- Page 1 FocalPoint™ System Utilities User’s Guide — ONYXWorks™ NFN Gateway-2 (Embedded) Installation & Operation Manual Document 52656 05/19/06 Rev: P/N: 52656:A ECN: 06-024...
-
Page 2: Fire Alarm System Limitations
Fire Alarm System Limitations While a fire alarm system may lower insurance rates, it is not a substitute for fire insurance! An automatic fire alarm system—typically made up of smoke detec- bedrooms), smoking in bed, and violent explosions (caused by escap- tors, heat detectors, manual pull stations, audible warning devices, ing gas, improper storage of flammable materials, etc.). -
Page 3: Installation Precautions
Acclimate Plus™, HARSH™, NOTI•FIRE•NET™, VeriFire™, NION™, NOTIFER Intergrated Systems™ and ONYXWorks™ are trademarks, and ONYX®, FlashScan®, UniNet®, VIEW®, NOTIFIER® are registered trademarks of Honeywell. Simplex® is registered trademark of Tyco International Ltd. Echelon® is a registered trademark and LonWorks™ is a trademark of Echelon Corporation. ARCNET® is a registered trademark of Datapoint Corporation. Microsoft® and Windows® are registered trademarks of the Microsoft Corporation. -
Page 4: Documentation Feedback
• Your comment Send email messages to: FireSystems.TechPubs@honeywell.com Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical Services. ONYXWorks™ NFN Gateway-2 Installation & Operation Manual - P/N: 52656:Rev: A 05/19/06... -
Page 5: Table Of Contents
Table of Contents Section 1 NFN Gateway-2 Overview..................7 1.1: Product Description ............................7 Table 1.1 NFN Compatibility Table.......................7 1.2: NFN Gateway-2 System Architecture ......................8 Figure 1.1 Basic NFN Gateway-2 Network ...................8 Figure 1.2 Advanced NFN Gateway-2 Network..................9 1.3: UL/NFPA Compliance..........................10 Section 2 NFN Gateway-2 Hardware Installation .............. - Page 6 Table of Contents 4.9: Resetting the Gateway Hardware.........................31 Figure 4.8 Reset Gateway Hardware ....................31 Section 5 ONYXWorks Workstation Operation ..............33 5.1: NFN Gateway-2 Event Handling.........................33 5.2: NFN Gateway-2 Commands for NOTI-FIRE-NET Devices...............33 Figure 5.1 Panel Right Click Menu ......................34 Figure 5.2 Detector Right Click Menu ....................34 Figure 5.3 Module Right Click Menu ....................35 Figure 5.4 Zone Right Click Menu.......................35...
-
Page 7: Section 1 Nfn Gateway-2 Overview
Section 1 NFN Gateway-2 Overview 1.1 Product Description This gateway: • Translates NOTI-FIRE-NET panel and device data into data that can be interpreted by a ONYXWorks™ Workstation. • Is the bridge between a ONYXWorks™ Workstation and a NOTI-FIRE-NET network. • Monitors NOTI-FIRE-NET networks over an IP network. -
Page 8: Nfn Gateway-2 System Architecture
NFN Gateway-2 Overview NFN Gateway-2 System Architecture 1.2 NFN Gateway-2 System Architecture The NFN Gateway-2 assembly connects to NOTI-FIRE-NET through NUP via the NCM-W/F; the NFN Gateway-2 connects to ONYXWorks™ via Ethernet. The NFN Gateway-2 bridges an ONYXWorks™ and NOTI-FIRE-NET system together, and it can use a Workstation as the primary reporting station of NOTI-FIRE-NET network. - Page 9 NFN Gateway-2 System Architecture NFN Gateway-2 Overview NFN Gateway NFN Gateway Embedded Version Embedded Version Figure 1.2 Advanced NFN Gateway-2 Network Ethernet Network Installation Overview ONYXWorks™ is a Proprietary Supervising Station that has a supervised client server architecture that communicates over IP networks. The Ethernet network can be a shared bandwidth system that operates over topologies such as an intranet, the Internet or a frame relay system.
