Rated for Outdoor Environment Wet Location
-40 °C to +66 °C (-40 F to 151 F)
7 7/16"
(189 mm)
Figure 1
Figure 2
ENCL-SPPS-WP side view
Push in the 4
optional tabs if
required
Mounting holes for
SPPS-204-25R-WP,
SPPS-204-70R-WP,
SPP-204-25R-WP,
SPP-204-70R-WP
2 threaded knockouts (NPT 3/4") on top and bottom
and 2 knockout holes for 3/4" conduit on left and right
Figure 4
ENCL-400-WP and ENCL-SPPS-WP
Replacement Weather Protected
7 15/16" (202 mm)
7 7/16" (189 mm)
8 5/8" (219 mm)
Bottom view
4 7/16"
(112 mm)
Top view without cover
3 15/16"
(100 mm)
Figure 3
ENCL-400-WP side view
CAUTION: Do not
remove rubber
gasket
Mounting holes for
FH-400-RR-WP,
FS-400-RR-WP,
FHS-400-RR-WP
www.mircomgroup.com LT-6510 Rev. 0 Jan. 2024
Enclosures
4 5/8"
(117 mm)
Advertisement
Related Manuals for MGC ENCL-400-WP
Summary of Contents for MGC ENCL-400-WP
- Page 1 ENCL-400-WP and ENCL-SPPS-WP Replacement Weather Protected Enclosures Rated for Outdoor Environment Wet Location -40 °C to +66 °C (-40 F to 151 F) 7 15/16” (202 mm) 3 15/16” 7 7/16” (100 mm) (189 mm) 7 7/16” (189 mm) 8 5/8” (219 mm)
- Page 2 Mount ENCL-400-WP directly on the wall or ceiling depending on the model of horn, strobe or horn/strobe. When mounting on the wall, mount the enclosure with the word TOP at the top, and mount the device with the MGC nameplate at the top.
