- Page 1 ImpulseRadar April 2023 PLT-600 User Manual Headquarters: Skolgatan 22, SE-939 31, Malå Sweden | info@impulseradar.se...
-
Page 2: Table Of Contents
Table of Contents NOTE FOR USERS IN USA AND CANADA ................1 HARDWARE OVERVIEW ....................1 GPR U .............................. 3 SOFTWARE OVERVIEW ..................... 3 & C ..........................3 ETUP ONNECTION Survey Settings ..........................4 Data Acquisition & Export ....................... 5 APPENDIX A –... -
Page 3: Note For Users In Usa And Canada
Operation of this device shall only occur when in contact with or within 1 m of the ground. Hardware Overview The ImpulseRadar PLT-600 is a single-channel GPR system based on a modern real-time sampling (RTS) technology platform, offering state-of-the-art data acquisition capabilities. It is a perfect tool for ice thickness studies. - Page 4 For more information, please contact your local ImpulseRadar representative, or contact our sales team at sales@impulseradar.se Pulling rope. Hook for measuring wheel. GPR System Protective casing Skid plate Figure 1: PLT GPR system along with a pull rope ImpulseRadar PLT User Manual v1.6...
-
Page 5: Gpr Unit
‘ViewPoint’ in the search-bar. It is also available on ImpulseRadar website. Now, start the PLT-600 GPR system and turn the Wi-Fi ‘ON’ on your android device. It might take few minutes for the GPR system’s Wi-Fi to be detected by the android device. -
Page 6: Survey Settings
Use password ‘impulseradar’ to connect with the GPR system. If prompted, allow the android device to connect to this network without internet access. Now open the App. If prompted, allow it to access device location and photos, videos, music, & audios. -
Page 7: Data Acquisition & Export
. Press to delete last marker. In the filter settings menu , several different filter options are available such as background removal, dynamic and manual gains, and contrast settings. ImpulseRadar PLT User Manual v1.6... -
Page 8: Appendix A - Specifications
Appendix A – Specifications ImpulseRadar products are under continuous development, and we reserve the right to change specifications at any time and without prior notice. You may verify product specifications at any time by contacting our headquarters at;... -
Page 9: Appendix B - File Formats
Samsung Galaxy Tab Active Pro, or equivalent Appendix B – File Formats Files Stored in the Project Directory <project name> - current project name (project data directory has the same name) ImpulseRadar File Types & Descriptions File Type Description Naming Convention Explanation... -
Page 10: Files/Information Stored In The System
USER DISTANCE INTERVAL: 0.010000 Distance interval for interface STOP POSITION: 17.024 Stop Position in meters WHEEL NAME: wheel1 Wheel name (max 20 chars) WHEEL CALIBRATION: 306.799877930 Wheel calibration (ticks per meter) ZERO LEVEL: 58 Zero Level ImpulseRadar PLT User Manual v1.6... -
Page 11: Profile Data File (*. Iprb)
Trace <tab> Sample <tab> Marker Standard <tab> RGB colour code <tab> Marker Type <tab> User Comment <tab> Latitude <tab> North/South <tab> Longitude <tab> East/West <tab> Altitude <tab> Altitude Unit <tab> GPS Status <tab> Precision Marker Flag <CRLF> ImpulseRadar PLT User Manual v1.6... -
Page 12: Multi Line Project Header (*. Mlproj)
Multi Line Project Header (*. mlproj) Multi Line - Reference Line Project ML_PROJECT_TYPE: REF_LINE <profiles> 2ch refline nr2_001_0 2ch refline nr2_001_1 2ch refline nr2_002_0 2ch refline nr2_002_1 </profiles> TYPE: 2 SEPARATION: 0.25 ImpulseRadar PLT User Manual v1.6... -
Page 13: Important Note For Us Customers
(d) Users of authorized, coordinated UWB systems may transfer them to other qualified users and to different locations upon coordination of change of ownership or location to the FCC and coordination with existing authorized operations. ImpulseRadar PLT User Manual v1.6... -
Page 14: Important Note For Canadian Customers
Canada. L’exploitation est soumise aux deux conditions suivantes : 1. Cet appareil ne peut pas causer d’interférence. 2. Cet appareil doit accepter toute interférence, y compris les interférences qui peuvent provoquer un fonctionnement indésirable de l’appareil. ImpulseRadar PLT User Manual v1.6... - Page 15 ImpulseRadar PLT User Manual v1.6...
