- Page 1 ™ P e r f o r m a n c e , D e l i v e r e d . 3/4HP Jet Pump (Shallow) Made in China/Fabriqué en Chine Lotus Tool Group (Philippines) www.lotustools.ph LM75X...
-
Page 2: Products Overview
Drawing of Installation a) Check the electirc pump includes the cable, terminal or plug (if equipped) before the installation to see whether is any damage in transit or storage. Check whether the cold insulation resistance exceeds 50MΩ Lotus Tool Group ®... -
Page 3: Maintenance
50mΩ. Otherwise corresponding measures shall be taken. The electric pump could not be reused until it meets the operation requirement 2. The maintenance job should be taken according to the next step. Lotus Tool Group ®... - Page 4 8. If the shaft does not run freely, release it using a screwdriver inserting in the special slot. If this is not sufficient to solve the problem, remove the pump body, undoing the relevant mounting bolts and clean it throughly to remove any encrustation. Lotus Tool Group ®...
-
Page 5: Troubleshooting
3. Impeller clogged or send it to the service agency for repair. 4. Electric pump starts frequently 5. Electric pump overload 6. Phase lost for three-phase electric pump Lotus Tool Group ®... -
Page 6: Technical Data
7. TECHNICAL DATA SKU: LM75X Power: 3/4HP Rated Voltage/Frequency: 220V / 60Hz Speed: 3450rpm Max. Flow Rate: 2.5m³/h Max. Height: 30m Inlet x Outlet: 1”x1” Cable Length: 35cm Lotus Tool Group ®... - Page 7 Terminal cover Screw Snap ring Screw Washer Cable presser I mpeller “ O” ring Woun d stator Rotor Mechanical Seal Split ring Pump support Back cover Drops gua rd Bolt Bearing Snap ring Fan cover Bolt Lotus Tool Group ®...
