  • Page 1 Owner’s Manual Manual del Propietario Manuel d’utilisatio Benutzerhandbuch LX Amplifiers select language seleccione el idioma choisir la langue sprache auswählen...
  • Page 2: Table Of Contents

    Contents Overview ......4 LX Mono Specifications ......5 Installation ...... 7 Mounting ....... 7 Power Wiring ....... 10 Input Wiring ......13 Subwoofer Wiring ....14 Operation ..... 15 LXRC Installation ....22 LXRC Operation ....26 Troubleshooting .... 29 Garantía | Garantie ....
  • Page 3 Input Wiring ......37 Speaker Wiring ....38 Operation ..... 41 LXCC ........47 Troubleshooting .... 50 Garantía | Garantie .... LX Multi-Channel Specifications ...... 51 Installation ....52 Mounting ......52 Power Wiring ....... 55 Input Wiring ......58 Speaker Wiring ....
  • Page 4: Overview

    VENTILATION. SUBWOOFERS SHOULD BE MOUNTED WITH AT LEAST 1 INCH (2.5CM) CLEARANCE BETWEEN THE FRONT OF THE SPEAKER AND ANY SURFACE. KICKER PRODUCTS ARE CAPABLE OF PRODUCING SOUND LEVELS THAT CAN PERMANENTLY DAMAGE YOUR HEARING! TURNING UP A SYSTEM TO A LEVEL THAT HAS AUDIBLE DISTORTION IS MORE DAMAGING TO YOUR EARS THAN LISTENING TO AN UNDISTORTED SYSTEM AT THE SAME VOLUME LEVEL.
  • Page 5: Lx Mono

    LX Mono Specifications Model: LX850.1 LX1250.1 Dynamic Power [Watts] 1100W 1600W RMS Power Output [Watts] @ 14.4V, 4Ω mono, ≤ 1% THD+N 300W X 1 400W X 1 @ 14.4V, 2Ω mono, ≤ 1% THD+N 500W X 1 750W X 1 @ 14.4V, 1Ω...
  • Page 6 Low Level: 125mV–5V High Level: 1V–40V Note: All specifications and performance figures are subject to change. Please visit www.kicker.com for the most current information. To get the best performance from your new KICKER amplifier, we recommend using genuine KICKER speakers, accessories and wiring.
  • Page 7: Installation

    Installation Mounting Choose a structurally sound location to mount your KICKER amplifier. Make sure there are no items behind the area where the screws will be driven. Choose a location that allows at least 4” (10cm) of open ventilation for the amplifier. Drill four holes using a 7/64”...
  • Page 8 Remove and orient the magnetized KICKER plate and badge as needed. English...
  • Page 9 Remove the magnetized top panel cover to access the LX amplifier’s power distribution and speaker output terminals, as well as gain and LED accent lighting settings. English...
  • Page 10: Power Wiring

    The new extended warranty applies only to KICKER amplifiers and accessories sold to consumers by Authorized KICKER Dealers in the United States of America or its possessions. It also only applies to the original purchaser of KICKER amplifiers and accessories. One warranty extension per amplifier is allowed regardless of the number of amplifier installation kits purchased.
  • Page 11 KICKER Subwoofers, and a cables, and you’ll have an audio upgrade that will dominate any factory system! KICKER amplifiers make it easy to upgrade to solid bass with your existing or stock source unit. Ask your dealer about KICKER upgrades.
  • Page 12 For multiple amplifier installations where distribution blocks are used, each amplifier should have its proper-rated fuse, or breaker, installed between the amplifier and the distribution block within eighteen inches of the block, or on the distribution block if it provides for fusing. The primary power wire should also be fused between the battery and distribution block, within eighteen inches of the battery’s positive terminal, with...
  • Page 13: Input Wiring

