  • Page 1 Product manual E-FDC Fire damper Fire protection Version 2.5.0 Issue Date: 15.05.2024.

  • Page 2: Product Overview

    E-FDC40 昀椀re dampers are equipped with with end switches for position signalling. E-R40 manual mechanism. Fire dampers E-E-E-E-FDC are used for prevention of 昀椀re ATEX rated versions of 昀椀re dampers can be delivered with Manual spring return mechanism is equipped with thermal...

  • Page 3: Tests And Certificates

    FIRE RESISTANCE CERTIFICATES CLASSIFICATION E-FDC 昀椀re resistance is tested according to EN 1366-2 “Fire All our dampers are submitted to a number of tests by o昀케- resistance tests for service installations- Part 2: Fire damp- Please consult latest Declaration of Performance: cial test institutes.

  • Page 4: Technical Data

    Fire damper for areas with potentially explosive PRODUCT MUST BE INSTALLED BY INSTRUCTIONS SUPPLIED BY THE MANUFACTURER atmospheres are also available 28502800400001 PRODUCT OVERVIEW FIRE DAMPER - E-FDC Product speci昀椀cations Dimensional range Product label Pressure drop tables 1 - Casing air leakage classi昀椀cation Pressure drop values are described with the “Zeta”...
  • Page 5 E-FDC40 - MF2 Fire damper with integrated MF2 installation frame with 40 mm damper blade and 昀椀re classi昀椀cation up to EI90S. Sizes range from d355 till d800. PRODUCT OVERVIEW FIRE DAMPER - E-FDC Ordering key Actuators R (R-S) E-M24-S Manual operating mechanism, optionally with end switches (R-S). In...
  • Page 6 15,4 17,5 20,4 23,6 27,7 33,7 Weight [kg] K [mm] *K - Dimension of the minimum installation opening DIMENSIONS FIRE DAMPER - E-FDC Product [mm] [mm] [mm] [mm] [mm] E-FDC 25 E-FDC 40 E-FDC25-E-R25 (up to d315) E-FDC40-E-R40 (d355 up to d800) ...
  • Page 7 E-FDC25-EMS E-FDC40-EMS Ød [mm] 12,2 13,8 15,7 17,8 20,7 23,9 Weight [kg] K [mm] *K - Dimension of the minimum installation opening FIRE DAMPER - E-FDC Product [mm] [mm] [mm] [mm] [mm] E-FDC 25 E-FDC 40   d/2+22 d/2+12...
  • Page 8 35,1 35,1 Tip pogona Actuator type K [mm] K [mm] *K - Dimension of the minimum installation opening *K - afmeting van de minimale installatieopening DIMENSIONS FIRE DAMPER - E-FDC Product [mm] [mm] [mm] [mm] BFL (M)   BFN (M)
  • Page 9 Weight [kg] Actuator type ATEX rated SCHISCHEK 24/230 V electric actuator+E-ExPro-TT+E-ExBox-BF K [mm] *K - Dimension of the minimum installation opening DIMENSIONS FIRE DAMPER - E-FDC Model [mm] E-FDC 25 E-FDC 40 Ex classi昀椀cation of product: Length of damper blade outside of casing...
  • Page 10 Factory assembled to the 昀椀re damper E-FDC25-APP-R E-FDC25-APP-EMS E-FDC25-APP-M Ød [mm] Weight [kg] 10,1 12,3 11,6 13,8 10,8 DIMENSIONS FIRE DAMPER - E-FDC Damper diameter Applique frame diameter Ød[mm] Ød + A [mm] Product [mm] Ød +105 mm E-FDC 25 125 - 160 Ød + 95 mm...
  • Page 11 Factory assembled to the 昀椀re damper E-FDC25-MF1-R E-FDC25-MF1-EMS E-FDC25-MF1-M Ød [mm] Weight [kg] 10,3 12,5 15,5 10,2 11,8 13,2 16,2 DIMENSIONS FIRE DAMPER - E-FDC Product [mm] E-FDC 25 E-FDC25-MF1-R E-FDC25-MF1-EMS E-FDC25-MF1-M E-FDC 40  62 82 d + 118   d + 118...
  • Page 12 E-FDC25-MF2-M Ød [mm] Weight [kg] 11,4 13,8 17,2 11,1 12,9 15,3 18,7 10,3 12,1 14,5 17,9 DIMENSIONS FIRE DAMPER - E-FDC Product [mm] E-FDC 25 E-FDC25-MF2-R E-FDC25-MF2-EMS E-FDC25-MF2-M E-FDC 40 65 103,5 65 103,5  d+118   65 103,5...
  • Page 13 E-FDC40-MF2-M Ød [mm] 22,8 25,9 29,6 33,6 39,1 62,8 23,1 26,2 29,9 33,9 39,5 45,3 63,1 22,6 25,7 29,4 33,4 44,8 64,2 Weight [kg] DIMENSIONS FIRE DAMPER - E-FDC E-FDC40-MF2-M Product E-FDC40-MF2-R / E-FDC40-MF2-EMS [mm]   d + 120...

