- Page 1 ARC ACTIVATED HEADSHIELD Model Nos: CWH6, CWH7 & CWH8 Part Nos: 6000671, 6000672 & 6000688 ASSEMBLY & OPERATING INSTRUCTIONS GC03/14...
-
Page 2: Environmental Protection
INTRODUCTION Thank you for purchasing this CLARKE Headshield. Please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, & you can look forward to the product giving you long &... -
Page 3: General Safety Warnings
GENERAL SAFETY WARNINGS • The protective plate in this headshield is breakable and will not protect against impact hazards. • This Headshield is designed for use in arc welding or cutting applications such as MIG/MAG, TIG, MMA, Plasma Arc, and Carbon Arc. •... -
Page 4: Battery Installation
2. The top headband can be adjusted by bending the strap and positioning the peg in the appropriate hole. 3. When the thumbscrews (3) are tight, the angle of tilt can be quickly and repeatably adjusted using the adjusting tab (9), by placing it on the chosen peg on the headband. -
Page 5: Care And Maintenance
Shade numbers according to BS 679, DIN 4647-1 and EN 169 WARNING: DO NOT USE FOR WELDING OUTSIDE THE RANGE OF DIN 9- 13. INJURY TO THE EYES & LOSS OF EYESIGHT MAY BE CAUSED. CARE AND MAINTENANCE GENERAL Damaged components must be replaced immediately to avoid risk of eye and face injuries. -
Page 6: Component Parts
COMPONENT PARTS r t r Parts & Service: 020 8988 7400/E-mail:Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 7: Declaration Of Conformity
Product Description: Arc Activated Welding Head Shields Model number(s): CWH6, CWH7, CW8 Serial / batch Number: Date of Issue: 30/12/2012 Signed: ..........J.A. Clarke Director CWH6/7/8 Welding Mask rv4 Page 1 of 1 Parts & Service: 020 8988 7400/E-mail:Parts@clarkeinternational.com or Service@clarkeinternational.com...
