CORA PANEL
MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the CORA PANEL and is the answer not in the manual?

Questions and answers

Related Manuals for Fermax CORA PANEL

Summary of Contents for Fermax CORA PANEL

  • Page 1 CORA PANEL MANUAL...
  • Page 2 Technical publication for information purposes edited by FERMAX ELECTRÓNICA S.A.U. FERMAX ELECTRÓNICA applies a continuous improvement policy, therefore it reserves the right to modify the contents of this document, as well as the product specifications referred to therein, at any time and without prior notice.
  • Page 3 6. ANNEX I: MY CONNECT PORTAL 7. ANNEX II: CORA EXTENDED 7.1. EXPANDER MODULE 7.1.1. Expander for the DUOX PLUS Panel 7.2. FUNCTIONALITY DESCRIPTION FOR GRAPHICAL INTERFACE AND WEB SERVER IN HEXACT MODE 7.2.1. Deactivate internal card reader CORA PANEL...
  • Page 4 User list Maintenance (FW version update and installation test) The Cora Panel can be used for all types of DUOX PLUS installations, from the most basic (individual kits) to large installations with multiple monitors or telephones. NOTE: The CORA Panel is not compatible with the iLOFT telephone in any of its current or future versions.

  • Page 5: Installation

    (“Door Forced” if there has been an unauthorised door release, or “Door Left Open” if it has not been properly closed after an authorised release). CN1: Connection for external card reader / external controller. CN2: Connection for directory Panel. CN3: Not used. CN4: RS485 connection. CORA PANEL...
  • Page 6 Due to its conical tip, no force needs to be exerted on the Panel - simply hold it against the surface SUPPLEMENTARY box while inserting the screw with the locking tool. CLOSING PIECE CORA PANEL...
  • Page 7 Note: If a self-drilling screw does not take hold, it will have to be replaced by a longer dowel and screw. UPPER SEAL ASSEMBLY SCREW HOLES LOWER SEAL ASSEMBLY THE LOWER SEAL INCLUDES THE HOUSING FOR THE LOCKING SCREW Mount the Panel on the adapted City S6 flush box (see Assembly Sequence page 7). CORA PANEL...

  • Page 8: Technical Specifications

    18-24Vdc NON-POLARIZED (polarisation is not taken into account during installation) Power supply Direct from the DUOX Bus Operating temperature - 25ºC to 55ºC Relative humidity 5-95%, non-condensed Dimensions (mm) 203 (W) × 129 (H) × 17.5 (D) IP65 rating IK08 rating CORA PANEL...
  • Page 9 4. DESCRIPTION 4.1. SCREEN The Cora Panel includes a 5" TFT in 4:3 vertical format, where the images are displayed to help the Panel User to move between the different functions. The User interface is intended to be used via the buttons on the keypad. When the Panel is in standby, if any button is pressed or presence is detected, it will activate (this function can be disabled from the web server).

  • Page 10: Card Reader

    The reading distance is approximately 4 cm with key rings, and 7 cm with cards. 4.5 LIGHTING LED array: The CORA Panel includes a distinctive array of LEDs that provides status information to the User via colour changes and moving lights.

  • Page 11: Main Screen

    Users Different Information Screens depending on whether there is an Phonebook and a Guard Unit: 31.05.2021 18:05 31.05.2021 18:05 31.05.2021 18:05 MARQUE Nº DE VIVIENDA LLAMAR A MARQUE Nº VIVIENDA DE VIVIENDA LLAMAR A VIVIENDA MARQUE Nº DE VIVIENDA LLAMAR A BUSCAR EN VIVIENDA AGENDA BUSCAR EN AGENDA LLAMAR A CONSERJE CORA PANEL...

  • Page 12: Off Mode

    CÓDIGO DE ACCESO CÓDIGO DE ACCESO CÓDIGO DE ACCESO VERSIÓN 10.03 TIPO DE PLACA BLOQUE Nº BLOQUE Nº SUBBLOQUE Nº PLACA MÁSTER Sí CONECTIVIDAD NIVEL SEÑAL ADAPTADOR DE LÍNEA CONFIRMAR CONFIRMAR CONFIRMAR CONFIRMAR BORRAR BORRAR BORRAR BORRAR SALIR CORA PANEL...

