Welcome to Hiwatt.
Proudly producing generations of Iconic British Tone
for the World's best artists. Legendary headroom, clean
and clear sounds, great for pedals and studio work,
AMPLIFIER FEATURES*
•Classic Hiwatt 'Tube Ampli er' with switchable power
40 Watt/20 Watt
•2x ECC83 + 1x ECC82 British Tubes in the preamp and
4x EL84 British Tubes in the power stage.
•3-band EQ plus push/pull 'Tone Shift' (MIDDLE control) for
maximum tone versatility.
•Custom Hiwatt Octapulse12-100 Loudspeaker,
speci cally voiced for this amp. (100W power rating).
•Real Spring Reverb.
•Auxiliary in great for small gigs and practice.
unbeatable live onstage.
Hiwatt.co.uk
Advertisement
Related Manuals for HIWATT T40/20 COMBO
Summary of Contents for HIWATT T40/20 COMBO
- Page 1 AMPLIFIER FEATURES* •Classic Hiwatt ‘Tube Ampli er’ with switchable power 40 Watt/20 Watt •2x ECC83 + 1x ECC82 British Tubes in the preamp and 4x EL84 British Tubes in the power stage.
- Page 2 • Never attempt to by-pass fuses or t ones provided with your ampli er. If a of incorrect value. replacement is needed, please contact your Hiwatt Dealer. • Never use an ampli er in wet or damp conditions. • Always unplug this ampli er during lightning storms or when unused for •...
-
Page 3: Front Panel Features
FRONT PANEL FEATURES Input - Plug your guitar in here with a 1/4” instrument cable Aux - Plug in an external audio device here with a 3.5mm jack Channel Select - Choose between Normal Gain and Overdrive Gain channels. The red LED indicates when the Overdrive Gain channel is selected. -
Page 4: Output Configurations
PEDALS LOVE HIWATT! “The sound of Hiwatt amps is bold, with plenty of headroom and bottom end. They are especially great platforms for a pedal based rig.” -Guitar A cionado Magazine, 2015 T40/20 INPUT NORMAL OVERDRIVE BASS MIDDLE TREBLE REVERB... - Page 5 ADDING AN EXTENSION SPEAKER CABINET LINE MAIN EXTENSION OUTPUT SEND RETURN FOOTSWITCH SPEAKER INPUT LINE LINE MAIN EXTENSION OUTPUT SEND RETURN FOOTSWITCH MAIN EXTENSION OUTPUT SEND RETURN FOOTSWITCH SPEAKER SPEAKER INPUT INPUT LINK INPUT INPUT LINK...
- Page 6 GETTING CREATIVE WITH TONES Crystal Clear Cleans • NORMAL GAIN set low • Cut BASS to tame low frequencies • Boost MIDDLE and TREBLE for more clarity • Set MASTER VOL anywhere from 3 o’clock to maximum INPUT NORMAL OVERDRIVE BASS MIDDLE TREBLE...
- Page 7 BRITISH ENGINEERING • Hiwatt ampli ers are warranted against defects in materials and worksmanship for a period of 1 year. • Speakers, transformers, reverb tank, batteries, and tubes/valves for 90 days. • Please note: It is your responsibility to use the equiptment safely and properly, without modi cations, within speci cations and with a safe power supply.
