DADISICK GFL-F Series User Manual

User manual for GFL-F series
laser ranging sensors
！
Warn
● The light source of this product uses visible semiconductor lasers. It is prohibited
to directly or indirectly re ect the laser beam from the re ecting object into the eye.
If the laser beam enters the eyes, it may pose a risk of blindness.
● This product does not have an explosion-proof structure. Prohibit use in
ammable, explosive gas or explosive liquid environments.
● Do not disassemble or modify this product as it is not designed to automatically
turn o laser emission when the body is opened. If the client disassembles or modi es
this product without authorization, it may cause personal inju , re, or electric shock
hazards.
● The use of controls, adjustments, or operational procedures beyond those
speci ed here may result in hazardous radiation leaks.
！ Reminded
● It is ve dangerous to wire, connect/disconnect inte aces when the power is
turned on. Please make sure to turn o the power before operation.
● Installation in the following locations may cause malfunctions:
1. A place covered with dust or steam;
2. Places where corrosive gases can be generated;
3. A place that will directly receive splashed water or oil;
4. Places subjected to severe vibration or impact.
● This product is not suitable for outdoor use.
● Do not use this sensor in an unstable state sho ly after the power is turned on
(approximately 15 minutes of warm-up time)
● If it is necessa to use a switching power regulator, please ground the grounding
terminal. Do not connect to high-voltage cables or power lines. Operation failure will
lead to induction or damage faults, as each product has di erences, so there may be
slight di erences in the detection characteristics of the workpiece.
● Do not use this product in water.
● Please do not disassemble, repair, or modify this product without authorization, as
it may cause electric shock, re, or inju to the human body.
● Wipe o dust on the transmitting or receiving components to maintain proper
detection. Avoid direct impact of external objects on this product.
● Operate within the rated range.
！
This product cannot be used as a safety device to protect the human body.
Dimensions
Wiring method
NPN+Analog+RS485
Brown + V
External
Pink
Input
Control
Black
Output
External
Input
Blue 0 V
Gray
Analog Output
Analog Ground
Shield
AGND AGND
RS485(A+)
White
Yellow RS485(B-)
PNP+Analog+RS485
Brown + V
Control
External
Black
Output
Input
External
Pink
Input
Blue 0 V
Gray
Analog Output
Analog Ground
Shield
AGND
AGND
White RS485(A+)
Yellow RS485(B-)
Display and Buttons
Output indicator light
Learning key
Set up
Technical Parameters
Item
NPN+analog+485
PNP+analog+485
Measure distance
Item
NPN+analog+485
PNP+analog+485
Measure distance
Resolution
Measurement error
Laser type
Voltage
Current consumption
+
12V-24V DC
-
±10%
Control output
Analog
Input
Device
Output action
Sho circuit protection
Analog voltage output
Analog current output
Reaction time
External input
Protective structure
Operating temperature
Storage temperature
+ 12V-24V DC
-
±10%
Working humidity
Use ambient illumination
Use elevation
Analog Cable
Input
Device
Material
Quality
★: Indicates the measurement distance. In harsh environments, such as when the sunlight is too strong, the ambient
temperature uctuates too much, and the re ective su ace is dark, the measurement results will have larger errors. In
this case, the use of a target re ective plate will be better.
Threshold setting
The current value
-/options
+/options
Model
GFL-F100NM-485 GFL-F200NM-485 GFL-F500NM-485
GFL-F100PM-485 GFL-F200PM-485 GFL-F500PM-485
0.1-1m 0.1-2m 0.1-5m
Model
GFL-FM10NM-485 GFL-FM20NM-485 GFL-FM50NM-485
GFL-FM10PM-485 GFL-FM20PM-485 GFL-FM50PM-485
0.1-10m 0.1-20m 0.1-50m
1mm
+(2mm+d*1/10,000)★
Red semiconductor laser Class II laser 655+10nm<1mW
12V-24VDC+10% pulsation P-P10%
≤50mA @24V
NPN or PNP open drain output
Open drain collector transistor output
Maximum current:50mA
Applied voltage: less than 30V DC
Residual voltage: less than 1.5V
Leakage current: less than 0.1mA
Normally open/normally closed can be switched
Automatic recove type
Output range: 0-5V (alarm: 5.2V) Output impedance: 100Ω
Output range: 4-20mA (alarm: 0mA) Output impedance: 300Ω max
50-200ms
NPN contactless input
IP67
-10C~+45℃ (be careful not to condense or freeze)
-20℃~+60℃
35%~85%RH
Incandescent lamp: light receiving su ace illumination below 3000lux
Below 2000m
With 8-core composite cable 2m
Aluminum pa s
About 150g