  • Page 13: Panel Configuration

    - Use a browser and access the website http://fermax_cora.com. The Login Screen will appear. ACCESO CONFIGURACIÓN FERMAX_981FG ACCEDA CON SU NAVEGADOR 5.2.1 LOGIN The Web Server Access Screen will show a drop-down menu where you must select the type of profile according to the code entered to create the access point. For the INSTALLER profile: Default code 19025. For the ADMIN profile: Default code 11077. If you have registered an Installer or Administrator card, select the correct profile and enter the card number. CORA PANEL...
  • Page 14 DUOX devices in an installation Exit Web Server logout Actions: ACTION DESCRIPTION Click Information icon Displays information on the current view Stores User-entered information from the current Click Save icon section and moves on to the next section CORA PANEL...

  • Page 15: Panel Information

    Tiempo apertura ���� Ajustes Vivienda: ���� Usuarios Tiempo de apertura botón de salida: ���� Mantenimiento ���� Salir Sensor Puerta: CÓDIGOS TECLADO Permitir Códigos de Teclado: Número de dígitos: ���� LECTOR RFID Controlador Externo: Solicitar código PIN: TAMPER Tamper: ���� CORA PANEL...

  • Page 16: Keypad Codes

    To enter the keypad codes on the Panel, it is necessary to press beforehand. PARAMETER DESCRIPTION Activates / deactivates door release functionality by Allow Keypad Codes entering keypad codes Number of digits Set number of User door release digits (4 to 6) CORA PANEL...

  • Page 17: Rfid Reader

    A 30-second window will open for entry of the identifiers you wish to add to the reader. Each successfully submitted identifier shall emit a confirmation tone and send a confirmation message to the Web Server. Once finished, you can either wait for the 30 seconds to expire or close the window to confirm the registrations. CORA PANEL...
  • Page 18 LANGUAGES Language selection and customisations AUDIO Audio-related settings VIDEO Video-related settings DISPLAY Display-related settings CALLING Call-related settings CONCIERGE Settings related to Guard Units CLOCK System clock related settings Management of customised images to appear on IMAGES the display CORA PANEL...
  • Page 19 Dansk Danish Pусский Russian Íslenska Icelandic Türkçe Turkish Italiano Italian ‫עברית‬ Hebrew Magyar Hungarian Nederlands Dutch Hrvatski Croatian Português Portuguese български Bulgarian Català Catalan Lietuvių Lithuanian Valencià Valencian Latviski Latvian Euskera Basque Eesti Estonian Galego Galician ελληνικά Greek CORA PANEL...
  • Page 20 Türkçe Turkish Magyar Hungarian ‫עברית‬ Hebrew Hrvatski Croatian Nederlands Dutch български Bulgarian Português Portuguese Lietuvių Lithuanian Català Catalan Latviski Latvian Valencià Valencian Eesti Estonian Basque Basque ‫فارسی‬ Farsi / Persian Galego Galician ‫عرب‬ Arabic ελληνικά Greek Český Czech CORA PANEL...
  • Page 21 The Panel defaults to 4. SUB-SECTION DESCRIPTION Activate / deactivate adaptive audio. If activated, the Adaptive volume is adjusted according to the ambient noise Conversation Conversation volume Messages Message volume Volume token key presses Microphone This sub-section allows you to configure the audio volume to the Apartment. The range of allowed values is from 1 to 8. CORA PANEL...
  • Page 22 Automatic Display brightness setting (ON / OFF) Auto Brightness adapts to the ambient lighting Display activation event configuration from standby Activate the (Key press - Key press or presence) Contact list. No. of names Configuration of number of Users displayed on the per Screen User Phonebook Screen (1 or 4) LED array activation configuration (always off or Off LED array with display off) CORA PANEL...
  • Page 23 Activate / deactivate retroview Retroview when Activate retroview ALWAYS or ON CALL ONLY Carousel Images Welcome Activate / deactivate welcome image Choice of welcome image: Fermax Carousel Images Image or customised Time in seconds for which each Carousel image Carousel Images time...
  • Page 24 Alphanumeric call alphanumeric calls (ON / OFF) Configures the activation / deactivation of the Villa Mode continuous ring tone during the call (ON / OFF) Terminate on opening Activate / deactivate End Conversation when the door opening door during a call (ON / OFF) CORA PANEL...
  • Page 25 Import Allows a .CSV table of mappings to be imported Export Allows export of current mappings to a .CSV table Edit mapping Allows a current mapping to be exported Remove mapping Allows a current mapping to be deleted CORA PANEL...
  • Page 26 Allows a .CSV table of Guard Unit labels to be Export imported Allows you to deactivate Call Divert on the Panel Reset Guard Units if it has been activated by mistake Edit label Allows editing of a current label Remove label Allows deletion of a current label CORA PANEL...
  • Page 27 2024-05-13 ���� ���� ���� Auto AJUSTE HORARIO VERANO/INVIERNO ���� Z… ���� Europe/Madrid ���� ���� Date / Time Format PARAMETER DESCRIPTION Time Format 12H – 24H Date Format Indicates in which order the day, month and year are shown CORA PANEL...
  • Page 28 Up to 4 images can be loaded to be shown on the display for additional information or advertising. Each image contains an identifier displayed at the bottom (1 - 4). Image format: jpg 480x640 pixel. ACTION DESCRIPTION Import Allows image import Delete Allows image deletion Next image Display the following image Previous image Show previous image CORA PANEL...