  • Page 14: Installation

    MAINTENANCE AND OPERATION INSTALLATION FIRE DAMPER - E-FDC The duct connected to the 昀椀re damper must be supported The 昀椀re damper must be installed into a 昀椀re partition To help you 昀椀nd the suspension plane, a bendable 昀椀xing The gap in the installation opening between the 昀椀re...
  • Page 15 PRODUCT OVERVIEW DIMENSIONS Standard actuator E-FDC25 ELECTRIC E-FDC-E-R25 MANUAL INSTALLATIONS ACTUATOR ACTUATOR positions ACTUATORS ACCESSORIES REPLACEMENTS MAINTENANCE AND OPERATION E-FDC40 ELECTRIC E-FDC-E-R40/EMS MANUAL ACTUATOR ACTUATOR E-FDC-E-R40/EMS ACTUATOR E-FDC EX ACTUATOR (Ød < 316)
  • Page 16 Fire Batt/ Weichschott EI 90 (ve i↔o)S 300Pa (480 kg/m thick E-FDC25:EI 60 ( i↔o)S Mineral wool FIRE DAMPER - E-FDC Eurobond Firemaster Extra 300Pa (≥ 23 kg/m E-FDC40:EI 60 ( i↔o)S E-FDC25:EI 120 (ve Gypsum plaster, mortar sealing or mortar i↔o)S...
  • Page 17 Aerated concrete ( ≥ 550 kg/m3) or reinforced concrete (≥ 2200 kg/m³) ceiling / 昀氀oor, more than 100 mm thick Plasterboard Flexible wall type F (EN520) FIRE DAMPER - E-FDC REMOTE FROM WALL ≥ 100 mm EI 60 (ve i↔o)S 300Pa (Isover) Aerated concrete ( ≥...
  • Page 18 Possible damper orientations 0-360 ° INSTALLATION FIRE DAMPER - E-FDC 1. Create an opening in the wall (minimal dimensions on pg.14). Bend the 昀椀xing bracket (A) 90°. Place the damper in the opening up to the wall limit mark (B) on the damper.
  • Page 19 (minimum density of 100 kg/m³) covered with plasterboard cover boards (D). Possible damper orientations 0-360° INSTALLATION FIRE DAMPER - E-FDC E-FD-A-CSP-BxH For more details see 1. Create an opening in the wall pg.45 (Ød + 80 mm) x (Ød + 80 mm).
  • Page 20 (D). Possible damper orientations 0-360° INSTALLATION FIRE DAMPER - E-FDC 1. Create an opening in the wall (Ød + 80...300 mm) x (Ød + 80...300 mm). Bend the 昀椀xing bracket (A) 90°. Place the damper in the opening up to the wall limit mark (B) on the damper.
  • Page 21 (C) covered with plasterboard cover boards (D). Possible damper orientations 0-360° INSTALLATION FIRE DAMPER - E-FDC E-FD-A-CSP-BxH 1. Create an opening in the wall For more details see (minimal dimensions on pg.14). Cover the hole with pg.45 GKF gypsum boards (D) (12,5 mm thick) on the one side, 昀椀x them with self-tapping screws Ø3,5x45...
  • Page 22 (mineral wool (E) with density up to 60 kg/m³ can be used). 0-90°-180°-360° INSTALLATION FIRE DAMPER - E-FDC E-FD-A-CSP-BxH 1. Create an opening in the wall For more details see (Ød + 80 mm) x (Ød + 80 mm) and build the pg.45...
  • Page 23 (mineral wool (E) with density up to 40 kg/m³ can be used). 0-90°-180°-360° INSTALLATION FIRE DAMPER - E-FDC E-FD-A-CSP-BxH 1. Create an opening in the wall For more details see (Ød + 80 mm) x (Ød + 80 mm) and build the pg.45...
  • Page 24 (D). minimum thickness of the wall is 100 mm. INSTALLATION FIRE DAMPER - E-FDC 1. Create an opening in the wall (Ød + 80...300 mm) x (Ød + 80...300 mm) and build the subframe according to the drawing, see page 39.
