- Page 1 INSTALLATION GUIDE For DIN type mortise locks MODELS: ELECTRONIC INFO: E10M - ME0J - E30M Copyright © 2025 Salto Systems, S.L.
- Page 2 SALTO recomienda utilizar cerraduras con un pregiro maximo de 4º. SALTO empfiehlt den Einsatz von Einsteckschlössern mit max. 4° Vorspannung. SALTO recommande d’utiliser des serrures à mortaiser avec un angle au repos de 4° maximum. SALTO raccomanda l'utilizzo di una serratura con un angolo di pre-rotazione massimo di 4°.
- Page 3 INSTALLATION GUIDE | For DIN type mortise locks Select handing Seleccione mano Drückerrichtung wählen Choisir le sens de la bèquille Kies draairichting Selezionare il verso PAGE 3/14 saltosystems.com...
- Page 4 INSTALLATION GUIDE | For DIN type mortise locks TORX 20 3 mm PAGE 4/14 saltosystems.com...
- Page 5 INSTALLATION GUIDE | For DIN type mortise locks Installation Instalación Montage Installation Handleidig Montaggio 8 mm. MIN. 20 mm. *ø8 *ø9 PAGE 5/14 saltosystems.com...
- Page 6 INSTALLATION GUIDE | For DIN type mortise locks TORX 20 PAGE 6/14 saltosystems.com...
- Page 7 INSTALLATION GUIDE | For DIN type mortise locks NOT OK LR03 PAGE 7/14 saltosystems.com...
- Page 8 INSTALLATION GUIDE | For DIN type mortise locks AT THIS POINT DO NOT CLOSE THE click! DOOR, PROGRAM THE LOCK FIRST. Follow user manual NO CIERRE LA PUERTA, PROGRAME LA CERRADURA Consulte el manual del usuario TÜR NICHT SCHLIESSEN, ZUERST SCHLOSS PROGRAMMIEREN. Folgen Sie dem Benutzerhandbuch TORX 10 NE FERMEZ PAS LA PORTE,...
- Page 9 INSTALLATION GUIDE | For DIN type mortise locks Installation Instalación Montage Installation Handleidig Montaggio ***** PANIC ***** 8 mm. PRIVACY SALTO LE8Pxx.. LE7Sxx.. OPTION 1 OPTION 2 *ø8 *ø9 PAGE 9/14 saltosystems.com...
- Page 10 INSTALLATION GUIDE | For DIN type mortise locks PAGE 10/14 saltosystems.com...
- Page 11 INSTALLATION GUIDE | For DIN type mortise locks TORX 20 NOT OK PAGE 11/14 saltosystems.com...
- Page 12 INSTALLATION GUIDE | For DIN type mortise locks Unplug Desconecte Débranchez Ziehen Losmaken Scollagare Plug Conecte Einstecken Connecte Insteken Collegare click! TORX 10 LR03 PAGE 12/14 saltosystems.com...
- Page 13 INSTALLATION GUIDE | For DIN type mortise locks Battery change Sustitución de las pilas Batterie tauschen Remplacer les piles Vervangen batterij Sostituzione la pila TORX 10 PAGE 13/14 saltosystems.com...
- Page 14 INSTALLATION GUIDE | For DIN type mortise locks PAGE 14/14 saltosystems.com...