  • Page 29: Call Information

    5.2.7 USERS This view allows you to enter and manage specific User configurations and service functions. It contains the following sections: SECTION DESCRIPTION RESIDENTS Resident User management SERVICES Management of service providers By default, when the Users item is selected, the RESIDENTS section will be displayed, where an empty table will appear. CORA PANEL...
  • Page 30 Access Control / Keypad Codes / Number of digits) Door Release card code. It is possible to enter this number by pressing the Proximity icon and swiping the selected card through the card reader within 30s. (9 digits) CORA PANEL...
  • Page 31 1 and 20, preconfigured in the section Settings / Images / Web Server Call Information Edit User It is possible to edit the information of an existing User by clicking on the icon CORA PANEL...
  • Page 32 Keypad Code Web Server Access Code Keypad (5 digits) Web server access card code. It is possible to configure this number by pressing the icon Proximity and swiping the selected card through the card reader within 30s (9 digits) CORA PANEL...
  • Page 33 Carrier code or card Enables the activation / deactivation of the Trade Carrier functionality. If this option is activated, the bell button Trades performs the door release directly during the set hours and days CORA PANEL...

  • Page 34: Maintenance

    Enables you to enter the maintenance tools view FIRMWARE UPDATES This sub-section shows the current version of the Panel firmware and allows the User to upgrade to a new version. ACTION DESCRIPTION Select File Allows selection of update file Launches firmware update. The Panel goes into maintenance mode until the update is completed. Update If the filename is not correct, no action is taken and an error pop-up is displayed Update To perform the update, the file must have the following name: fermaxUpgrade.tar.bz2 CORA PANEL...
  • Page 35 EN MANTENIMIENTO After a few minutes, the Panel will reboot and boot with the new version installed, displaying the Configuration Boot Screen with the new version. In the event of an unsuccessful upgrade, the Panel will reboot to its pre-upgrade version. Panel Configuration This sub-section allows you to import or export a complete configuration of parameters and Panel tables. CORA PANEL...
  • Page 36 It is accessed from the Maintenance view, by clicking on the KEY icon: This view allows various maintenance actions to be carried out on the Panel and contains the following sections: ACTION DESCRIPTION DETECTION Detection of DUOX Terminals in installation TRAFFIC DUOX traffic display in installation Detection CORA PANEL...
  • Page 37 Inspect Terminal Terminal are displayed. It is possible to generate a .PDF report of the selected Terminal by pressing Allows a .PDF report with the information of the Generate report installation and all its Terminals to be generated CORA PANEL...