-
Page 10: Ul/Nfpa Compliance
NFN Gateway-2 Overview UL/NFPA Compliance 1.3 UL/NFPA Compliance This gateway is intended to be installed in accordance with the Local Authority Having Jurisdiction (LAHJ) and has been investigated to, and found to be in compliance with the following: Underwriters Laboratories U.S. Documents •... -
Page 11: Section 2 Nfn Gateway-2 Hardware Installation
Section 2 NFN Gateway-2 Hardware Installation 2.1 Required Equipment To use a NFN Gateway-2 the following equipment is required: • "NFN Gateway-2 Components". • A UL listed, battery backed, +24VDC power supply. • RJ45 to RJ45 standard Ethernet network cable - Network connection to PNET-1 surge suppressor (supplied by customer). -
Page 12: 1: Nfn Gateway-2 Motherboard Layout
NFN Gateway-2 Hardware Installation Installation Overview 2.2.1 NFN Gateway-2 Motherboard Layout The PC board layout is shown in figure below. Descriptions of pertinent connections are described in subsequent sections. Reset Button +3VDC Lithium Battery +24VDC Power RJ45 Ethernet EIA-232 Port Connector Connector DB9-NUP connector - used for operation as the network connection to NOTI-FIRE-NET... -
Page 13: Nfn Gateway-2 Cabinet Installation
NFN Gateway-2 Cabinet Installation NFN Gateway-2 Hardware Installation 2.3 NFN Gateway-2 Cabinet Installation Step 1. Mount the gateway CAB-3/CAB-4 series cabinet on a building’s inside wall at a height local regulation require. NOTE: The gateway cabinet is ordered separately. For installation details, refer to the CAB-3/CAB-4 Series Installation Document, 15330. -
Page 14: Hardware Installation
NFN Gateway-2 Hardware Installation Hardware Installation 2.4 Hardware Installation Step 1. Install the gateway motherboard mounting plate (P/N: 18747) into the gateway cabinet. Step 2. Install the gateway motherboard onto it’s mounting plate. The board is attached using the supplied screws (six). Step 3. -
Page 15: Cable Connections
Cable Connections NFN Gateway-2 Hardware Installation 2.5 Cable Connections 2.5.1 DB-9 to NUP Connection (NFN Gateway-2 to NOTI-FIRE-NET) The NFN Gateway-2 connects to the NCM-W/F Network Control Module. Use a NCM-W for a twisted pair wire connection or NCM-F for a fiber-optic cable connection. Make the connection according to Figure 2.4 below:... -
Page 16: Power Connection
NFN Gateway-2 Hardware Installation Power Connection 2.6 Power Connection The power supply for the NFN Gateway-2 is a +24VDC. The NFN Gateway-2 requires +24VDC @ 330 mA nominal and battery backup in accordance with local code requirements. It can be powered by any power limited source that is UL listed for use with fire protective signaling units. -
Page 17: Section 3 Nfn Gateway-2 Software Installation
Section 3 NFN Gateway-2 Software Installation This section provides information about installing the ONYXWorks software. NOTE: If installing the NFN Gateway-2 as part of an existing ONYXWorks™ system make sure the Workstation’s software key has been upgraded to include NFN Gateway-2 functionality (ONYXWorks™... - Page 18 NFN Gateway-2 Software Installation Install the NFN Gateway Configuration Tool Step 3. After communication has been established, the following window will display. For information about the fields in this window see, "NFN Gateway Configuration Field Descriptions".: Figure 3.2 NCM and IP Configuration Settings Step 4.