    Input Wiring The LX-series are capable of receiving both Low-level signals with the RCA inputs and Hi-level signals with the Hi-Level Input wiring harness on the front panel of the amplifier. The LX Mono amplifiers also feature RCA Output to conveniently chain more LX amplifiers in your audio system.
  • Page 14: Subwoofer Wiring

    Subwoofer Wiring Single 2Ω Dual Voice Coil L7X Subwoofer wired in parallel. Final impedance of load must be a minimum of 1Ω. SUBSONIC X-OVER FREQ BANDWIDTH +12V SPEAKER KICK EQ+ PWR/ 10 Hz 80 40 Hz 160 20 Hz 80 HI-LEVEL REMOTE BASS INPUT...
  • Page 15: Operation

    Operation BASS GAIN BOOST +12V SPEAKER DC OFFSET GAIN 0 dB MATCH LO-PASS CENTER SUBSONIC X-OVER FREQ BANDWIDTH +12V SPEAKER KICK EQ+ PWR/ 10 Hz 80 40 Hz 160 20 Hz 80 HI-LEVEL REMOTE BASS INPUT INPUT OUTPUT Automatic Turn-On: The LX-series offers two different automatic turn-on modes;...
  • Page 16 GAIN MATCHING: In any audio system, the goal is to reach maximum input and output levels without distortion or clipping. The engineers at KICKER have taken the guesswork, and hassle, out of matching the output voltage of your source unit to the amplifier with the Gain Matching feature.
  • Page 17 2. Set all EQ and crossover settings to flat on your source unit. 3. Play the downloadable file from KICKER.com 4. Turn the source unit up to the maximum unclipped volume level. If you cannot accurately determine this, ¾ volume is a good starting point.
  • Page 18 Sine wave tracks can be downloaded for free from KICKER.com under the “Support” tab. Use the 50Hz sine wave to set the gain for a subwoofer and the 1kHz sine wave for full-range speakers.
  • Page 19 When the desired voltage is shown (reference power chart at KICKER.com), or you start to see the waveform square off stop increasing the gain, turn the amplifier off, reconnect all speakers and set the crossovers to your desired setting. Your gain is now set for maximum unclipped power from the amplifier.
  • Page 20 Factory Reset: Remove the top panel cover to access the Factory Reset button. To restore factory settings, press and hold the Factory Reset button for 10 seconds. Turn the amplifier off and back on by cycling the ignition. Factory Reset - Press & Hold for 10 seconds WARNING: Factory reset will reset all settings that are controlled by LXCC to factory (including crossover)
  • Page 21 BASS GAIN BOOST DC OF GAIN 0 dB MATCH LO-PASS CENTER SUBSONIC X-OVER FREQ BANDWIDTH KICK EQ+ 10 Hz 80 40 Hz 160 20 Hz 80 KICK EQ Parametric Bass Boost: The BASS BOOST may be set from 0dB– 6dB. Use the FREQ setting to adjust the I-LEVEL REMOT INPUT...
  • Page 22: Lxrc Installation

    LX amplifier, with access to LED lighting changes, real-time battery input voltage monitoring, clip output indication, and KICKER’s proprietary SHOCwave 2.0 (Sub-Harmonic Octave Creation) algorithm. Connect the supplied RJ-45 cable from the back of the LXRC to the Remote Bass jack of the LX amplifier.
  • Page 23 Surface Mounting: To surface mount the LXRC, place the LXRC against a surface and secure the mounting bracket using the supplied screws. English...
  • Page 24 Flush Mounting: To flush mount the LXRC behind a mounting surface, begin by cutting a 1-inch diameter hole in the mounting surface, being careful not to drill through existing wiring or mechanisms. Remove the LXRC front mounting nut and mounting bracket. Adjust the rear mounting nut forward to set the protrusion of the LXRC knob.
  • Page 25 Place the LXRC through the mounting hole, then reattach the front mounting nut to secure the remote against the mounting surface. Connect the LXRC to the Remote Bass jack of the LX amplifier. English...
  • Page 26: Lxrc Operation

