MODEL
ESP-JV SYSTEM
INSTALLATION,
OPERATION
& MAINTENANCE
MANUAL
Central Air Conditioning Series
2 to 5 Tons
Fan Coil Unit/Air Supply
Components
SECTION 1: INTRODUCTION
SpacePak System Design........................................
Code Compliance.....................................................
Air Distribution Requirements ..................................
Air Distribution Components.....................................
Shipment of Unit.......................................................
SECTION 2: SYSTEM INSTALLATION
Step 1: Locating the Unit..........................................
Step 2: Cutting Return Air Opening..........................
Step 3: Attaching Supply Air Plenum Adaptor..........
Step 4: Setting the Unit.............................................
Step 5: Connecting Refrigerant Lines....................... 8
Step 6: Installing the Condensate Trap & Line.........
Step 7: Wiring the Unit...........................................10-15
Step 8: Installing Air Distribution Components......... 16
IN UNITED STATES: 260 NORTH ELM ST. WESTFIELD, MA 01085 (413) 564-5530/FAX (413) 564-5815
IN CANADA: 7555 TRANMERE DRIVE, MISSISSAUGA, ONTARIO, L5S 1L4 (905) 670-5888/FAX (905) 670-5782
SECTION 3: START UP & OPERATION
2
Sequence of Operation............................................. 20
2
Prior to Start-Up ....................................................... 20
2
System Start-Up & Adjustments............................... 20
3
Charging Cooling Only Systems............................... 24
5
Factors Affecting the Balance of the System............ 24
SECTION 4: MAINTENANCE
6
Before Each Cooling Season.................................... 25
7
If System Fails to Operate........................................ 25
8
Troubleshooting Guide.......................................... 26-29
8
Service/Troubleshooting Form.................................. 31
Parts List................................................................... 32
WARRANTY INFORMATION......................Back Cover
9
®
COPYRIGHT
2017
ESPJV2-0218
W30-WG0890
