MAINTENANCE
IMPORTANT: Unplug the vacuum before performing any maintenance.
EMPTYING THE DUST CUP
Empty the dust cup each time you vacuum and periodically during cleaning, when debris in the dust cup
reaches the MAX fill line.
Press the Wand Release button and lift off To remove the dust cup from the handheld
the handheld vacuum. vacuum, press the two
buttons at the same time and slide out
the dust cup.
Hold the dust cup over the trash. Press the To reinstall, push the lid closed, then insert
Empty button and pull open the dust cup lid the front end of the dust cup into the
until it clicks and locks in the open position. handheld vacuum first, then the back end,
Gently tap the cone-shaped screen inside the until it clicks into place.
dust cup to knock dust and debris into the trash.
CLEANING FILTERS
Regularly rinse and replace the filters to maintain your vacuum's suction power.
To prevent damage from cleaning chemicals, rinse filters with cold water only. Do not use soap. Allow all filters to
air-dry for at least 24 hours before reinstalling them to prevent liquid from being drawn into electronic parts.
With the dust cup detached, press the Filter To access the post-motor filter, press the
Access buttons on both sides of the back of release latch on the filter cover on the
the dust cup, then pull out the filter housing. hand held vacuum. Remove the cover and
Pull the foam filter out of the housing, then lift out the filter.
lift out the felt filter by the pull tab.
The Post-Motor Filter
The should be washed once every 9 months.
Pre-Motor Filters
once a month.
Note: The Quick Guide shows the select accessories that are included with your model.
Accessory type and quantity may vary depending on the model.
The image shown here is for illustrative purposes only and may be subject to change.
Illustrations may differ from actual product. We are constantly striving to improve our products; therefore
the specifications contained herein are subject to change without notice.
NOTE: For proper operation, please ensure that all parts are firmly pressed until CLICKED
1) Remove the handheld vacuum from the wand and check all dust cup intake openings
for debris or blockages.
2)
Detach the wand and check it for blockages.
3)
Detach the wand, then tilt the floor nozzle
blockages.
Dust Cup Release
SELF-CLEANING BRUSHROLL
over
If you run a hard or sharp object or notice a noise change while vacuuming, check for
blockages or objects caught in the brushroll.
If some fibers remain wrapped around the brush roll after continued use, clear them from the
brush roll.
DEBRIS WRAPPED
AROUND BRUSHROLL
Clean off any debris on the brushroll.
C
To minimize the risk of power cord damage,
If this occurs, immediately shut off power to the vacuum and remove the cord from the
brushroll or nozzle.
NOTE: For best performance, keep the Soft Roller clean with regular maintenance.
Power cord caught in brushroll or floor nozzle.
• To minimize the risk of power cord damage, DO NOT run the vacuum over the power cord. If this
occurs, immediately shut off power to the vacuum and remove the cord from the brushroll or nozzle.
should be washed
• Inspect power cord and plug for any damage before use. DO NOT use vacuum cleaner with a
damaged cord or plug. Turn off all controls before plugging in or unplugging the vacuum cleaner.
Store your vacuum cleaner with the power cord secured around the two cord hooks.
Vacuum is not picking up debris. No suction or light suction.
See Maintenance section for more information.
• Empty the dust cup. Check filters to see if they need cleaning. Follow instructions for rinsing and
completely air-drying the filters before reinstalling them.
• Clear any blockages in the nozzle, wand, handheld vacuum, or accessories. See Checking for Blockages
section for more information.
• If any string, hair, or carpet fibers remain wrapped around the brushroll after continued use, carefully
clear them away.
• Remove any blockages from the debris intake in the floor nozzle. Pinch the tabs on the bottom of the
nozzle to open the cover, and lift up the intake tube. Clear blockages, then push the tube down and
press the nozzle cover closed.
in place.
CHECKING FOR BLOCKAGES
Debris Intake back and check openings for
NOZZLE MAINTENANCE
DEBRIS BEHIND BRUSHROLL
Check the Debris intake and clear away any dirt
cover,
or blockages. To close the push down
until it clicks into place.
7
CORD MAINTENANCE
1. DO NOT pull or carry vacuum cleaner by
the cord or use cord as a handle.
2. DO NOT unplug by pulling on the cord.
Grasp the plug. not the cord.
3. DO NOT close the door on the cord.
4. DO NOT pull the cord around sharp
corners.
leave the cord near heated
S. DO NOT
surfaces.
run the vacuum over the power cord.
DO NOT
TROUBLESH O O T ING
Vacuum lifts area rugs.
• Suction is powerful. Take care when vacuuming area rugs or rugs with delicately sewn edges.
• Turn off the unit to disengage the brushroll. To restart, press the power button on the handle.
NOTE: Clean area rugs in Bare Floor mode or with accessories. See Available Accessories section.
Vacuum turns off on its own or the indicator light flashes red.
If your vacuum overheats, the thermostat will automatically turn off the motor. Perform the following steps
to restart:
1. Turn off the vacuum and unplug it.
2. Empty the dust cup and clean the filters. See Emptying the Dust Cup and Cleaning Filters sections.
3. Check for blockages in the wand, floor nozzle, handheld vacuum, inlet openings, and accessories.
4. Reassemble the entire vacuum and ensure all parts click into place.
5. Allow unit to cool for a minimum of 60 minutes.
6. Plug in vacuum and turn it on.
Handheld vacuum is warm.
Due to the strong suction power of the vacuum, it is normal for the area around the filter exhaust to
become warm during and after use. Turn off the vacuum and wait 10 minutes for it to cool down. If it
still feels warm, clean the pre-motor and post-motor filters. See Maintenance section for filter cleaning
instructions.
PLEASE READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.
This Owner's Guide is designed to help you get a complete understanding of your new Shark
Ultralight PowerFins ™ Corded Stick Vacuum with Self-Cleaning Brushroll.
SharkNinja Operating LLC
Illustrations may differ from actual product. We are constantly striving to improve our products;
therefore the specifications contained herein are subject to change without notice.
For SharkNinja U.S. Patent information, visit sharkninja.com/uspatents
© 2021 SharkNinja Operating LLC. SHARK is a registered trademark of SharkNinja Operating LLC.
POWERFINS is a trademark of SharkNinja Operating LLC.
TECHNICAL SPECIFICATIONS
120V-, 60Hz
Voltage:
