Rage RC HERO-COPTER MILITARY EDITION Instruction Manual

Hide thumbs

Advertisement

Table of Contents

INSTRUCTION MANUAL
Specifications
Height
Total Length
Weight (with battery)
Total Rotor Width
Battery
Main Motor
Tail Motor
Charger
Transmitter.
Flight Time
Charge Time
3.66" (93mm)
9.45" (240mm)
3.5 oz. (99g)
10.1" (256mm)
7.4V 2S 350mAh LiPo
1023 Coreless
0720 Coreless
USB cord
4-channel, 2.4GHz
Up to 12 minutes
Approximately 60 min.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HERO-COPTER MILITARY EDITION and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rage RC HERO-COPTER MILITARY EDITION

Summary of Contents for Rage RC HERO-COPTER MILITARY EDITION

  • Page 1 INSTRUCTION MANUAL Specifications Height 3.66” (93mm) Total Length 9.45" (240mm) Weight (with battery) 3.5 oz. (99g) Total Rotor Width 10.1” (256mm) Battery 7.4V 2S 350mAh LiPo Main Motor 1023 Coreless Tail Motor 0720 Coreless Charger USB cord Transmitter. 4-channel, 2.4GHz Flight Time Up to 12 minutes Charge Time...
  • Page 2 The Hero-Copter Military Edition is the next Rage RC helicopter that takes the ease of flying a micro heli to a whole new level. This new scale-like heli is equipped with all the features that make RC drones easy to fly, such as 6-axis flight control, auto take-off and land, altitude hold, plus three flight modes (beginner, intermediate, and advanced) that make it fun to fly for pilots of all skill levels.

  • Page 3: Battery Safety Precautions

    Important Notes, Safety Precautions, and Warnings The manual includes safety information and instructions for the operation and maintenance of this aircraft. Please read the entire manual to understand the functions of this aircraft before any operation. Potential damage to the product and personal injury may occur if the product is not operated correctly.
  • Page 4 Functions Power On LED Auto Take-off and Auto Land 3-Speed Switch Hold for 3 seconds for (Low, Medium, and High) emergency stop On/Off switch Throttle/ Rudder Control Aileron/Elevator Control No function Aileron Trim Trim Rudder Elevator Trim Basic Parts Identification Swashplate Blade Grip Rotor head...

  • Page 5: Charging Instructions

    Charging Instructions The charging process is completed by plugging the USB connector into a power source, such as a USB port on a computer, a USB adapter into an AC power outlet, or a portable power bank. With all 3 power sources, follow the steps listed below: Connect the USB charge cord to the USB port on the power source.

  • Page 6: Flight Controls

    Flight Controls Descend...
  • Page 7 Binding and Flight Instructions Turn On 1. Connect the battery as shown in the diagram. Simply slide the battery into the socket until you feel it lock into place. 2. Once the battery is secured in place, turn on the aircraft by pushing the button in the center of Then turn on the power to the the battery.
  • Page 8 Trimming Instructions The aircraft was set up at the factory for a steady hover. However, if you find that you need to make minor adjustments to maintain a steady hover, the trim buttons can be used as shown in the diagrams w.

  • Page 9: Troubleshooting Guide

    Trouble Shooting Guide The lights on the aircraft and Review step #2 on page 7 of The aircraft has not been transmitter continue to blink the manual and repeat the bound to the transmitter. and the aircraft will not binding process. respond to controls.

  • Page 10: Exploded View & Part List

    Exploded View Part List HM1.6*9 PWM1.7*6 ST1.4*4PB RGR6123 Army RGR6124 Marines RGR6125 Navy ST1.4*4PB ST1.4*4PB ST1.4*4PB 3*6*2.5 ST1.4*4PB PM1.4*6 7.4V 350mAh ST1.7*5PB Part Number Description Part Number Description RGR6060 Main Blade Set (4) RGR6068 Main Gear Complete Screw Set RGR6117 RGR6075 2S 350mAh LiPo Battery Blade Grips w/ Screws...
  • Page 11 Replacing Basic Parts To remove a damaged rotor blade, use the correct size hex wrench on the screw. When installing the new blade, make sure not to over-tighten. To change the main gear, first remove the screw. To change the main motor, unplug the original motor Next, pull directly down on the main gear to remove.

  • Page 12: Warranty

    Warranty Warranty Period: Rage R/C warrants that the Hero-Copter (“Product”) will be free from original factory defects in materials and workmanship upon purchase (“Warranty Period”). What is Not Covered - This warranty is not transferable and does not cover (a) cosmetic damage, (b) damage due to acts of God, accident, misuse, abuse, negligence, commercial part of the Product, (d) attempted service by anyone other than a Rage R/C authorized service center, or (e) Product not purchased from an authorized Rage R/C dealer.
