Specifications
Hull Length:
Overall Length:
Hull Height:
Hull Width:
Motor:
ESC:
Transmitter and Receiver:
Servo:
Weight:
Battery:
INSTRUCTION MANUAL
INSTRUCTION MANUAL
32-3/4" (830mm)
36-3/4" (930mm)
7-3/4" (195mm)
3720/1800kV Water-Cooled BL Motor
60A Water-Cooled Brushless-Forward Only
2-channel, 2.4GHz
40g Waterproof
40.6 oz. (1150g) Without Battery
For optimal balance and performance, use two 2S LiPo
battery packs with XT60 connectors and minimum
rating of 4000mAh 25C
6-1/4" (158mm)
Advertisement
Table of Contents
Related Manuals for Rage RC VELOCITY 900BL
Summary of Contents for Rage RC VELOCITY 900BL
- Page 1 INSTRUCTION MANUAL INSTRUCTION MANUAL Specifications Hull Length: 32-3/4” (830mm) Overall Length: 36-3/4” (930mm) Hull Height: 6-1/4” (158mm) Hull Width: 7-3/4” (195mm) 3720/1800kV Water-Cooled BL Motor Motor: 60A Water-Cooled Brushless-Forward Only ESC: 2-channel, 2.4GHz Transmitter and Receiver: 40g Waterproof Servo: 40.6 oz. (1150g) Without Battery Weight: For optimal balance and performance, use two 2S LiPo Battery:...
-
Page 2: Table Of Contents
Overview The Velocity 900BL is Rage RC’s biggest and fastest boat to date! Reaching speeds of over 45mph (72km/h), this offshore speed demon is powered by a brushless water-cooled 1800kV motor and is equipped with a 60A water-cooled electronic speed control. The Velocity 900BL also features a durable uni-body ABS hull that arrives pre-painted with a unique matte orange finish and bold, aggressive graphics that give the Velocity 900 a fast, sleek design that looks the part whether speeding across your local lake or sitting proudly on the shelf. -
Page 3: Quick Start Guide
Quick Start Guide If you’re an experienced RC driver, this list will give you all the information you need to get started driving your new boat as quickly as possible. If this is your first RC vehicle, it is strongly recommended that you read the ENTIRE manual before you attempt to operate your new boat. -
Page 4: Safety Precautions
Please make sure you read the entire instruction manual to become familiar with the features of the Velocity 900BL before operating. Failure to operate this product correctly can result in damage to the product or personal property – and even cause serious injury. -
Page 5: Battery Safety Precautions
• LiPo cells should not be discharged to below 3.0V each. In the case of the 4-cell, 14.8V battery recommended for the Velocity 900BL you should not allow the voltage to fall below 12.0V during operation. -
Page 6: Rudder Installation
Rudder Installation Rudder H2.5 Hex Wrench H2 Hex Wrench The rudder for the Velocity 900BL To get started put the rudder into Secure the rudder to the mount by arrives unassembled in a separate place on the bracket mount as using the H2.5 hex wrench to... -
Page 7: Battery Installation
Battery Installation The Velocity 900BL is wired so that you have two options for power. You can use either one 4S pack or two 2S packs. When using a single 4S pack the supplied jumper plug must be plugged into one of the leads. -
Page 8: On/Off Switch
Transmitter Functions Steering Dual Rates No Function Antenna Throttle Dual Rates Power Switch Indicator LED Steering Reverse Steering Wheel Steering Trim Throttle Trigger On/OFF Switch Battery LED Monitor Slide the switch up for ON and down for OFF Flashing red:... -
Page 9: Dual-Rate Functions
Dual-Rate Functions Adjust the steering control by pressing the switch to the left or to the right. Press the switch to the right for Steering Dual Rate more steering control and to the left for less steering Throttle Dual Rate control (beginner setting). -
Page 10: Throttle Control
Throttle Control With the Velocity 900BL, there is no need to arm the motor. Simply squeeze the trigger in, or towards the driver for the boat to move forward. Right Forward Left Steering Control Rotate the steering wheel to the left, or counterclock- Rotate the steering wheel to the right, or clockwise wise to turn the boat to the left. -
Page 11: Checking The Radio System And Getting Started
Checking the Radio System and Getting Started 1. Power on the transmitter by turning on the switch on the left top end. 2. Connect a fully charged battery by plugging it into the ESC inside the hull. 3. Before placing the boat in the water, test the control of the transmitter by using the throttle “trigger”... -
Page 12: When Finsihed Running
When Finsihed Running allow Boat Maintenance... -
Page 13: Self-Righting Operation
Running the boat in salt water could cause some parts to corrode. If you run the NOTICE boat in salt water, make sure it is rinsed thoroughly in fresh water after each use and lubri- cate the drive system. Because of the corrosive effects, running the boat in salt water is at the discretion of the owner and will void the boat’s warranty. -
Page 14: Troubleshooting
Troubleshooting remove close to... -
Page 15: Replacement Parts List
Replacement Parts List See your local hobby shop or place of purchase first. If unavailable, parts can be ordered directly on-line at www.ragerc.com, or call 1-866-724-3811 M-F 9:00am-5:00pm Mountain Time. RGRB1209 Velocity 900BL RTR Boat RGRB1236B 2.4Ghz Receiver RGRB1249 Stainless Motor Mount... -
Page 16: Limited Warranty
Limited Warranty Warranty Period: Rage R/C warrants that the Velocity 900BL (“Product”) will be free from original factory defects in materials and workmanship upon purchase (“Warranty Period”). What is Not Covered - This warranty is not transferable and does not cover (a) cosmetic damage, (b) damage... -
Page 17: Operating And Maintenance Notes
Operating and Maintenance Notes:... - Page 18 © HRP Distributing, Inc. Printed 05/2024...