  • Page 38 The Terminal Discovery results table consists of the following fields: FIELD DESCRIPTION Direction DUOX address of the discovered Terminal Model Discovered Terminal model Version Version of the discovered Terminal Identifier Unique identifier of the discovered Terminal Displays discovered Terminal configuration Shares parameters The Terminal Discovery results table consists of the following fields: CORA PANEL...
  • Page 39 Commands / data transmission and reception of DUOX commands in the installation. Slower than simple detection. Launches a test that indicates the transmission and Video / Audio reception quality of Video/Audio in the installation. Much slower than detection. CORA PANEL...
  • Page 40 After the START button is pressed, the testing process will start: The Web Server will show a percentage bar of executed tests and a table of results in process with the Terminals to be tested. The Panel will display the maintenance Screen throughout the process. CORA PANEL...
  • Page 41 Indicates that the test was NOT successful between the Panel and the Terminal TEST KO Communication, audio or video problems may occur NO TERMINAL Indicates that the test could not be started DETECTED There could be a faulty or non-installed Terminal CORA PANEL...
  • Page 42 Allows you to delete the commands displayed DELETE COMMANDS in the table GENERATE REPORT Allows the generation of command reports The results table consists of the following fields: FIELD DESCRIPTION WASHING Command timestamp COMMAND Command type DATA Command data ORIGIN Command source device Transmit/receive command from the Amplifier's point TX/RX of view CORA PANEL...
  • Page 43 LLAMADA A VIVIENDA 12 _ 123 _ 1234 _ BORRAR LLAMA R CANCELAR LLAMAR BORRAR LLAMA R BORRAR LLAMAR LLAMANDO A VIVIEND A LLAMANDO A VIVIEND A EN CONVERSACIÓN FIN DE CONVERSACIÓ N 1234 CANCELAR RELLAMAR CANCELAR RELLAMAR CANCELAR CORA PANEL...
  • Page 44 Carousel Screens Press the BELL button A redial may be performed without changing the Screen Press the UP ARROW No action Press the DOWN ARROW No action Press MAGNIFYING GLASS button No action Screen during conversation EN CONVERSACIÓN CANCELAR CORA PANEL...

  • Page 45: Call Routing

    These Panels do not belong to any block and allow calls to be made to any existing block in the installation. The calling range is from xx0001 to xx9999, where xx can be any values from 00 to 99. CORA PANEL...
  • Page 46 The behaviour of these Screens is exactly the same as that of the Direct Call to Apartment Screen, except for the following points: - The digits marked correspond to a DUOX address mapping and not to the DUOX address itself. - It will always be possible to enter up to 6 digits. CORA PANEL...
  • Page 47 At this point it is possible to enter the next 4 digits (2 if a Call Code Length of 4 is selected) of the address to be called. Once the Bell button is pressed, the call process will start. CORA PANEL...
  • Page 48 Press the BELL button Select block and go to the next Screen Press the UP ARROW Change block selection Press the DOWN ARROW Change block selection Press MAGNIFYING GLASS No action button Call Apartment Screen in block call mode. CORA PANEL...

