SiUS612209EA
Service Instructions
DX6VS***1*A* / DZ6VS***1*A* Inverter Outdoor Units,
DV**FEC / DFVE** EEV air handlers & CAPE(A)* / CHPE* EEV cased coils
with R-410A Refrigerant
WARNING
Only personnel that have been trained to install, adjust, service or repair(here-
inafter, "service") the equipment specified in this manual should service the
equipment. The manufacturer will not be responsible for any injury or property
WARNING
damage arising from improper service or service procedures. If you service this
unit, you assume responsibility for any injury or property damage which may
result. In addition, in jurisdictions that require one or more licenses to service
DO NOT BYPASS SAFETY DEVICES
the equipment specified in this manual, only licensed personnel should service
the equipment.
Improper installation, adjustment, servicing or repair of the equipment specified
in this manual, or attempting to install, adjust, service or repair the equipment
specified in this manual without proper training may result in product damage,
property damage, personal injury or death.
© 2022
