Little Seeds 4764119LS Assembly Manual

Metal house bed
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Metal House Bed
Weight Limit:
Bed: 400 LBS / 181 KG
Upper Rail: 15 LBS / 7 KG
Two adults
recommended
for assembly
Do NOT return this product.
For missing or broken parts
- Visit www.littleseedskids.com
- Write to cs@dhpfurniture.com
- Call 1-800-267-1739
Keep this Assembly Manual for future reference.
Please DO NOT throw away this instruction manual.
NOTE: THIS INSTRUCTION BOOKLET
CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
____________________________
This product is not intended for commercial use
1
Model No:
4764119LS(White)
4764419LS(Dove Gray)
Lot Number:
(TAKEN FROM CARTON)
Date of purchase:
_______ / _______ / _______
MY.H 2024/7/10
B344764119LS00KT
Follow little seeds on:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4764119LS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Little Seeds 4764119LS

Summary of Contents for Little Seeds 4764119LS

  • Page 1 Two adults MY.H 2024/7/10 recommended for assembly B344764119LS00KT This product is not intended for commercial use Do NOT return this product. Follow little seeds on: For missing or broken parts - Visit www.littleseedskids.com - Write to cs@dhpfurniture.com - Call 1-800-267-1739...
  • Page 2 Look inside for Assembly Manual Check us out! Littleseedskids.com...
  • Page 3 Leave a 5 STAR RATING by scanning the QR code! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Little Seeds product, and to give us your valuable feedback. www.littleseedskids.com...

  • Page 4: Do Not Return This Product To The Store

    Do NOT return this product to the store! DHP Consumer Services 1-800-267-1739 Visit: Assembly Tips 12345 Albert-Hudon www.littleseedskids.com Boulevard, Suite 100 Montreal, Quebec Canada H1G 3L1 cs@dhpfurniture.com NOTES Ensure all parts and components are present before beginning assembly. Assembly and handling will require two people. Assemble on a soft, smooth surface to prevent damage to the product finish.

  • Page 5: Part Identification

    All packed in 1 box! Part Identification There are inner box(es) with components required to complete the Not actual size assembly. Before you throw the package, please use the Check Box to identify the parts and ensure that you have all the parts needed for the assembly.
  • Page 6 All packed in 1 box! Part Identification There are inner box(es) with components required to complete the Not actual size assembly. Before you throw the package, please use the Check Box to identify the parts and ensure that you have all the parts needed for the assembly.
  • Page 7 All packed in 1 box! Part Identification There are inner box(es) with components required to complete the Not actual size assembly. Before you throw the package, please use the Check Box to identify the parts and ensure that you have all the parts needed for the assembly.
  • Page 8 Part Number 4764119LS(White) 4764419LS(Dove Gray) Part Label T4764119LS010KT T4764419LS010KT T4764119LS020KT T4764419LS020KT T4764119LS030KT T4764419LS030KT T4764119LS040KT T4764419LS040KT T993660 T993740 T993670 T993750 T993680 T993760 T993640 T993720 T4764119LS050KT T4764419LS050KT T4764119LS060KT T4764419LS060KT T4764119LS070KT T4764419LS070KT T4764119LS080KT T4764419LS080KT IMPORTANT: This part number list is unique to your product. Please keep it on hand when calling for replacement parts.

  • Page 9: Hardware List

    Hardware Pack #: The screw(s), bolt(s) to be used at each step are shown in 4764119LS(White) actual size in the lower right corner of the page. HP#:24764119LS0KT 4764419LS(Dove Gray) Actual size 1/4"...
  • Page 10 Step 1 Attach K1 x 2 and K2 x 2 to V1 with www.littleseedskids.com...
  • Page 11 Step 2 Attach T to A and B with Holes should be oriented on the same side ! The pre-assembled antiskid pad should be facing downward. www.littleseedskids.com...
  • Page 12 Step 3 Attach T to C and D with Holes should be oriented on the same side ! The pre-assembled antiskid pad should be facing downward. www.littleseedskids.com...
  • Page 13 Step 4 2 people required. Place the subassembly (K1,K2&V1) obtained from STEP 1 on top of A/B/C/D ,and insert K1 into A and C , K2 into B and D. Note: Thread holes on A, B, C & D are facing inside of the bed. www.littleseedskids.com...
  • Page 14 Step 5 5.1 Secure K1 to A and C,K2 to B and D with 5.2 Attach K x 2 to A & K1, B & K2, C & K1 and D & K2 with X 12 www.littleseedskids.com...
  • Page 15 Step 6 Attach J to A and D with Bracket should be facing up and inside The pre-assembled antiskid pad should be facing downward. www.littleseedskids.com...
  • Page 16 Step 7 Attach J1 to B/C with The pre-assembled antiskid pad should be facing downward. www.littleseedskids.com...
  • Page 17 This bed offers you 2 options, you can switch when needed, Option 1: Bed with Front Guard Rail. To assemble as per Step 8. Option 2: Bed without Front Guard Rail. To assemble as per Step 9. Option 1 Option 2 www.littleseedskids.com...
  • Page 18 Step 8 Option 1 To assemble with Front Guard Rail: 8.1 Secure J2 to A with 8.2 Secure J2 to J with www.littleseedskids.com...
  • Page 19 Step 9 Option 2 To assemble without Front Guard Rail: Screw into A and J as illustration www.littleseedskids.com...