-
Page 19: Start The Nfn Gateway-2 Application
Start the NFN Gateway-2 Application NFN Gateway-2 Software Installation 3.2 Start the NFN Gateway-2 Application The Serial Configuration Tool is used to initially configure the NFN Gateway-2 to communicate with NOTI-FIRE-NET network. See Section 3.1, “Install the NFN Gateway Configuration Tool”, on page 17 for installation information. - Page 20 NFN Gateway-2 Software Installation Start the NFN Gateway-2 Application Change the Default Password Step 1. On the main web page, click on Password Settings at the list on the left. Step 2. Once you are on the Password Settings web page, delete the asterisks that denote the current password, type in the new password.
-
Page 21: Configure The Nfn Gateway-2 With The Workstation
Configure the NFN Gateway-2 with the Workstation NFN Gateway-2 Software Installation 3.3 Configure the NFN Gateway-2 with the Workstation Step 1. Select Start >Programs >Facilities Monitoring >Workstation. Step 2. From the main menu bar, select Configuration >Gateways. Figure 3.5 Workstation Menu - Configure Gateways Step 3. - Page 22 NFN Gateway-2 Software Installation Configure the NFN Gateway-2 with the Workstation Step 4. From the Add Gateway Connection window, enter the Gateway Number and the computer name or IP address and then click OK. Figure 3.7 New Connection Setup Screen Step 5.
-
Page 23: Section 4 Nfn Gateway-2 Operation
Section 4 NFN Gateway-2 Operation This section provides information about operating the ONYXWorks software. 4.1 Browser Security Settings These Microsoft® Internet Explorer® settings for trusted sites MUST be made before you use the web server. • Enter your Web Server’s IP address. •... -
Page 24: Logging In
NFN Gateway-2 Operation Logging In 4.2 Logging In NOTE: The ONYXWorks application requires version 5 or later of Microsoft® Internet Explorer. Start the NFN Gateway-2 Application Step 1. Start Microsoft® Internet Explorer (see “Start the NFN Gateway-2 Application” on page 19). -
Page 25: Overview Of The Nfn Gateway-2 Interface
Overview of the NFN Gateway-2 Interface NFN Gateway-2 Operation 4.3 Overview of the NFN Gateway-2 Interface The NFN Gateway-2 interface is a html page type format that displays configuration information about the NOTI-FIRE-NET network, the NFN Gateway-2, its password settings, node mapping on the network, version information and network statistics. -
Page 26: Viewing Version Information On The Nfn Gateway-2
NFN Gateway-2 Operation Viewing Version Information on the NFN Gateway-2 4.4 Viewing Version Information on the NFN Gateway-2 The Version Info link navigates to a page that displays a list of NOTI-FIRE-NET panels, annunciators and related monitoring devices. Corresponding version information and their related network interfaces is also displayed. -
Page 27: Viewing Nup Port Statistics
Viewing NUP Port Statistics NFN Gateway-2 Operation 4.5 Viewing NUP Port Statistics The NUP Port Statistics page displays a status overview of all nodes and NCMs on the NFN network. This information is useful for troubleshooting purposes Figure 4.4 NUP Port Statistics NOTE: Only ONYX series products (NFS/NFS2-3030, NFS-640, NCA/NCA-2) will have version information displayed. -
Page 28: Viewing Or Changing Nfn Settings
NFN Gateway-2 Operation Viewing or Changing NFN Settings 4.6 Viewing or Changing NFN Settings The NFN Settings page displays various values that can be changed through the NFN Gateway-2. Figure 4.5 NFN Gateway-2 Settings Site Settings Site Name - A user defined field used to enter a unique descriptive name for the NFN Gateway-2 browser. -
Page 29: Viewing Or Changing Gateway Settings
Viewing or Changing Gateway Settings NFN Gateway-2 Operation 4.7 Viewing or Changing Gateway Settings Gateway Address - The location of the NFN Gateway-2, valid settings are between 1 and 99. Gateway Timeout - This entry sets time (in seconds) the NFN Gateway-2 will wait before retry attempts. -
Page 30: Viewing Or Changing Node Mapping
NFN Gateway-2 Operation Viewing or Changing Node Mapping 4.8 Viewing or Changing Node Mapping Node Mapping allows the user to map nodes that are active on the NOTI-FIRE-NET network to the NFN Gateway-2. Node mapping is similar to filtering in that if a node is mapped in the NFN Gateway-2, then the Workstation will communicate with that node. -
Page 31: Resetting The Gateway Hardware
Resetting the Gateway Hardware NFN Gateway-2 Operation 4.9 Resetting the Gateway Hardware Click on Reset Hardware to reboot the ONYXWorks. During the process of rebooting the NFN Gateway-2 will temporarily leave the network and it will not communicate during the reboot process. - Page 32 NFN Gateway-2 Operation Resetting the Gateway Hardware ONYXWorks™ NFN Gateway-2 Installation & Operation Manual - P/N: 52656:Rev: A 05/19/06...