    LXRC Operation The LXRC serves as both a rotary knob for precise adjustments and as a multi-function push-button to change modes, with an illuminated LED ring to display the current setting. You may cycle through most modes by pressing and holding the button for <3 seconds (short-press).
  • Page 27 Gain (Remote Level): The LXRC gain control is a gain attenuator from -26dB to 0dB. This will allow you to conveniently adjust the gain of the subwoofer channel on the fly, with the maximum being the gain setting you’ve selected on the LX amplifier top panel.
  • Page 28 Clip: The CLIP display serves as a global clip indicator to show when a clipped output signal is detected. If you change your Gain or SHOCwave setting, you may notice the CLIP LED become active. This means your new DSP settings have caused an output to clip and you should reduce the gain or compensate in some other way.
  • Page 29: Troubleshooting

    There are Power (PWR) & Protection (PRT) LEDs on the side panel of your KICKER LX series amplifier. Depending on the state of the amplifier and the vehicle’s charging system, the LEDs will glow either green or red. When the green LED is lit, this indicates the amplifier is turned on and no trouble exists.
  • Page 30: Lx Stereo

    Low Level: 125mV–5V High Level: 1V–40V Note: All specifications and performance figures are subject to change. Please visit www.kicker.com for the most current information. To get the best performance from your new KICKER amplifier, we recommend using genuine KICKER speakers, accessories and wiring.
  • Page 31: Installation

    Installation Mounting Choose a structurally sound location to mount your KICKER amplifier. Make sure there are no items behind the area where the screws will be driven. Choose a location that allows at least 4” (10cm) of open ventilation for the amplifier. Drill four holes using a 7/64”...
  • Page 32 Remove and orient the magnetized KICKER plate and badge as needed. English...
  • Page 33 Remove the magnetized top panel cover to access the LX amplifier’s power distribution and speaker output terminals, as well as gain and LED accent lighting settings. English...
  • Page 34: Power Wiring

    The new extended warranty applies only to KICKER amplifiers and accessories sold to consumers by Authorized KICKER Dealers in the United States of America or its possessions. It also only applies to the original purchaser of KICKER amplifiers and accessories. One warranty extension per amplifier is allowed regardless of the number of amplifier installation kits purchased.
  • Page 35 KICKER amplifiers make it easy to upgrade to solid bass with your existing or stock source unit. Ask your dealer about KICKER upgrades. English...
  • Page 36 For multiple amplifier installations where distribution blocks are used, each amplifier should have its proper-rated fuse, or breaker, installed between the amplifier and the distribution block within eighteen inches of the block, or on the distribution block if it provides for fusing. The primary power wire should also be fused between the battery and distribution block, within eighteen inches of the battery’s positive terminal, with...
  • Page 37: Input Wiring

    Input Wiring The LX-series are capable of receiving both Low-level signals with the RCA inputs and Hi-level signals with the Hi-Level Input wiring harness on the front panel of the amplifier. PWR/ PWR/ HI-LEVEL HI-LEVEL AMP1 AMP1 AMP2 AMP2 OUTPUT OUTPUT INPUT INPUT...
  • Page 38: Speaker Wiring

    Speaker Wiring Stereo Operation English...
  • Page 39 Stereo & Bridged Operation Both stereo amplifier outputs (AMP1 & AMP2) are capable of bridged mono output. Please refer to the RMS Power Output in the specifications for bridged output power relative to impedance. Use the LEFT+ and RIGHT– terminals of the desired amplifier output to be bridged.
  • Page 40 Bi-Amplification Bi-Amplification dedicates stereo amplifier channels to specific frequency ranges to increase efficiency and headroom, greatly improving audio quality. As an example, you can use one stereo output for tweeters, and another stereo output for your mids. English...
  • Page 41: Operation

