Maxview Roam Basecamp Installation & User's Instructions

Hide thumbs

Table Of Contents

Quick Links

Download this manual

Router is pre-fitted

inside antenna enclosure.

BASE/50

Installation & User Instructions

This manual provides information on how to control the Roam Basecamp Router using

your device's internet browser. Most of these functions can be completed easier and

faster using the Maxview Roam App.

See the Roam App instruction

manual for more information.

UK contact:

Helpline:

+44 (0)1553 811000

Email:

support@maxview.co.uk

Web:

www.maxview.co.uk

Maxview Address:

Maxview Ltd, Garage Lane, Setchey,

King's Lynn, Norfolk. PE33 0AT. UK

Maxview reserve the right to change specifications without prior notice.

9111471 Iss 1

Maxview Roam Basecamp Powered by

Roam Basecamp

Unique Router Password & Serial Number Information.

Please keep this instruction manual and label safe,

for future reference.

We have partnered up with one of the largest

suppliers of Wi-Fi products worldwide.

Table of Contents

Need help?

Do you have a question about the Roam Basecamp and is the answer not in the manual?

Questions and answers

Summary of Contents for Maxview Roam Basecamp

Page 1 Roam Basecamp BASE/50 Installation & User Instructions This manual provides information on how to control the Roam Basecamp Router using your device’s internet browser. Most of these functions can be completed easier and faster using the Maxview Roam App. See the Roam App instruction manual for more information.
Page 2: Table Of Contents
Introduction Thank you for purchasing this product, should you have any difficulty using your Roam Basecamp Mobile 4G Wi-Fi System please contact our friendly Customer Helpline on +44 (0)1553 811000 or email support@maxview.co.uk. Contents Record your Purchase Router - Advanced Functions and Changing...
Page 3: Product Contents
Available separately - Order PSU2000 Choosing a Service Provider To use the Maxview Roam Bascamp, you will need a suitable data SIM card (sold separately) The Maxview Roam Basecamp is unlocked, so you can use any service provider. The best package will depend on many factors such as data usage, budget, location of travel and...
Page 4: Router Set Up
Router Set Up - Inserting your SIM Card - Removing the Router from the antenna enclosure...
Page 5 Inserting a SIM Card Firstly remove the 14 screws on the rear of the Use pin to firmly press on SIM eject button. This is antenna enclosure using a Phillips screwdriver. located next to the SIM slot. It is not necessary to apply force to the SIM tray itself.
Page 6: Removal And Re-Inserting Router Back Into The Antenna Enclosure
Removal and re-inserting router back into the antenna enclosure The router can now be slid downwards and then easily removed from the antenna enclosure. To re-insert the router back into the antenna enclosure, simply reverse these 3 steps. The ethernet cable MUST be inserted into the port.
Page 7: Powering & Mounting
Powering & Mounting Instructions...
Page 8: Connecting The Ethernet Cable To The Antenna Enclosure
The POE Adaptor can be mounted to a wall using the supplied screw for a neat installation. 12V Cigarette Adaptor 230V powering option For those who have a 230V power supply a separate PSU unit can be purchased separately from Maxview. Order code: PSU200O. See page 3.
Page 9: Using The Pre-Fitted Mounting Bracket
After fitting the SIM, we recommend testing the router is connecting to the Cell network and functioning fully. This should be done before refitting the plastic cover and mounting your Basecamp in it’s intended location. Using the pre-fitted mounting bracket This universal design comes complete with 4 x Pole Clamps at different sizes suitable for a wide range of pole sizes or different applications.
Page 10: Positioning Your Roam Basecamp
Positioning your Roam Basecamp For the best performance we always recommend mounting the Roam Basecamp as high and securely as possible. Preferably just above your vehicle’s roof line. If using in a vehicle application see our mounting options below. Alternatively the unit can be mounted to a tripod as shown right.
Page 11 Important! Ensure the Basecamp is secure when fixed to your chosen mounting method. Consider removing the Basecamp in adverse weather conditions or high wind. Always remember to remove your temporarily mounted Basecamp before travel. B2535 - Deluxe Tripod The Deluxe Tripod offers a robust and reliable platform with the added functionality of height adjustment.