  • Page 25 140 kg/m3, 昀椀re protection coating. Possible damper orientations 0-90°-180°-360° INSTALLATION FIRE DAMPER - E-FDC 1. Create an opening in the wall (Ød + 80...300 mm) x (Ød + 80...300 mm) Bend the 昀椀xing bracket (A) 90°. 2. Place the damper in the opening up to the wall limit mark (B) on the damper.
  • Page 26 100 mm thicknes, installed in a steel frame ACCESSORIES construction. REPLACEMENTS E-FDC 25 EI 60 (i o)S E-FDC 40 EI 60 (i o)S MAINTENANCE AND OPERATION Sealing between dampers and wall is 2 layers of Rockwool Firepro 50 mm tick sealed with intumescent 昀椀re resistant sealant.
  • Page 27 40 mm. Possible damper orientations 90-180-270° INSTALLATION FIRE DAMPER - E-FDC 1. Create an opening in the wall Ød + 80 mm, 30mm below the ceiling. 2. Insert the 昀椀re damper into the opening and 昀椀x the mounting bracker with salf taping screw (3,5 x 35 mm) 3.
  • Page 28 Technical drawing Possible damper orientations 90-180-270° INSTALLATION FIRE DAMPER - E-FDC 1.Prepare subconstruction and cladding of the wall with gypsum boards acc. to technical drawing. Take care that cladding of the wall is not connected to pro昀椀le connected to the ceiling so it could pcompensate movement of the ceiling without impact to the wall."...
  • Page 29 Installation material is gypsum plaster or mortar (C). Possible damper orientations 0-360° INSTALLATION FIRE DAMPER - E-FDC 1. Create an opening in the 昀氀oor/ ceiling (minimal dimensions on pg.14) and bend the 昀椀xing bracket (A) 90°. Place the damper in the opening up to the wall limit mark (B) on the damper.
  • Page 30 Possible damper orientations 0-360° INSTALLATION FIRE DAMPER - E-FDC 1. Create an opening in the 昀氀oor/ceiling (Ød + 80...300 mm) x (Ød + 80...300 *Fire Batt 昀氀oor/ceiling installations require a suspension for the 昀椀re damper. For more details, see page 27 rigid 昀氀oor / page 28 ceiling.
  • Page 31 27 mm Possible damper orientations 0-360° INSTALLATION FIRE DAMPER - E-FDC 1. Suspension strut should be connected with drop rods (8/10 mm) to the 昀氀oor slab above. It is used to support the damper and ease the installation. 2. When using L pro昀椀le 昀椀xation, support steel C d+300) pro昀椀le with 50 mm high peace of aerated concrete...
  • Page 32 27 mm Possible damper orientations 0-360° INSTALLATION FIRE DAMPER - E-FDC 1. Suspension strut should be connected with drop rods (8/10 mm) to the ceiling slab above. It is used to support the damper and ease the installation. 2. If using L pro昀椀le 昀椀xation, support steel C pro昀椀le...
  • Page 33 100 mm. Possible damper orientations 0-360° INSTALLATION FIRE DAMPER - E-FDC 1. Create a wall opening according to the dimensions in the table below. 2. Insert 昀椀re damper into wall and fasten with screws (8 pcs, 4,8x60 mm).
  • Page 34 70 mm. Possible damper orientations 0-360° INSTALLATION FIRE DAMPER - E-FDC 1. Create a wall opening according to the dimensions in the table below. 2. Insert 昀椀re damper into wall and fasten with screws (8 pcs, 4,8x60 mm).
