MGC ENCL-400-W-WP Replacement

This manual covers the following models:
ENCL-400-W-WP White Enclosure For Weather Protected 400 NAC Series
ENCL-400-WP Red Enclosure For Weather Protected 400 NAC Series
ENCL-SPPS-W-WP White Enclosure For Weather Protected SPPS Series
ENCL-SPPS-WP Red Enclosure For Weather Protected SPPS Series
Rated for Outdoor Environment Wet Location
-40 °C to +66 °C (-40 F to 151 F)
7 7/16"
(189 mm)
Figure 1
Figure 2 ENCL-SPPS-WP side view
Push in the 4
optional tabs if
required
Mounting holes
for SPPS-204-WP,
SPP-204-WP
2 threaded knockouts (NPT 3/4") on top and bottom
and 2 knockout holes for 3/4" conduit on left and right
Figure 4
ENCL-400-WP and ENCL-SPPS-WP
Replacement Weather Protected
7 15/16" (202 mm)
7 7/16" (189 mm)
8 5/8" (219 mm)
Bottom view
4 7/16"
(112 mm)
Top view without cover
3 15/16"
(100 mm)
Figure 3 ENCL-400-WP side view
CAUTION: Do not
remove rubber
gasket
Apply outdoor-rated
Mounting holes for
weatherproof silicone to the 2
FH-400-WP,
mounting holes and around the
FS-400-WP,
FHS-400-WP conduit connectors.
www.mircomgroup.com LT-6510 Rev. 1 Dec. 2024
Enclosures
4 5/8"
(117 mm)