Page 12: Getting Online Factory Reset
Router - Getting Online - Factory Reset...
Page 13 Once you select this network, You are now connected and can settings and view available Wi-Fi you must enter the password. This begin using your Roam Basecamp. networks. is located on the front page of this instruction manual or the attached...
Page 14 When prompted, select ‘join’. Your device will automatically connect to the Roam router. That’s it! You are now connected to the secure Wi-Fi hotspot of your Roam Basecamp Router. The Wi-Fi network name and password will remain the same as those listed on the back of the router.
Page 15: Factory Reset
Factory Reset At any time, the Roam router can be reset to its factory settings using the reset button on the side of the router. This will restore all settings on the router, including: • Router SSID (network name) and password to those listed on the back of the router. •...
Page 16: Router Settings
Did you know? The functions in this section can be completed easier and faster using the Maxview Roam App. See the Roam App instruction manual for more information.
Page 17: Connecting To The Web User Interface
Advanced Functions and Changing Router Settings All of the settings and functionality of the Roam Basecamp router are changed using the Web User Interface. This can be accessed using a browser when your device is connected to the Roam Wi-Fi network. The Roam Basecamp router is very powerful and there are many settings in here which can be adjusted to suit your requirements.
Page 18 When accessing the Web User Interface for the first time, you will be offered the chance to use the Set Up Wizard. This can be used to set up the router’s most relevant parameters, such as changing the hotspot username and password. Competent users can navigate through other settings, however we recommend skipping the Set Up Wizard as it is not strictly necessary to change any of these settings.
Page 19: Logging Out Of The Web User Interface
Logging out of the Web User Interface Once you have finished using the Web User Interface, you should log out. We recommend doing this every time you have finished using the Web User Interface. Select ‘Log Out’ in the top right hand corner and Once you have logged out you can now close the confirm you wish to log out.
Page 20 Router Changing the Primary Internet Source from 4G to WiFi Did you know? The functions in this section can be completed easier and faster using the Maxview Roam App. See the Roam App instruction manual for more information.
Page 21 This can be done using a separate device with Wi-Fi connectivity, such as a mobile phone, laptop or tablet. It is easier and faster to switch between 4G and Wi-Fi using the Maxview Roam App. See the Roam App instruction manual for more information.
Page 22 Next the wireless connection you wish to connect to click ‘Join Network” Enter the password for the network and network name if you choose to do so. Then click ‘Submit’ Hit the enable button to turn on.
Page 23 Your router will now connect to your chosen wifi network. However the connection your router uses for to connect to the internet will depend on your WAN configuration setting, To change connection priority drag and drop each connection in the order desired. Then save and apply.
Page 24: Changing The Routers Lan Ip Address
Changing the Routers LAN IP Address In some cases, the LAN IP Address of the Roam Router will be the same as the source Wi-Fi IP address. If this is the case, using Wi-Fi as the internet source will not work. To fix this, we must change the LAN IP Address of the Roam Router.
Page 25: Other Functions
Router Other Functions Did you know? The functions in this section can be completed easier and faster using the Maxview Roam App. See the Roam App instruction manual for more information.
Page 26: Managing And Removing Wi-Fi Connections
Managing and Removing Wi-Fi Connections Navigate to ‘Network’ and then ‘Wireless’. From here, you can then view and manage the most recent WiFi connection listed under the Wireless Station Mode heading. This includes updating the password or removing it completely if it is no longer uses The Router will store the details of the most recently used Wi-Fi connection only.
