IS4T/5T/6T-WP
IS4T
WP - IS5T
WP - IS6T
MAIN FEATURES
• Compact dimensions
• Quick installation
• Suitable for indoor and outdoor
installations
PACKAGE CONTENTS
The box contains:
N°1 ISxT-WP speaker
N°1 wall bracket
N°2 screw
N°2 rubber washer
This quick start and warranty documentation
DESCRIPTION
IS-WP is the new dB Technologies versatile
passive speaker series designed with the
specific needs of installers in mind for an
immediate and user-friendly application.
The three cube models available (4", 5",
6.5" woofer respectively) are an optimal
solution for indoor and outdoor sound rein-
forcement with quick installation guarante-
ed by the included bracket, invisible moun-
ting points, and a IP55 certification.
ACCESSORY
SP-IS
speakON® panel
QUICK START USER MANUAL SECTION 1
DIMENSIONS
WP
TECHNICAL SPECIFICATIONS
Speaker Type:
Protection against
solid objects and
liquids:
Coverage (HxV):
RMS Power:
Rated impedance:
HF:
LF:
Signal Input/Output:
Housing:
Dimensions
(WxHxD):
Weight:
1
W
IS4T-WP
IS5T-WP
Fullrange
Fullrange
passive speaker
passive speaker
110° x 110°
110°x110°
40 W
-
4", 1" v.c.
5", 1" v.c.
Terminal barrier strip (or speakON® using
the SP-IS accessory panel
Wooden box with metal grille
130x130x150
160x160x180
mm
(5.1x5.1x5.9 in)
(6.3x6.3x7.1 in)
2 Kg (4 lbs.)
2.8 Kg (6 lbs.)
info@dbtechnologies-aeb.com
420120454Q REV1.0
D
IS6T-WP
Coaxial 2-way
passive
speaker
IP55
100°x100°
60 W
100 W
8 Ohm
-
0.75", 1" v.c.
6.5", 1.5" v.c.
195x195x210
mm
mm
(7.7x7.7x8.3 in)
4.8 Kg (10 lbs.)