    Operation AMP1 AMP1 AMP2 AMP2 GAIN GAIN GAIN GAIN AMP1 AMP2 +12V +12V DC OFFSET DC OFFSET GAIN GAIN GAIN GAIN MATCH MATCH MATCH MATCH +12V +12V BRIDGED (L+ AND R-) PWR/ PWR/ FADER FADER HI-LEVEL HI-LEVEL CONTROLLER AMP1 AMP1 AMP2 AMP2 OUTPUT...
  • Page 42 GAIN MATCHING: In any audio system, the goal is to reach maximum input and output levels without distortion or clipping. The engineers at KICKER have taken the guesswork, and hassle, out of matching the output voltage of your source unit to the amplifier with the Gain Matching feature.
  • Page 43 2. Set all EQ and crossover settings to flat on your source unit. 3. Play the downloadable file from KICKER.com 4. Turn the source unit up to the maximum unclipped volume level. If you cannot accurately determine this, ¾ volume is a good starting point.
  • Page 44 Sine wave tracks can be downloaded for free from KICKER.com under the “Support” tab. Use the 50Hz sine wave to set the gain for a subwoofer and the 1kHz sine wave for full-range speakers.
  • Page 45 When the desired voltage is shown (reference power chart at KICKER.com), or you start to see the waveform square off stop increasing the gain, turn the amplifier off, reconnect all speakers and set the crossovers to your desired setting. Your gain is now set for maximum unclipped power from the amplifier.
  • Page 46 Factory Reset: Remove the top panel cover to access the Factory Reset button. To restore factory settings, press and hold the Factory Reset button for 10 seconds. Turn the amplifier off and back on by cycling the ignition. Factory Reset - Press & Hold for 10 seconds WARNING: Factory reset will reset all settings that are controlled by LXCC to factory (including crossover)
  • Page 47: Lxcc

    LXCC The LXCC is a Control Center that grants access to the expanded DSP functions of the LX amplifier, allowing you to fine-tune your LX with ease. Once your LX amplifier has been installed, begin by connecting the RJ-45 cable of the LXCC to the Controller/Remote Bass input of the LX amplifier.
  • Page 48 GAIN TRIM: Push the Gain Trim knob to open Gain Trim settings. Push the knob again or the Amp Select button to select the amplifier channel being modified. You can cut by -9dB or boost by +3dB per amplified section (AMP1 & AMP2). This allows you to make minor adjustments to levels, helping to match outputs, such as cutting your tweeter channels, while boosting the mids.
  • Page 49 Use the knobs to set your crossover points, between 20Hz–5kHz HP/BP and 40Hz– 5kHz LP for full-range channels. X-OVER TYPE: Select the amplifier channel for which you’d like to change the crossover type. Press the X-OVER TYPE button to choose Linkwitz-Riley or Butterworth.
  • Page 50: Troubleshooting

    There are Power (PWR) & Protection (PRT) LEDs on the side panel of your KICKER LX series amplifier. Depending on the state of the amplifier and the vehicle’s charging system, the LEDs will glow either green or red. When the green LED is lit, this indicates the amplifier is turned on and no trouble exists.
  • Page 51: Lx Multi-Channel

    Low Level: 125mV–5V High Level: 1V–40V Note: All specifications and performance figures are subject to change. Please visit www.kicker.com for the most current information. To get the best performance from your new KICKER amplifier, we recommend using genuine KICKER speakers, accessories and wiring.
  • Page 52: Installation

    Installation Mounting Choose a structurally sound location to mount your KICKER amplifier. Make sure there are no items behind the area where the screws will be driven. Choose a location that allows at least 4” (10cm) of open ventilation for the amplifier. Drill four holes using a 7/64”...
  • Page 53 Remove and orient the magnetized KICKER plate and badge as needed. English...
  • Page 54 Remove the magnetized top panel cover to access the LX amplifier’s power distribution and speaker output terminals, as well as gain and LED accent lighting settings. English...
  • Page 55: Power Wiring

