- Page 1 WELDING LEAD KIT MODEL NO: WGK9 PART NO: 8130356 USER INSTRUCTIONS ORIGINAL INSTRUCTIONS GC 10/24 - rev 1...
-
Page 2: Specification
Thank you for purchasing this CLARKE product. This Lead Kit is a standard welding accessory kit for stick and MMA welding. The kit is suitable for use with Clarke WH215 Welder Generator and all other welders with a 9mm dinse connector which are rated current up to 200A. -
Page 3: Safety Warnings
SAFETY WARNINGS WARNING: ELECTRIC SHOCK CAN KILL. DO NOT TOUCH LIVE ELECTRICAL PARTS WITH BARE HANDS AND DO NOT USE WET OR DAMP GLOVES OR CLOTHING. USE THIS CLAMP ONLY FOR ELECTRICAL WELDS AND FOR RETURN CURRENT OF THE WELDING CIRCUIT. 1. - Page 4 3. Tighten the grip until the electrode is secure. 4. Follow the instructions for the welding machine that you will be using, typically the CLARKE WH215. 5. Connect the welding lead to the appropriate DIN socket on the welder. • 135 Amp - LOW range •...
-
Page 5: Maintenance
WELDING TECHNIQUE 1. With the welder correctly connected to the mains supply and the leads attached to the machine, ensure the earth clamp is firmly attached to the workpiece on CLEAN, SOLID metal and as close to the proposed weld as is practical, and the appropriate current setting for the job has been set. - Page 6 DECLARATION OF CONFORMITY - UK Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 7: Declaration Of Conformity (Ce)
DECLARATION OF CONFORMITY - CE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
