- Page 1 Product manual E-FDC-DD Fire damper Fire protection Version 1.0.0 Issue Date: 19.12.2023.
-
Page 2: Product Overview
Brass bearings are pressed into the casing. Calcium silicate blade is equipped with the seal made out of EPDM rubber. Fire dampers E-FDC-DD are produced up to size d315 and have 25 mm thick damper blade. - Page 3 FIRE RESISTANCE CLASSIFICATION E - Integrity I - Insulation E-FDC-DD fire resistance is tested according to EN 1366-2 90 - Classification time in minutes “Fire resistance tests for service installations- Part 2: Fire S - Smoke leakage dampers”. Classification of the fire dampers is defined...
-
Page 4: Technical Data
PRODUCT OVERVIEW DIMENSIONS INSTALLATIONS ACTUATORS ACCESSORIES E-FDC-DD-d100-M230-S MAINTENANCE AND OPERATION FIRE DAMPER - E-FDC-DD TECHNICAL DATA Pressure drop tables Product label Product specifications Pressure drop values are described with the “Zeta” values 1 - Casing air leakage classification Nominal sizes E-FDC-DD... - Page 5 INSTALLATIONS ACTUATORS Dimensional range ACCESSORIES Diameter Cross section Net area Model [mm] [dm²] [dm²] Ød MAINTENANCE AND OPERATION 0,74 0,50 E-FDC-DD D100 1,17 0,87 E-FDC-DD D125 1,93 1,55 E-FDC-DD D160 3,05 2,56 E-FDC-DD D200 4,79 4,18 E-FDC-DD D250 7,64 6,87...
- Page 6 PRODUCT OVERVIEW DIMENSIONS MODELS INSTALLATIONS Casings ACTUATORS E-FDC-DD ACCESSORIES Cylindrical fire damper with 25 mm damper blade and fire classification up to EI 90S. Sizes range MAINTENANCE AND OPERATION from d100 till d315. PRODUCT OVERVIEW Actuators Ordering key M24-S-ST (1) Damper type...
-
Page 7: Installation
DIMENSIONS INSTALLATION INSTALLATIONS ACTUATORS The E-FDC-DD fire damper is always tested in standardized support frames (both in a rigid wall ACCESSORIES and in a flexible wall) in accordance with EN 1366-2: 2015. The results obtained are valid for all similar... - Page 8 100 mm thick Installation with ≥ 100 mm 300Pa profile inserts B: Plasterboard type A (EN520), FIRE DAMPER - E-FDC-DD EI 60 (ve i↔o)S mineral wool up to 60 kg/m³ Aerated concrete E-FDC-DD installation ( ≥ 550kg/m³) Remote from floor/ceiling Floor/ Ceiling ≥...
- Page 9 PRODUCT OVERVIEW DIMENSIONS Rigid wall INSTALLATIONS installation ACTUATORS ACCESSORIES The wall is composed of concrete blocks (minimum density of 550 kg/m³) or MAINTENANCE AND OPERATION reinforced concrete (minimum density of 2200 kg/ m³) and with a minimum thickness of 100 mm. Possible damper orientations 0 - 90 - 180 - 270 - 360°...
- Page 10 PRODUCT OVERVIEW DIMENSIONS Gypsum blocks INSTALLATIONS wall installation ACTUATORS ACCESSORIES The wall is composed of gypsum blocks (minimum density of 995 kg/m³), and with minimum MAINTENANCE AND OPERATION thickness of 70 mm. Possible damper orientations 0 - 90 - 180 - 270 - 360° INSTALLATION 1.
- Page 11 Flexible wall installation PRODUCT OVERVIEW The wall is composed of 2x2 plasterboard DIMENSIONS boards, 12,5 mm thick, installed on a steel frame INSTALLATIONS construction. To fulfill the classification it is NOT mandatory to use the mineral wool inside the wall ACTUATORS (mineral wool with density up to 60 kg/m³...
- Page 12 Weise von unten ein, wobei die L-Profile und die Ka- nalstahlklammer um 90° gegenüber den Profilen auf der Oberseite gedreht sein müssen. 5. Die Brandschutzklappe E-FDC-DD wird in den ver- tikalen Lüftungskanal eingesetzt und zusätzlich mit selbstschneidenden Schrauben (8 Stück - DIN 7504 3,5 x 9,5 mm), die gleichmäßig über den Umfang verteilt sind,...
- Page 13 PRODUCT OVERVIEW DIMENSIONS INSTALLATIONS UW50 UW50 rail ACTUATORS ACCESSORIES d+15 (max) MAINTENANCE AND OPERATION CW50 CW50 rail INSTALLATION FIRE DAMPER - E-FDC-DD Installation with S+40 D+15 (max) profiles inserts UW50 rail CW50 UW50 rail rail...
- Page 14 PRODUKTÜBERSICHT ABMESSUNGEN Minimale Installa- INSTALLATION tionsabstände ANTRIEBE KOMMUNIKATIONS MODULE ZUBEHÖR ERSETZUNGEN WARTUNG UND BETRIEB FIRE DAMPER - E-FDC-DD *Mindestabstand von der Decke / Wand oder anderen Brandschutzklappen!
-
Page 15: Technical Specifications
PRODUCT OVERVIEW ELECTRIC DIMENSIONS ACTUATOR INSTALLATIONS E-M24-S, E-M230-S, ACTUATORS E-M24-S-ST ACCESSORIES Damper is delivered in closed position. When MAINTENANCE AND OPERATION electric actuator is connected to the power supply, damper blade will open. When the damper reaches the end position (damper open), the electro motor will stop. - Page 16 PRODUCT OVERVIEW DIMENSIONS ACCESSORIES INSTALLATIONS ACTUATORS Flexible duct connections Flexible duct connec- ACCESSORIES tors are used in HVAC systems for isolation from structure-borne noise, expansion compensation MAINTENANCE AND OPERATION and fire damper connections (total length 150mm, flexible 60mm). Safety grilles Fire damper, safety grille and, if applicable, extension piece are assembled at the factory to form a unit.
- Page 17 Remove any wrapping. • • Provide at least one annual check of the damper Carefully unpack E-FDC-DD fire damper - be careful • Protect fire damper from dust and contamina- • of sharp edges and do not use excessive force for •...
- Page 18 FIRE DAMPER - E-FDC-DD...
