INDOOR UNIT FOR VRF SYSTEM
TECHNICAL & SERVICE MANUAL
Indoor unit
[Model Name]
PLFY-P08NEMU-E
PLFY-P12NEMU-E
PLFY-P15NEMU-E
PLFY-P18NEMU-E
PLFY-P24NEMU-E
PLFY-P30NEMU-E
PLFY-P36NEMU-E
PLFY-P48NEMU-E
Model name
indication for
MAIN UNIT
INDOOR UNIT
[Service Ref.]
PLFY-P08NEMU-E
PLFY-P12NEMU-E
PLFY-P15NEMU-E
PLFY-P18NEMU-E
PLFY-P24NEMU-E
PLFY-P30NEMU-E
PLFY-P36NEMU-E
PLFY-P48NEMU-E
Model name
indication for GRILLE
REVISED EDITION-D
R410A
Revision:
• DISASSEMBLY PROCEDURE
has been modified in
REVISED EDITION-D.
• Some descriptions have been
modified.
OCH611 REVISED EDITION-C
is void.
CONTENTS
1. SAFETY PRECAUTION ......................... 2
3. SPECIFICATIONS ................................. 11
4. 4-WAY AIRFLOW SYSTEM .................. 16
6. WIRING DIAGRAM ............................... 20
9. TROUBLESHOOTING .......................... 29
PARTS CATALOG (OCB611)
March 2018
No. OCH611

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CITY MULTI Series and is the answer not in the manual?

Questions and answers

Related Manuals for Mitsubishi Electric CITY MULTI Series

Summary of Contents for Mitsubishi Electric CITY MULTI Series

  • Page 1: Table Of Contents

    INDOOR UNIT FOR VRF SYSTEM March 2018 No. OCH611 REVISED EDITION-D TECHNICAL & SERVICE MANUAL R410A Indoor unit [Model Name] [Service Ref.] PLFY-P08NEMU-E Revision: PLFY-P08NEMU-E • DISASSEMBLY PROCEDURE has been modified in PLFY-P12NEMU-E PLFY-P12NEMU-E REVISED EDITION-D. • Some descriptions have been modified.
