Industrial HVLS Fan
Installation &
Owner's Manual
MODELS:
MCFAN16PBGR
MCFAN24XBGR
Read this manual carefully before installation and keep it where
the operator can easily find it for future reference.
Due to updates and constantly improving performance, the
information and instructions within this manual are subject to
change without notice.
Version Date: 10/23/2024
Please visit www.mrcool.com/documentation
to ensure you have the latest version of this manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MCFAN16PBGR and is the answer not in the manual?

Questions and answers

Summary of Contents for MrCool MCFAN16PBGR

  • Page 1 Due to updates and constantly improving performance, the information and instructions within this manual are subject to change without notice. Version Date: 10/23/2024 Please visit www.mrcool.com/documentation to ensure you have the latest version of this manual.
  • Page 2: Table Of Contents

    5. If there is unusual oscillating movement, immediately stop the ceiling fan and contact MRCOOL, or a qualified service professional. The means of attachment to the ceiling, such as hooks or other devices, must be fixed with a sufficient strength to withstand 4 times the weight of the ceiling fan.
  • Page 3: Unit Overview

    UNIT OVERVIEW 2.1 Product Summary The MRCOOL® Industrial HVLS fan with permanent magnet frequency conversion is specifically developed to save energy, reduce consumption, and create a comfortable work environment. The independently designed permanent magnet motor features a small, light weight size, high efficiency, low noise, and variable frequency speed regulation.
  • Page 4: Exploded View Unit Diagrams

    UNIT OVERVIEW 2.4 Exploded View Unit Diagrams MCFAN16PBGR MCFAN24XBGR mrcool.com...
  • Page 5: Packing Lists

    UNIT OVERVIEW 2.5 Packing Lists MCFAN16PBGR General Accessories Concrete Structure Name Quantity Name Quantity Motor RC Structure Controller Fixed Base Cover M12x50 Hex Bolt (Full Thread) M12x100 Expansion Screw M12x16 Hex Bolt (Full Thread) M12x100 Expansion Screw Hook M12 Hex Nylon Nut 4*10 Knurled Hand Screw Φ12 Standard Spring Washer...
  • Page 6 M12 Hex Nylon Nut Installation Tools Φ6 Steel Rope Name Quantity M6 Slide Retainer 13-16 Open End Wrench M10 Turnbuckles Hook 14-17 Open End Wrench Locking Pin Cross Screwdriver Slotted Screwdriver 14AWG*4 Cable 5mm Inner Hex Spanner 18AWG*2 Cable mrcool.com...
  • Page 7: 16-Foot Fan Installation

    M5X10 Slotted Screw M6X14 Hex Bolt NOTE M10X100 Hex Bolt M10X80 Hex Bolt Ensure the blade bracket on the motor assembly is installed in the correct direction. (See the figure above.) M10 Hex Nylon Nut Ø10 Large Washer Ø10 Spring Washer mrcool.com...
  • Page 8 Four-Hole Gasket tightening the screws and check whether all the screws are tightened. Blade Press Plate M12X50Hex Bolt (Full Thread) M12X16 Hex Bolt (Full Thread) M12 Hex Nylon Nut Ø12 Spring Washer mrcool.com...
  • Page 9 Install the connecting rod cover, screw and lock it as shown. Accessories Needed: Name Qty. Connecting Rod Cover M4X12 Cross Screw Step 10: Install the fixed seat cover as shown and lock it with the head screw. Accessories Needed: Name Qty. Fixed Seat Cover Hand Screw M4 mrcool.com...
  • Page 10 NOTE The included angle between the steel rope and the connecting rod is greater than 30° and less than 45°. The steel rope clamp shall be securely installed and the steel rope can be adjusted by the elastic hook. mrcool.com...
  • Page 11 After connecting the wire, pull to verify that the wire is secured. When connecting the fast terminal, the power cord should be peeled 13/16" (10mm) and inserted into the card slot as a depth of 5/8" (17mm). mrcool.com...
  • Page 12: 24-Foot Fan Installation

    M12 Hex Nylon Nut symmetrically at both ends. M12X100 Expansion Screw Step 2: Install the quick terminal on the connecting rod, screw and lock it tightly. Accessories Needed: Name Qty. Connecting Rod Quick Terminal Cross Recessed Pan Head Screws M3x16 mrcool.com...
  • Page 13 Step 4: Install the mounted motor connecting rod assembly on the fixed seat and screw it without tightening. Accessories Needed: Name Qty. Motor Connecting Rod Assembly M12X130 Hex Bolt Ø12 Large Washer Ø12 Standard Spring Washer M12 Hex Nylon Nut mrcool.com...
  • Page 14 Install the tail blade assembly on the motor, install the screws and pull the blade outward from the center of the motor. Screw the blade without tightening. Accessories Needed: Name Qty. Blade Assembly M12X50 Hex Bolt (Full Thread) M12X16 Hex Bolt (Full Thread) Blade Press Plate Four-Hole Gasket M12 Hex Bolt Ø12 Spring Washer Ø12 Flat Washer mrcool.com...
  • Page 15 Determine the position of the expansion bolt hook, drill the mounting hole with a 14mm drill bit (hole depth 80mm), install the M12X100 expansion bolt hook with the opening upward and tighten the expansion screw hook. Accessories Needed: Name Qty. Expansion Bolt Hook mrcool.com...
  • Page 16 NOTE The included angle between the steel rope and the connecting rod is greater than 30° and less than 45°. The steel rope clamp should be securely installed and the steel rope can be adjusted by the turn hook. mrcool.com...
  • Page 17 After connecting the power cord, pull to verify the power cord is reliable. When connecting the fast terminal, the power cord should be peeled 10mm and inserted into the card slot at a depth of 17mm. mrcool.com...
  • Page 18: Control Panel Operation

    Press "Set" again to confirm. In keypad control mode, the up and down keys can also be used for dynamic speed control. "Run" and "Stop/Reset" keys control start and stop. Press "Stop/Reset" key to reset inverter to fault status. mrcool.com...
  • Page 19: Troubleshooting

    -Repair the temperature control circuit circuit -Increase motor heat dissipation -Motor temperature is too high Instruction is invalid -Cable is loose -Plug the cable securely -Frequency converter has fault -Turn off the power and power on again Failure -Contact the manufacturer mrcool.com...
  • Page 20 Industrial HVLS Fan The design and specifications of this product and/or manual are subject to change without prior notice. Consult with the sales agency or manufacturer for details.
