GF20-500N-ZBA,GF20-500P-ZBA
instructions
----------------------------------
Precautions:
To ensure your safety, please follow the following regulations when
using:
1. This product is only used for detecting the target substance. Do not
use this product for purposes such as protecting the human body or
body parts.
2. This product cannot be used as an explosion-proof product. Do not
use this product in hazardous areas and/or environments with
potentially explosive gases.
3. This product is a DC powered sensor. Do not use AC power.
Otherwise, it may cause the product to explode or catch fire.
4. Do not connect the sensor along the power or high-voltage lines, as
the sensor may malfunction or be damaged due to noise.
5. When using commercial switch type Pressure regulator, ensure that
the chassis grounding terminal and grounding terminal are grounded.
6. Do not use outdoors or in areas where external light can directly
enter the light receiving surface.
GF20 series exterior dimensions
Technical specifications:
GF20-500N-ZBA
Model
NPN output
Type
Control
NPN or PNP collector open circuit
output
Light source
Reaction time
1MS within
Operation indicator light: Green LED indicates
Display
power indicator light, and red LED indicates
indicator
output
Detection
500CM
distance
control
NPN/PNP Open collector 24V, maximum 100mA
(only for main components) residual voltage: 1V
output
Between 12 and 24VDC ± 10%, floating ratio
Power supply
(P-P): maximum 10% level 2
Working
Incandescent lamp: maximum: 20000lux,
environment
brightness
Standard mode:
Power
maximum 300mW
Maximum voltage:
Consumption
24V
Vibration
10 to 55Hz, dual amplitude: 1.5mm, X, Y, and Z
resistance
Ambient
temperature
GF20-500P-ZBA
PNP output
1 output port, lead out type
Red light 623NM,
daylight: maximum: 30000lux
Standard mode:
maximum 300mW
Maximum voltage:
24V
axes for 2 hours respectively
-10 to+55 ℃, no freezing