  • Page 20: Helpful Hints

    Helpful Hints Front Guard Rail J2 is removable, it can be dismantled and assembled upon demand . To remove Front Guard Rail J2: Remove Bolt , Bolt & Spring Washer that are assembled in Step 8, and follow Step 9 to fill the holes with To re-assemble Front Guard Rail J2.
  • Page 21 Clean the product with a soft damp cloth. DO NOT use harsh chemicals or abrasive cleaners. Check bolts and nuts periodically and tighten if necessary. WARNING: For your safety, do not climb or hang on the 4764119LS(Off White): T392640 upper metal rails! 4764419LS(Dove Gray): T394760 4764119LS(Off White): T994230...
  • Page 22 NO tire este manual de instrucciones. L mites de peso: Cama: 400 LBS / 181 KG Riel superior: 15 LBS / 7 KG Modelo No: 4764119LS(Blanco) 4764419LS(Gris perla) NOTA: ESTE MANUAL DE INSTRUCCIONES CONTIENE INFORMACI N DE SEGURIDAD IMPORTANTE. POR FAVOR L ALO Y CONS RVELO PARA REFERENCIA FUTURA.

  • Page 23: Garantia Limitada

    Espa ol iNo regrese este producto a la tienda! Contacte nuestro amigable equipo de servicio al cliente si necesita ayuda. 1-800-267-1739 Visit: Consejos para DHP Consumer Services el ensamblaje www.littleseedskids.com 12345 Albert-Hudon Boulevard, Suite 100 Montreal, Quebec Canada H1G 3L1 cs@dhpfurniture.com NOTA Aseg rese de tener todas las piezas y componentes antes de comenzar a armar el producto.
  • Page 24 Antes de tirar este paquete, por favor utilice la Casilla de Verificaci n para identificar sus partes y garantizar de que cuenta con todas las piezas necesarias para el ensamblaje. N MERO DE PIEZAS ETIQUETAS DE PIEZAS 4764119LS(Blanco) 4764419LS(Gris perla) DESCRIPCION Poste...
  • Page 25 Espa ol Paso 1 Une K1 x 2 y K2 x 2 a V1 con Paso 2 Une T a A y B con Paso 3 Une T a C y D con Paso 4 Se requieren 2 personas Colocar el subconjunto( K1,K2 & V1 ) obtenidos desde el paso 1 en la ranura en la A/B/C/D y K1 dentro A /C y K2 dentro B y D.
  • Page 26 Espa ol PRECAUCI N: Esta unidad est dise ada para ser utilizada nicamente con los productos y/o pesos m ximos indicados. Su uso con otros productos y/o productos m s pesados que los pesos m ximos indicados puede provocar inestabilidad o causar lesiones. Consejos tiles Mueva sus muebles nuevos con cuidado, se requiere de dos personas para levantar y trasladar su producto a su nueva ubicaci n.
  • Page 27 Ce produit n'est pas destin un usage commercial deux personnes. NE PAS RETOURNER CE PRODUIT AU MAGASIN. Suivez Little Seeds sur : Si une pi ce est manquante ou endommag e, contactez notre Service la client le. -Visitez www.littleseedskids.com - crivez cs@dhpfurniture.com...
  • Page 28 Fran ais Contactez notre quipe amicale de service la client le, pour obtenir de l'aide. 1-800-267-1739 Visit: Astuces DHP Consumer Services d'assemblage www.littleseedskids.com 12345 Albert-Hudon Boulevard, Suite 100 Montreal, Quebec Canada H1G 3L1 cs@dhpfurniture.com NOTES * Avant de commencer l'assemblage, assurez-vous d'avoir re u toutes les pi ces. * Deux personnes sont n cessaires pour l'assemblage.
  • Page 29 Avant de jeter l'emballage, s'il vous pla t utiliser les cases cocher pour identifier les pi ces et assurez-vous que vous avez toutes les pi ces n cessaires pour l'assemblage. LISTE DES PI CES 4764119LS(Blanc) 4764419LS(Gris tourterelle) DESCRIPTION TIQUETTE DES PI CES...
  • Page 30 Fran ais tape 1 Attacher K1 x 2 et K2 x 2 V1 avec tape 2 Attacher T A et B avec tape 3 Attacher T C et D avec tape 4 2 personnes requises Place le sous ensemble( K1,K2 & V1 ) obtenus l' tape 1 dans la fente sur A/B/C/D ins rer K1 dans A/C et K2 dans B/D.

  • Page 31: Conseils Utiles

    Fran ais ATTENTION: Cette unit est destin e tre utilis uniquement avec les produits et/ou les poids maximum indiqu s. L'utilisation avec d'autres produits et/ou des produits plus lourds que les poids maximum indiqu s peut entra ner une instabilit ou causer des blessures. Conseils Utiles D placez votre nouveau mobilier avec soin, nous recommandons deux personnes pour soulever et transporter le mobilier vers son nouvel emplacement.