-
Page 33: Section 5 Onyxworks Workstation Operation
Section 5 ONYXWorks Workstation Operation The ONYXWorks provides communication between NOTI-FIRE-NET devices and the ONYXWorks™ system. When an event occurs on a NOTI-FIRE-NET network being monitored by NFN Gateway-2, the event displays in the New Events area on the Workstation’s display. Each NOTI-FIRE-NET device is recognized by its own unique device ID on the Workstation’s display. - Page 34 ONYXWorks Workstation Operation NFN Gateway-2 Commands for NOTI-FIRE-NET Devices Panel Commands The following figure shows the device commands that are available for Panel devices. Figure 5.1 Panel Right Click Menu Detector Commands The following figure shows the device commands that are available for Detector devices. Figure 5.2 Detector Right Click Menu ONYXWorks™...
- Page 35 NFN Gateway-2 Commands for NOTI-FIRE-NET Devices ONYXWorks Workstation Operation Module Commands The following figure shows the device commands that are available for Module devices. Figure 5.3 Module Right Click Menu Zone Commands The following figure shows the device commands that are available for Zone devices: Figure 5.4 Zone Right Click Menu ONYXWorks™...
-
Page 36: Network Explorer For Nfn Gateway-2
ONYXWorks Workstation Operation Network Explorer for NFN Gateway-2 5.3 Network Explorer for NFN Gateway-2 The Network Explorer for NFN Gateway-2 (Network Explorer window) displays information about all the nodes on the NOTI-FIRE-NET network being monitored by the NFN Gateway-2. The Network Explorer window operates similar to Microsoft’s Windows Explorer. -
Page 37: 1: Displaying Properties In The Network Explorer For Nfn Gateway-2
Network Explorer for NFN Gateway-2 ONYXWorks Workstation Operation 5.3.1 Displaying Properties in the Network Explorer for NFN Gateway-2 The Network Explorer window displays information through its expandable Panels tree down to the point level. Click on a node in the Panels tree to view its general properties. Entries in the Property column that display an asterisk (*) can be edited. - Page 38 ONYXWorks Workstation Operation Network Explorer for NFN Gateway-2 ONYXWorks™ NFN Gateway-2 Installation & Operation Manual - P/N: 52656:Rev: A 05/19/06...
-
Page 39: Index
Index Cabinet Installation 13 Ethernet 9 Ethernet Connection 15 Gateway Configuration Tool 17 motherboard layout 12 NCM 18 NCM-W/F 15 Power Connections 16 System 8 ONYXWorks™ NFN Gateway-2 Installation & Operation Manual - P/N: 52656:Rev: A 05/19/06... - Page 40 Index ONYXWorks™ NFN Gateway-2 Installation & Operation Manual - P/N: 52656:Rev: A 05/19/06...
- Page 41 Products are date stamped at time of manufacture. The sole and exclusive obligation of Honeywell is to repair or replace, at its option, free of charge for parts and labor, any part which is defective in materials or workmanship under normal use and service.
- Page 42 World Headquarters 12 Clintonville Road Northford, CT 06472-1653 USA 203-484-7161 fax 203-484-7118 www.notifier.com...
