone, you do not have the “Recall” button. You must simulate the “Recall button”, by means of pressing the # button. (The # button simulates the function of the Recall button.) NEC IP DECT SV8300 Installation Guide 13 - 11...

  • Page 170: Led Indication On Handset

    Issue 1.0 SV8300 LED I NDICATION ON ANDSET ECTION General The LED indication on the handset may indicate “incoming call” and/or “voice message waiting”. The SV8300 allows you to manipulate the behavior of the LED on the handset. A limited number of types of handsets support this feature. So, the ...

  • Page 171: Chapter 14 Ip Dect Mobility In Sv8300

    Make sure that you have sufficient licenses for the Remote Site. Use  command F88>16> to read out the number of Remote Site licenses. The “Zenia” handset is not supported for IP DECT Mobility using a SARI.  NEC IP DECT SV8300 Installation Guide 14 - 1...

  • Page 172: Setting Up User Mobility In Ip Dect

    Issue 1.0 SV8300 SV8300 ETTING UP THE ONFIGURATION IN ECTION Setting up the configuration in the SV8300 for DECT Mobility is the same as for User Mobility in an SV8300 Remote Unit. Setting up such a configuration is described in the “SV8300 Networking Manual”, chapter “Remote Unit”.

  • Page 173: Ip Dect System With Branch Offices

    Site. When the handset moves back to the Main Site, the same mechanism is used but now in the Main Unit. However, the DAPs in the Main Site must use the IPLA IP address of the Main Unit as Gatekeeper address. This means that NEC IP DECT SV8300 Installation Guide 14 - 3...

  • Page 174: Individual Ip Dect Systems

    Issue 1.0 SV8300 the configuration files for the DAPs in the Head Quarter (Main Site) must have a different Gatekeeper IP address as the DAP(s) in the Remote Site. Therefore, you must have (at least) two different dapcfg.txt files in the IP DECT system.

  • Page 175: Chapter 15 Dap Controller Redundancy

    The maximum number of Local DAP Controllers is 10. The difference between a Central and a Local DAP Controller is determined by the configuration that you setup in the “DAP Configurator” in the Primary DAP Controller. NEC IP DECT SV8300 Installation Guide 15 - 1...
  • Page 176 Issue 1.0 SV8300 Below, you see the DAP Configurator screen in which you must setup the configuration. Please note that you determine the difference between the Central and the Local DAP Controller here together with the priority. So, for the Central DAP Controller, you specify a Primary and if required, a Secondary DAP Controller.

  • Page 177: Dap Controller Redundancy For Roaming

    Branch Office, when the handset moves to the other Branch Office. The DAP Controller takes care of this functionality. To make this mechanism more reliable, the DAP Controller must be made redundant. NEC IP DECT SV8300 Installation Guide 15 - 3...
  • Page 178 Issue 1.0 SV8300 DAP C ONTROLLER EDUNDANCY IN ESSAGING ECTION ONFIGURATION DAP Controller Redundancy in a messaging configuration, means that you have two DAP Controllers and two DMLS services. Please note that in this description, we assume that we have Central DAP Controllers (Primary and Secondary), and no Local DAP Controllers.
  • Page 179 Primary DAP Controller will issue a paging request via all DAPs in the system, to page the handset. When the handset responds, the message is sent to the handset. Figure 15-3 Messaging When Primary DAP Controller is Active NEC IP DECT SV8300 Installation Guide 15 - 5...
  • Page 180 Issue 1.0 SV8300 Message to the handset when Primary DAP Controller is down.  Figure 15-4 Messaging to Handset When Primary DAP is Down shows that, when the Primary DAP Controller is down, the Messaging Application will send the message to the DMLS (DMLS 2) that is connected to the Secondary DAP Controller.
  • Page 181 Secondary DAP Controller. The DAP checks if the Primary DAP Controller is up- and-running. If it is up-and-running, it will send the message to the Primary DAP Controller. If not running, it will send the message to the secondary DAP Controller. NEC IP DECT SV8300 Installation Guide 15 - 7...

  • Page 182: Dap Controller Redundancy - How Does It Work

    Issue 1.0 SV8300 DAP C – H ONTROLLER EDUNDANCY OW DOES IT WORK ECTION In the DAP Controller Redundancy, there is a Primary DAP Controller and a Secondary DAP Controller. Please note that in an operational configuration, both DAP Controllers are up-and-running. The Primary DAP Controller contains the actual and up-to-date configuration.