    The new extended warranty applies only to KICKER amplifiers and accessories sold to consumers by Authorized KICKER Dealers in the United States of America or its possessions. It also only applies to the original purchaser of KICKER amplifiers and accessories. One warranty extension per amplifier is allowed regardless of the number of amplifier installation kits purchased.
  • Page 56 KICKER amplifiers make it easy to upgrade to solid bass with your existing or stock source unit. Ask your dealer about KICKER upgrades. English...
  • Page 57 For multiple amplifier installations where distribution blocks are used, each amplifier should have its proper-rated fuse, or breaker, installed between the amplifier and the distribution block within eighteen inches of the block, or on the distribution block if it provides for fusing. The primary power wire should also be fused between the battery and distribution block, within eighteen inches of the battery’s positive terminal, with...
  • Page 58: Input Wiring

    Input Wiring The LX-series are capable of receiving both Low-level signals with the RCA inputs and Hi-level signals with the Hi-Level Input wiring harness on the front panel of the amplifier. PWR/ HI-LEVEL AMP1 AMP2 AMP3 INPUT The input channel corresponding to the wiring harness colors are: LX1200.5 AMP1 Left: White, White/Black...
  • Page 59 LX1300.7 AMP1 Left: White, White/Black AMP1 Right: Grey, Grey/Black AMP2 Left: Green, Green/Black AMP2 Right: Purple, Purple Black AMP3 Left: White, White/Black AMP3 Right: Grey, Grey/Black SUB Left: Green, Green/Black SUB Right: Purple, Purple Black English...
  • Page 60: Speaker Wiring

    Speaker Wiring Stereo & Sub Operation English...
  • Page 61 Stereo, Sub & Bridged Operation All stereo amplifier outputs (AMP1, AMP2 & AMP3) are capable of bridged mono output. Please refer to the RMS Power Output in the specifications for bridged output power relative to impedance. Use the LEFT+ and RIGHT – terminals of the desired amplifier output to be bridged.
  • Page 62 Bi-Amplification with Bridged Subwoofer Bi-Amplification and tri-amplification dedicate stereo amplifier channels to specific frequency ranges to increase efficiency and headroom, greatly improving audio quality. As an example, you can use one stereo output for tweeters, and another stereo output for your mids. English...
  • Page 63 Tri-Amplification (LX1300.7 only) As an example, the diagram below shows a tri-amplification wiring configuration using KICKER KSS693 Component Speakers, including a 6”x9”, 2-3/4” mid, and 1” tweeter. English...
  • Page 64: Operation

    Operation AMP1 AMP2 AMP3 GAIN GAIN GAIN GAIN AMP1 AMP2 AMP3 +12V DC OFFSET GAIN GAIN GAIN GAIN MATCH MATCH MATCH MATCH BRIDGED (L+ AND R-) PWR/ AMP2 AMP3 INPUT INPUT INPUT AMP1 AMP2 AMP3 CONTROLLER/ HI-LEVEL AMP2 AMP3 AMP1 AMP2 AMP3 REMOTE BASS...
  • Page 65 GAIN MATCHING: In any audio system, the goal is to reach maximum input and output levels without distortion or clipping. The engineers at KICKER have taken the guesswork, and hassle, out of matching the output voltage of your source unit to the amplifier with the Gain Matching feature.
  • Page 66 2. Set all EQ and crossover settings to flat on your source unit. 3. Play the downloadable file from KICKER.com 4. Turn the source unit up to the maximum unclipped volume level. If you cannot accurately determine this, ¾ volume is a good starting point.
  • Page 67 Sine wave tracks can be downloaded for free from KICKER.com under the “Support” tab. Use the 50Hz sine wave to set the gain for a subwoofer and the 1kHz sine wave for full-range speakers.
  • Page 68 When the desired voltage is shown (reference power chart at KICKER.com), or you start to see the waveform square off stop increasing the gain, turn the amplifier off, reconnect all speakers and set the crossovers to your desired setting. Your gain is now set for maximum unclipped power from the amplifier.
  • Page 69 Factory Reset: Remove the top panel cover to access the Factory Reset button. To restore factory settings, press and hold the Factory Reset button for 10 seconds. Turn the amplifier off and back on by cycling the ignition. Factory Reset - Press & Hold for 10 seconds WARNING: Factory reset will reset all settings that are controlled by LXCC to factory (including crossover)
  • Page 70: Lxcc