  • Page 35 100 Possible damper orientations 0-360° INSTALLATION FIRE DAMPER - E-FDC *Create an opening according to the table below and build the subframe according to the drawing, see page 39. 1. Place the 昀椀re damper in the opening.
  • Page 36 100 mm. Possible damper orientations 0-360° INSTALLATION FIRE DAMPER - E-FDC 1. Create an opening in the wall (E-FDC25- Ød +10 mm, E-FDC40-Ød + 25 mm). 2. Place the damper in the opening.
  • Page 37 70 mm. Possible damper orientations 0-360° INSTALLATION FIRE DAMPER - E-FDC 1. Create an opening in the wall (E-FDC25- Ød +10 mm, E-FDC40-Ød + 25 mm). 2. Place the damper in the opening. Damper blade must be closed during installation! 3.
  • Page 38 The minimum thickness of the Possible damper orientations wall is 100 mm. 0-360° INSTALLATION FIRE DAMPER - E-FDC 1. Create an opening in the wall (E-FDC25- Ød +10 mm, E-FDC40-Ød + 25 mm) and build the subframe according to the drawing, see page 39.
  • Page 39 100 mm. Possible damper orientations 0-360° INSTALLATION FIRE DAMPER - E-FDC 1. Create an opening in the 昀氀oor/ceiling (E-FDC25- Ød +10 mm, E-FDC40-Ød + 25 mm). Insert the 昀椀re damper into the opening and mark the places for drilling holes.
  • Page 40 20 mm thick, installed on a steel frame construction. Possible damper orientations INSTALLATION FIRE DAMPER - E-FDC E-FDC-MF2 Fire damper (Ød < 625 mm) E-FDC-MF2 Fire damper (Ød > 625 mm) E-FDC-MF2 Fire damper installation in 90 mm installation in 90 mm shaft wall with metal studs...
  • Page 41 (minimum density of 550 kg/m³) or REPLACEMENTS reinforced concrete (minimum density of MAINTENANCE AND OPERATION 2200 kg/m³) and with a minimum thickness of 100 mm. Technical drawing E-FDC 25 Possible damper orientations ° 0-360 INSTALLATION FIRE DAMPER - E-FDC 1.
  • Page 42 Rigid wall: The wall is composed of concrete blocks (minimum density of 550 kg/m³) or MAINTENANCE AND OPERATION reinforced concrete (minimum density of 2200 kg/m³) and with a minimum thickness of 100 mm. Technical drawing E-FDC 40 Possible damper orientations ° 0-360 INSTALLATION FIRE DAMPER - E-FDC Test the operation of the damper blade! 1.
  • Page 43 Ød/2 PRODUCT OVERVIEW Minimal installation DIMENSIONS distances INSTALLATIONS ACTUATORS Material in width of supporting constructions compliant with the classi昀椀cation from DOP ACCESSORIES *Coated mineral wool 240 mm wide (140 kg/m³) only in case of weichschott/昀椀rebatt REPLACEMENTS Damper blade must be closed during installation! MAINTENANCE AND OPERATION Weichschott/Firebatt - Mineral wool 1*.
  • Page 44 Flexible wallsubframe When installing the 昀椀re dampers in the 昀氀exible walls it is necessary to make a metal subframe onto which the damp- PRODUCT OVERVIEW er will be 昀椀xed with screws. Subframe should be prepared according to the drawings below. DIMENSIONS INSTALLATIONS ACTUATORS...