  • Page 183: Local Dap Controllers

    Branch Office only, in case the Central DAP Controllers (Primary and/or Secondary) are not reachable anymore. It performs a kind of Survivability task. There can be up to 10 Local DAP Controllers. NEC IP DECT SV8300 Installation Guide 15 - 9...
  • Page 184 Issue 1.0 SV8300 The DAPs in the Branch Office will check if the Central DAP Controllers are reachable. If not, they will check if the Local DAP Controller is reachable, and they lock on the local DAP Controller. Figure 15-7 Example of Mixed DAP Controllers, Central and Local shows a configuration with mixed DAP Controllers, Central and Local.
  • Page 185 Normally you will do DECT Management on the Primary DAP Controller,  and you will have full DECT Management functionality available. At the Secondary DAP Controller  When you open the WEB page on the Secondary DAP Controller with  NEC IP DECT SV8300 Installation Guide 15 - 11...
  • Page 186 Issue 1.0 SV8300 address “Localhost”, you will be redirected to the Primary DAP Controller and you will have full DECT Management functionality available. When the Primary DAP Controller is not up-and-running, you will not be redirected, but you will see the Secondary DAP Controller DECT Manager window in Read Only mode.
  • Page 187 Upgrade To Latest Release To upgrade to the latest release of the DAP Controller software consult the IP DECT Advanced Data Manual. NEC IP DECT SV8300 Installation Guide A - 1...
  • Page 188 Issue 1.0 SV8300 THIS PAGE INTENTIONALLY LEFT BLANK A - 2...
  • Page 189 PoE IEEE802.3af. adaptor and PoE No local power supply. support IEEE802.3af DC voltage on 36 - 60 Volt 36 - 57 Volt DAP via PoE PoE Class Class 0 Class 2 NEC IP DECT SV8300 Installation Guide B - 1...
  • Page 190 Issue 1.0 SV8300 Table B-1 Differences Between AP200 and AP300 ITEM AP200 AP300 Service/ One LED for Two LEDs, one for AP300 maintenance AP200 status. status, another for AP300 network status indication. Table B-2 Physical Differences ITEM AP200 AP300 Dimension 235 x 45 x 172 mm 145 x 43 x 174 (w x d x h) (w x d x h)

  • Page 191: Overview Of Differences

    AP400 Generic type, NEC branded DAP Type: Generic Type, un-branded DAP Type: AP300C AP400C Type to be used on NEC SMB systems. DAP Type: Generic type with connectors for external antennas NEC IP DECT SV8300 Installation Guide C - 1...
  • Page 192 SV8300 Table C-1 AP300 vs. AP400 Differences ITEM AP300 AP400 DAP Type: AP400S Type to be used on NEC SMB PBXs, but with a max. of 4 DAPs per system. Boot Package In Read Only In Flash memory. Memory Name: 49920xxx.dwl...

  • Page 193: Appendix D Lrms Messaging

    DMLS (DECT Messaging and Location Services). The DMLS offers a rich, yet simple, interface for Third Party messaging servers. For more information about Messaging Server applications, please contact your IP DECT supplier. NEC IP DECT SV8300 Installation Guide D - 1...
  • Page 194 Issue 1.0 SV8300 The following figure shows the message path between a Messaging Server and IP DECT. Figure D-1 Message Path in IP DECT - Messaging Server Configuration Note that the messaging between the Messaging Server and IP DECT, always goes via the DAP Controller/Manager.

  • Page 195: Types Of Messages

    Broadcast Messaging is implemented from IP DECT Release 4.2 onwards. Broadcast messaging will normally be used in case of an emergency situation where a large group of people needs to be reached in a very short time. NEC IP DECT SV8300 Installation Guide D - 3...

  • Page 196: Additional Broadcast Message Types

    Issue 1.0 SV8300 Broadcast Messaging has the following characteristics: It uses a kind of “connection-less” data transfer.  To improve message delivery, the Messaging Server can repeat the  message a few times. The handset will ignore duplicate messages. Neither the portable nor the end-user can confirm reception of the ...

  • Page 197: How About Normal, Urgent, Emergency Messages

    This timer is always longer that 30 seconds and normally shorter than one minute. The time value may be different per handset type. NEC IP DECT SV8300 Installation Guide D - 5...
  • Page 198 Issue 1.0 SV8300 Urgent and Emergency broadcast Message  When the handset receives a broadcast Emergency message, it appears on the handset as if it is unicast Emergency message. The ringing rhythm is the same. To stop the ringing, the handset user has to acknowledge the message by means of pressing the “OK”...

  • Page 199: Appendix E Overview Of Default Ip Ports

    (28001). IP DECT 3000-22635 Proprietary signalling (IP Unicast and IP Multicast), Protims Protocol and RTP (Real Time Protocol) TFTP TFTP Server (only for initial communication) then:1024-65535 SV8300 MP 3456 NEC IP DECT SV8300 Installation Guide E - 1...
  • Page 200 Issue 1.0 SV8300 THIS PAGE INTENTIONALLY LEFT BLANK E - 2...
  • Page 202 ® IP-DECT Installation Guide NEC Corporation of America Issue 1.0...

Table of Contents
