INDOOR UNIT FOR VRF SYSTEM
TECHNICAL & SERVICE MANUAL
Series PLFY
Indoor unit
[Model Name]
PLFY-EP06NEMU1-E
PLFY-EP08NEMU1-E
PLFY-EP12NEMU1-E
PLFY-EP15NEMU1-E
PLFY-EP18NEMU1-E
PLFY-EP24NEMU1-E
PLFY-EP30NEMU1-E
PLFY-EP36NEMU1-E
PLFY-EP48NEMU1-E
Grille model
[Model Name]
PLP-41EAEU
Model name
indication for
MAIN UNIT
INDOOR UNIT
WIRELESS REMOTE
CONTROLLER
(Option)
[Service Ref.]
PLFY-EP06NEMU1-E.TH
PLFY-EP08NEMU1-E.TH
PLFY-EP12NEMU1-E.TH
PLFY-EP15NEMU1-E.TH
PLFY-EP18NEMU1-E.TH
PLFY-EP24NEMU1-E.TH
PLFY-EP30NEMU1-E.TH
PLFY-EP36NEMU1-E.TH
PLFY-EP48NEMU1-E.TH
Model name
indication for GRILLE
ON
RETURN SELECT
MENU
HOLD
OFF
WIRED REMOTE
CONTROLLER
(Option)
R410A
Revision:
• Some descriptions have
TCH129 is void.
CONTENTS
1. SAFETY PRECAUTION .......................... 2
3. SPECIFICATIONS ................................... 5
4. 4-WAY AIRFLOW SYSTEM .................. 11
6. WIRING DIAGRAM ............................... 15
9. TROUBLESHOOTING .......................... 24
10. DISASSEMBLY PROCEDURE ............. 32
11. REMOTE CONTROLLER ..................... 37
PARTS CATALOG (TCB129)
January 2024
No. TCH129
REVISED EDITION-A
been modified.
