RV WATER HEATER

Model:TMRVQ-05010142/TMRVQ-05010242/TMRVQ-05010165

/TM-RV03-2/TM-RV03-2B

We continue to be committed to provide you tools with competitive price.

"Save Half", "Half Price" or any other similar expressions used by us only

represents an estimate of savings you might benefit from buying certain tools

with us compared to the major top brands and does not necessarily mean to cover

all categories of tools offered by us. You are kindly reminded to verify carefully

when you are placing an order with us if you are actually Saving

Half in comparison with the top major brands.

Table of Contents

Need help?

Do you have a question about the TMRVQ-05010142 and is the answer not in the manual?

Questions and answers

Summary of Contents for VEVOR TMRVQ-05010142

Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support RV WATER HEATER Model:TMRVQ-05010142/TMRVQ-05010242/TMRVQ-05010165 /TM-RV03-2/TM-RV03-2B We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
Page 3 Water heaters for recreational vehicle installation only！ WARNING READ THIS INSTRUCTION MANUAL CAREFULLY BEFORE OPERATION. RETAIN THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE. WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or death. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
Page 4 Obey all safety messages that follow this symbol to avoid possible injury or death. WARNING Failure to obey the following warnings could result in death or serious injury: Follow the information in this manual exactly. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
Page 5 Relief valve must be installed near the hot water outlet. A water heater shall not be connected to a chimney flue serving a separate appliance, designed to burn solid fuel. Provisions for adequate combustion and ventilation air in accordance with one of the following: A) the National Fuel Gas Code, ANSI Z223.1/NFPA 54;...
Page 6 Rated gas 0.408psi 0.408psi 0.408psi pressure Water inlet 1/2 NPT 1/2 NPT 1/2 NPT connection Water outlet 1/2 NPT 1/2 NPT 1/2 NPT connection Gas joint 1/2 NPT 1/2 NPT 1/2 NPT connection SAFE OPERATION ENVIRONMENT Gas combustion consumes a large amount of air and generates hot exhaust gases including carbon monoxide as the appliance works.
Page 7: Packing List
ensuring non-potable water sources, components, or heating systems, new or old, are not connected in any means to the appliance. DRIVING GUIDELINES ♦ The operator is responsible for ensuring all components are seated and locked in place before moving the RV, check the following: (1) Access door is flush with the mounting plate. AND (2) Door lock is engaged.
Page 8 Remote LCD Display Screw Kit 12+3 Tip:“+”is extra spare parts. Operation and Maintenance Pressure Relief Valve DANGER EXPLOSION OR SCALDING HAZARD. Failure to obey the following warnings could result in death or serious injury. • Do not tamper with the pressure relief valve. •...
Page 9: Installation
If a discharge line is used, do not use a reducing coupling or other restriction smaller than the outlet of the pressure relief valve. Allow both the valve and the line to completely drain. This water heater is equipped with a pressure relief valve that complies with the standard for Relief Valves and Automatic Gas Shutoff Devices for Hot Water Systems, ANSI Z21.22/CSA 4.4.
Page 10: Install Appliance
Provide adequate clearance at the rear of the unit for easy service access to the water connections. • This appliance must be installed by a qualified professional installer. • To install the Water Heater on carpeting, install the Water Heater onto a metal or wood panel that extends at least 3 in.
Page 11 Position the appliance into the frame Step 1： Step 2：Keep it flush with the wall. opening. Step 3:Assembled door panel. Step 4:Secure the door panel with screws. Step 5:Fasten the water heater to the RV with screws. 4.Ensure that the electrical power switch on the front of the appliance is set to the OFF position 5.Ensure that the gas supply is turned OFF.
Page 12 7.Connect the power supply wires (red and black wires on rear of water heater) to the appropriate nominal 12V DC power source connection. NOTE: The red wire is positive (+) and the black wire is negative (-). 8.Connect the wall controller wires (2 blue wires on the appliance). NOTE: Polarity does not matter, the wires can be connected to either blue wires.
Page 13: Operation
that will drain to the exterior of the RV. Performing Leak Testing WARNING FIRE AND/OR ELECTRICAL SHOCK HAZARD. Do not use matches, candles, or other sources of control when checking for gas leaks. Failure to obey this warning could result in death or serious injury. Isolate the Water Heater from the gas supply piping system before performing any pressure test equal to or greater than 0.5 PSI (34 mbar).
Page 14 Shut off gas appliances when refueling.  Use with L.P. gas only.  Turn gas off at the L.P. tank when the vehicle is in motion. This disables all gas appliances.  Gas appliances must never be operated while the vehicle is in motion. Unpredictable wind ...
Page 15 ON/OFF button: 1. Switch between on and off status. 2. On/Off Indicator: When the power is turned on, the indicator will be permanently on. When the power is off, the indicator will be shut off. 3. In the case of a system failure, pressing this button clears the fault code. Temperature adjustment button: At each press the heat up /heat down...
Page 16: Error Code
3. Adjust the set temperature to your preference. 4. Turn on the faucet. 5. The water heater will ignite the flame and heat the water to preset temperature. Operations in Freezing Temperatures The water heater is equipped with an automatic heating system and can be used in cold weather conditions.
Page 17: Product Details
Replace the controller System is firing the burner to prevent freezing of any water in the system. Cold Weather Anti Freeze operations Burners will run until safe warmer temperature is reached. Normal operations. PRODUCT DETAILS EXPLODED VIEW I （TMRVQ-05010142、TMRVQ-05010242、TMRVQ-05010165） - 16 -...
Page 18 Serial number Name Serial number Name Gas Inlet Connector Conversion head Bottom shell Outlet water temperature probe Guard coil Water Inlet temperature probe Gas proportional valve Cock heat exchanger Pressure relief valve Antifreeze thermostat Front outlet valve Overheat protection thermostat Stent 2 - 17 -...
Page 19 Water Inlet Connector Stent 3 Outlet pipe The chimney Water flow sensor Controller Door Frame Case cover Door Burners Door lock Power Cord Decorative rings Stent 1 EXPLODED VIEW II （TM-RV03-2、TM-RV03-2B） - 18 -...
Page 20 Serial Name number Gas Inlet Connector Bottom shell Guard coil Gas proportional valve heat exchanger Antifreeze thermostat Overheat protection thermostat Water Inlet Connector Outlet pipe Water flow sensor Case cover Burners Power Cord Stent 1 Conversion head Outlet water temperature probe Water Inlet temperature probe Cock Pressure relief valve...
Page 21: Maintenance
Verify proper operation after servicing. MAINTENANCE We recommend that the water heater be inspected monthly by the user and at least once a year by service technician. Before an inspection, make sure that the Electrical Power, LP Gas and Water systems are turned on. Purge air out of ALL hot and cold water lines.
Page 22: Troubleshooting
1.Inspect the integrity of the sealing (caulking or tape) between the side wall and the door of the water heater and ensure that the unit is solidly mounted to the vehicle. 2.Verify that the air inlet openings (louvers) are completely open and clear of any debris including mud, leaves, twigs, insects etc.
Page 23 The liquefied gas has been Replace the liquefied gas depleted? cylinder The gas valve and the inlet Open gas valve and the inlet valve are not opened valve completely completely Cannot produce hot water with The set temperature exceeds Reset to operational higher temperature capabilities temperature...
Page 24 Technical Support and E-Warranty Certificate www.vevor.com/support...
