I N S T A L L
G U I D E
Unpack box and make sure you have everything shown here.
1
What's what?
Important components labeled
Wiegand Terminals
For wiring to Wiegand device.
See Page 2.
Keypad Unit
Gasket
Keypad Unit
Back of unit shown
Slotted Screw
Security Screw
( 2x )
( 2x )
Reset Button
For performing unit reset
procedure
2
Prepare existing or install new
single-gang junction box to which
keypad unit will be mounted after
wiring and testing.
(Junction box is not included.)
L Key
Continued on next page...
AUTOMATIC GATES CAN CAUSE SERIOUS
ALWAYS CHECK THAT THE GATE PATH IS
CLEAR BEFORE OPERATING!
REVERSING OR OTHER SAFETY DEVICES
SHOULD ALWAYS BE USED!
1 of 4
12-000SGL
Model
WARN ING
INJURY OR DEATH!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Security Brands REMOTEPRO KP
Summary of Contents for Security Brands REMOTEPRO KP
- Page 1 1 of 4 I N S T A L L G U I D E 12-000SGL Model Unpack box and make sure you have everything shown here. Prepare existing or install new single-gang junction box to which keypad unit will be mounted after wiring and testing.
- Page 2 (can be changed) (4 or 5) Your system is ready to use. NOTE: Green arrow indicates “good” tone on keypad. NOTE: Green arrow indicates “good” tone on keypad. © 2024 Security Brands, Inc. All rights reserved. IG-12000SGL-EN-US Rev. A (4/2024)
- Page 3 3 of 4 I N S T A L L G U I D E Additional Programming 12-000SGL Model Change Master Code Unit Reset Procedure (For added security, changing the default Master Code is recommended.) This procedure is used to reset unit to factory default settings. Step 1 - Unscrew mounting screws with L Key and remove keypad unit from junction box.
- Page 4 I N S T A L L G U I D E 12-000SGL Model Notes RemotePro KP Model 12-000SGL Call (972) 474-6422 Email support@summitcontrol.com We are available Mon–Fri / 8am–5pm Central © 2024 Security Brands, Inc. All rights reserved. IG-12000SGL-EN-US Rev. A (4/2024)