Page 27 You will then see a list of the Wireless Access Points (hotspots) the router is creating. As standard, this will be for 2.4GHz. Select ‘pencil icon’ on the relevant access point. You will now be transferred to the ‘Interface Configuration’ tab under the ‘General Set Up’ tab. In the ESSID box, input a new name (ESSID) for your router.
Page 28: Entering Sim Pin
When the changes are complete, you will see You can now navigate to your device’s Wi-Fi a web browser error page and your device will no settings and view available Wi-Fi networks. The Roam longer be connected to the router. Because the Wi-Fi router hotspot will be displayed as your chosen name.
Page 29: Controlling Data Usage
To bring you the Roam Basecamp Router, we have partnered with Teltonika. Teltonika have a vast amount of information available for all function of the router and Web UI on their Wiki Support Site. This can be accessed at: https://wiki.teltonika.lt/view/RUT200.
Page 30: Router Firmware Update
Router Firmware Update From time to time, new firmware will be available to download onto the Router. It is not essential that the latest firmware is on the router, however we recommend keeping firmware up to date to ensure you have access to new feature releases and the latest security updates.
Page 31: Additional Information
Terms and conditions In no event shall Maxview be liable for any indirect, incidental or consequential damages from the sale or use of the product. This disclaimer applies both during and after terms of the guarantee. This does not affect your statutory rights.
Page 32: Maintenance
3. My phone is connected to the Roam Basecamp but I don’t have any phone signal? The Roam Basecamp creates a WiFi hotspot which can be used to provide a Wi-Fi connection to your device. This means it can be used for all features on your device that use an internet connection.
Page 33 8. Is there an easier way to change the settings for my router? Most router functionality can be controlled using the Teltonika App. 9. Why do I lose connection to my Roam Basecamp when I move in or out of range of the Wi-Fi source my Roam Basecamp is using? The Roam Basecamp will automatically detect and connect to the WiFi source you have set up in the Web User Interface.
Page 34 It is available to download from the Android Google Play and Apple App Stores. The Roam App is designed to simplify some of the key functions of the Maxview Roam Basecamp including set up, changing the Roam hotspot Wi-Fi name/password as well as switching between 4G and Wi-Fi source.
Page 35 18. What is WAN Failover? Once WIFI has been activated as the internet source, the Roam Basecamp uses WAN failover as default. This feature is designed to overcome the need to manually switch the internet source between mobile and Wi-Fi.
Page 36: Year Guarantee
2 year parts limited guarantee from the date of original purchase. Registering your product As part of our commitment to our customers, we ask owners of our Roam Basecamp 4G Wi-Fi Systems to register ownership. By registering products with the Maxview service database, we will have a record of the product purchase that will allow us to provide our customers with faster and improved technical support, notifications of software updates as well as many other benefits.
Page 37: Notes
Notes...
Page 38: Specifications
Specifications Antenna Antenna Type: Omni-directional 2 x Multi-band 4G/LTE Antenna 1 x Dual-band WiFi Antenna Frequency Range: 698-960 / 1710-2170 / 2300-2690MHz Peak Gain: 6.1 dBi Router Type: 4G (CAT4 LTE) Compatible Speeds: 4G up to 150Mbps Wi-Fi: MU-MIMO - 802.11.b/g/n - 2.4GHz Connection Devices: Up to 50 Dimensions:...
Page 39: Certification And Environment
UK PSTI Statement of Compliance Maxview Ltd. hereby declare that this equipment is compliant with Schedule 1 of The Product Security and Telecommunications Infrastructure (Security Requirements for Relevant Connectable Products) Regulations 2023. The statement of compliance is prepared by the manufacturer.
Page 40 The Maxview Roam Basecamp system uses a TELTONIKA NETWORKS UAB RUT200 LTE router. Used Frequency Range of Built-In RF Module: Band UL f, MHz DL f, MHz GSM900 880-915 925-960 GSM1800 1710-1785 1805-1880 WCDMA 1920-1980 2100-2170 880-915 925-960 1920-1980 2110-2170...