  • Page 49: Call From Phonebook

    It is possible to load Users in the Phonebook from the Web Server in the Users/Residents section: It is also possible to configure the number of Users displayed (4 or 1) per Screen in the Settings/ Display section: CORA PANEL...
  • Page 50 You will return to the previous Screen, but Press the BELL button selecting the first User beginning with the selected letter The previous letter is selected Press UP ARROW The following letter is selected Press the DOWN ARROW Press MAGNIFYING GLASS No action button CORA PANEL...
  • Page 51 When making a Phonebook call you can call any Apartment that is in the list; filtered Apartments are not shown in the directory in any event. Below is a table showing the behaviour of the Panel when making calls, depending on the parameters: - Restricted call, general Panel parameter activate deactivates this option. - Invisible User, User-specific parameter that allows the User to be shown or not in the Phonebook. CORA PANEL...
  • Page 52 Configuration of Guard Unit names from Web Server From the Settings/Concierge section, it is possible to associate names with the existing Guard Units in the installation. Below are several images showing how to name a General Entrance Guard Unit and a block Guard Unit: CORA PANEL...
  • Page 53 If there is only one Guard Unit in the installation, the call will be made directly by pressing the button. If there are several Guard Units, the following Screen will be displayed. SELECCIONE CONSERJE CONSERJERÍA EB01 CANCELAR LLAMA R CORA PANEL...
  • Page 54 Additional Door Lock + Text If this option is activated, extra text will appear information when an opening takes place If this option is activated, an extra image will be Additional Info Door Lock + Image displayed when an opening is performed CORA PANEL...
  • Page 55 If the Retroview setting is deactivated, the video will never be displayed on the Panel during the call and conversation. If the Retroview is activated with the When Calling option specified, the video will only be displayed on the Panel during calls, not during conversations. If Retroview is activated with the Always option specified, the video will be shown during calls and conversations. CORA PANEL...
  • Page 56 6 ANNEX I: MY CONNECT PORTAL UPDATE USERS FROM THE MYCONNECT PORTAL. (ONLY AVAILABLE WITH CORA CONNECT PANELS). The CORA Panel allows the User Phonebook to be updated from the MyConnect portal as long as the CORA Connect Panel is available. This Phonebook will be updated by uploading an .XLS file.
  • Page 57 4.- Once filled in, load the file on the Panel as follows: Select the right Phonebook button, select UPLOAD NEW, and select the file. 5. When a new Phonebook is loaded, the existing information on the Panel is overwritten. This action cannot be reversed, so it is advisable to have a backup of the current Phonebook. 6.- The “file successfully uploaded” message will appear. CORA PANEL...

  • Page 58: Power Supply

    • Nominal: 24Vdc NON-POLARIZED (polarisation is not taken into account during installation). Can be powered directly from the DUOX Bus It should be noted that in the specific case of connecting two or more Panel Directory Panels to the Cora DUOX PLUS Board, or installing the DDA inductive loop by means of the DUOX PLUS Board Expander, an external 12Vdc power supply must be used. CORA PANEL...

  • Page 59: Connection Terminals

    The DDA induction loop is attached to the back cover of the Cora Panel by clamps that are glued to the back of the Panel.
  • Page 60 RFID Reader/Disable Internal Reader section: By default the reader will NOT be disabled. It will be possible to disable it using this option. In addition, if the internal reader is enabled, the card reader illumination led will be activated. If disabled, it will be switched off. CORA PANEL...
  • Page 61 RADIO FREQUENCY MODULE: EC DECLARATION OF CONFORMITY FERMAX ELECTRÓNICA, S.A.U. declares that this product complies with the requirements of the RED Directive 2014/53/EU on Radio Frequency Equipment. https://www.fermax.com/spain/documentacion/documentacion-tecnica?type=declarations_of_conformity Radio frequency module: 4G: Frequency: 1800MHz / Maximum power: 23dBm ± 2.7dB EM proximity reader RFID antenna Frequency: 125KHz / Maximum power: -5.58 dBm...
  • Page 62 HEXACT ENTREZ LE Nº DE L’APPARTEMENT APPEL HÉBERGEMENT En el caso de que exista en curso una transferencia de usuarios desde la central HEXACT a la placa, aparecerá un reloj de arena a la izquierda del logo HEXACT. CORA PANEL...
  • Page 63 Ejemplo tabla de usuarios en modo HEXACT Mapeados Al estar activo este modo, la pantalla Usuarios/Residentes también cambiará: - No será posible eliminar o editar mapeados uno a uno - NO será posible importar mapeados - Seguirá siendo posible BORRAR todos los usuarios Ejemplo tabla de usuarios en modo HEXACT CORA PANEL...
  • Page 64 FERMAX ELECTRONICA S.A.U Avenida Tres Cruces, 133 46017 Valencia, Spain CORA PANEL...
