AEB DB Technologies IS26T-WP Quick Start User Manual

IS26T-WP
MAIN FEATURES
• Versatile
• Quick installation
• Suitable for indoor and outdoor installations
PACKAGE CONTENTS
The box contains:
N°1 passive speaker
This quick start and warranty documentation
DESCRIPTION
IS26T-WP is a full-range 2-way professional
passive speaker with two 6.5'' woofers and a 1''
compression driver for the high frequencies. Com-
pact, with a high linear response, IS26T-WP offers
maximum sound pressure and condenses the best
of the dBTechnologies acoustic experience and
IP55 protection for indoor and outdoor sound
reinforcement. This speaker uses the concept of
maximum versatility, allowing dozens of diffe-
rent configurations achievable with the available
accessories.
ACCESSORIES
SP-IS HK-15100WG
speakON® panel waveguide kit
SA-2x6
stand adapter
QUICK START USER MANUAL SECTION 1
DRK-1
flybar
LP-2 LP-3
bracket bracket
DIMENSIONS
W
TECHNICAL SPECIFICATIONS
Speaker Type 2-way passive speaker
Protection against solid
IP55
objects and liquids:
60°x90° (rotatable horn)
Coverage (HxV)
100° x 15° (IS26T100-WP)
RMS Power 250 W
Rated impedance 8 Ohm
HF 1" (exit), 1.7"v.c.
LF 2 x 6.5", 1.7"v.c.
Terminal barrier strip (or speakON®
Signal Input/Output
using the SP-IS accessory panel)
Housing Wooden box with metal grille
Rigging points Integrated mechanics
Dimensions (WxHxD) 210x650x270 mm (8.3x25.6x10.6 in)
Weight 15.5 Kg (34 lbs.)
DRK-2
flybar
LP-5
bracket
1 info@dbtechnologies-aeb.com
420120456Q REV1.0
HB-2x6
VB-2x6
bracket bracket
LP-13 LP-16
bracket bracket