  • Page 45: Wiring Diagram

    Thermal fuse melting point is 72 °C. E-R40 E-R25 (d355 up to d800) (up to d315) ACTUATORS FIRE DAMPER - E-FDC Technical speci昀椀cations Wiring diagram E-R25 E-R25 manual actuator is installed on E-FDC25 昀椀re Nominal voltage dampers up to size d315. It is available in ver- sion with (R-S) and without (R) end switches.
  • Page 46 Thermal fuse melting point is 72 °C. E-EMS-S mechanism is the same for E-FD- C25/E-FDC40 昀椀re dampers. ACTUATORS FIRE DAMPER - E-FDC Technical speci昀椀cations Wiring diagram Nominal voltage Solenoid: 24/ 48 VDC...

  • Page 47: Electric Actuator

    °C (optional 95 °C). If checking is needed for prop- er functioning of 昀椀re damper, pushing the switch on the thermal tripping device will close damper. ACTUATORS FIRE DAMPER - E-FDC Technical speci昀椀cations Wiring diagram When switch on tripping device is released, the damper will open.
  • Page 48 When switch on tripping device is re- leased, the damper will open. ACTUATORS FIRE DAMPER - E-FDC Wiring diagram Technical speci昀椀cations Damper can be opened without connecting to a voltage with enclosed Allen key, by turning in the...
  • Page 49 G Belimo thermal fuse 95 °C E-FD-A-BAT95 H Thermal fuse blanking plate E-FD-BP-KIT I Kit A E-FDC-A-KIT-A Upgrade to electric actuator (Belimo BFL) J Kit B E-FDC-A-KIT-B Upgrade to electric actuator (Belimo BFN) K Kit C E-FD-A-KIT-C- upgrade to electric actuator (Belimo BF) L E-R40 manual mechanism E-FD-A-E-R40 see page 40.
  • Page 50 E-FDC-A - d100 - 24 of the connecting duct, should be after the sensor. E-FDC-A - Accessories for round fire damper d100...d800 nominal diameter of the round fire damper SSA - Smoke sensor assembly 24 - Smoke sensor 24 V...
  • Page 51 SMOKE SENSOR CASING ROTATION PRODUCT OVERVIEW Smoke sensor casing can be rotated (90°-180°-270°) in order to pro- DIMENSIONS vide better 昀氀exibility for wiring. To rotate smoke sensor casing, follow the below instructions. INSTALLATIONS 1. Follow 昀椀rst step of smoke sensor rotation: locate and re ACTUATORS move hex screws.
  • Page 52 PRODUCT OVERVIEW DIMENSIONS INSTALLATIONS ACTUATORS ACCESSORIES REPLACEMENTS MAINTENANCE AND OPERATION REPLACEMENTS FIRE DAMPER - E-FDC UPGRADE TO END CONTACTS (E-R40 E-R40-S) 1. Locate hex screw, unscrew it and remove the cover. 2. Insert CEE (E-R25)/CEDC (E-R40) board in the appropriate place.
  • Page 53 MAINTENANCE AND OPERATION Service work may only be performed by authorized persons! REPLACEMENTS FIRE DAMPER - E-FDC 1. Locate hex screw. Unscrew it and remove the cover. 2. Insert the EMS on the custom plate. 3. Screw the EMS to the plate and connect the 2-pin connector into the appropriate socket on the CEDC board.
  • Page 54 (E-R25) ACCESSORIES REPLACEMENTS MAINTENANCE AND OPERATION REPLACEMENTS FIRE DAMPER - E-FDC 1. Locate the hex screw on the cover, unscrew it and remove the screw and cover. 2. Locate the hex screw on the thermal fuse and unscrew it. 3. Remove the old thermal fuse. Insert the new thermal fuse and secure it.
  • Page 55 ACCESSORIES REPLACEMENTS MAINTENANCE AND OPERATION REPLACEMENTS FIRE DAMPER - E-FDC 1. Find the hex screw located on the cover, unscrew and remove the screw and the cover. 2. Remove the position indicator sleeve. 3. Locate the 3 hex screws. Unscrew them.
  • Page 56 Belimo BFN E-FD-A-KTC Belimo BF REPLACEMENTS FIRE DAMPER - E-FDC Indicator cut on BE transition plate NOTE: Use kit according to table (upgrade to NOTE: Install the thermal fuse in a place where it will not interfere with the operation of...
  • Page 57 Belimo BFN E-FD-A-KTC Belimo BF REPLACEMENTS FIRE DAMPER - E-FDC Indicator cut on BE transition plate NOTE: Use kit according to table (upgrade to NOTE: Install the thermal fuse in a place where it will not interfere with the operation of...
  • Page 58 The blade must be closed before replacement the mechanism. REPLACEMENTS FIRE DAMPER - E-FDC 1. Locate the 2 hex screws, unscrew and re- move them. 2. Remove the Belimo electric actuator. 3. Find the 2 hex screws located on the tran- sition board (B), unscrew them and rotate BE transition plate (A) 90°.

  • Page 59: Maintenance And Operation

    Provide at least one annual check of the damper closed by pressing the button Protect 昀椀re damper from dust and contamina- • Carefully unpack E-FDC 昀椀re damper - be careful After each intervention, provide a systematic cleaning of tion. dust and especially the solenoid and its movable plate Do not expose the 昀椀re damper to the e昀昀ects of...
  • Page 60 FIRE DAMPER TESTING MANUAL ACTUATORS/ SOLENOID ACTUATOR PRODUCT OVERVIEW DIMENSIONS INSTALLATIONS 1. Close the damper blade by pushing the ther- ACTUATORS mic actuator through the hole on the casing. ACCESSORIES REPLACEMENTS MAINTENANCE AND OPERATION 2. Open the damper blade by inserting the metal rod (i.e.
  • Page 61 FIRE DAMPER - E-FDC...