    LXCC The LXCC is a Control Center that grants access to the expanded DSP functions of the LX amplifier, allowing you to fine-tune your LX with ease. Once your LX amplifier has been installed, begin by connecting the RJ-45 cable of the LXCC to the Controller/Remote Bass input of the LX amplifier.
  • Page 71 GAIN TRIM: Push the Gain Trim knob to open Gain Trim settings. Push the knob again or the Amp Select button to select the amplifier channel being modified. You can cut by -9dB or boost by +3dB per amplified section (AMP1, AMP2, AMP3, & SUB). This allows you to make minor adjustments to levels, helping to match outputs, such as cutting your tweeter channels, while...
  • Page 72 Use the knobs to set your crossover points, between 20Hz–5kHz HP/BP and 40Hz– 5kHz LP for full-range channels, or 10Hz– 160Hz for a subwoofer channel. Using a Hi-Pass filter on a subwoofer channel will engage the subsonic filter. X-OVER TYPE: Select the amplifier channel for which you’d like to change the crossover type.
  • Page 73 KICK EQ Parametric Bass Boost: When the subwoofer channel is selected, the TIME DELAY knob will instead become a KICK EQ Parametric Bass Boost for the subwoofer channel. This boost is independent of the GAIN TRIM setting, and may be set from 0dB–6dB. Press the knob to set the amount of boost.
  • Page 74: Lxrc Installation

    LX amplifier, with access to LED lighting changes, real-time battery input voltage monitoring, clip output indication, and KICKER’s proprietary SHOCwave 2.0 (Sub-Harmonic Octave Creation) algorithm. Disconnect the supplied RJ-45 cable used to fine-tune with the LXCC, then connect from the back of the LXRC to the Remote Bass jack of the LX amplifier.
  • Page 75 Surface Mounting: To surface mount the LXRC, place the LXRC against a surface and secure the mounting bracket using the supplied screws. English...
  • Page 76 Flush Mounting: To flush mount the LXRC behind a mounting surface, begin by cutting a 1-inch diameter hole in the mounting surface, being careful not to drill through existing wiring or mechanisms. Remove the LXRC front mounting nut and mounting bracket. Adjust the rear mounting nut forward to set the protrusion of the LXRC knob.
  • Page 77 Place the LXRC through the mounting hole, then reattach the front mounting nut to secure the remote against the mounting surface. Connect the LXRC to the Remote Bass jack of the LX amplifier. English...
  • Page 78: Lxrc Operation

    LXRC Operation The LXRC serves as both a rotary knob for precise adjustments and as a multi-function push-button to change modes, with an illuminated LED ring to display the current setting. You may cycle through most modes by pressing and holding the button for <3 seconds (short-press).
  • Page 79 Gain (Remote Level): The LXRC gain control is a gain attenuator from -26dB to 0dB. This will allow you to conveniently adjust the gain of the subwoofer channel on the fly, with the maximum being the gain setting you’ve selected on the LX amplifier top panel.
  • Page 80 Clip: The CLIP display serves as a global clip indicator to show when a clipped output signal is detected. If you change your Gain or SHOCwave setting, you may notice the CLIP LED become active. This means your new DSP settings have caused an output to clip and you should reduce the gain or compensate in some other way.
  • Page 81: Troubleshooting

    There are Power (PWR) & Protection (PRT) LEDs on the side panel of your KICKER LX series amplifier. Depending on the state of the amplifier and the vehicle’s charging system, the LEDs will glow either green or red. When the green LED is lit, this indicates the amplifier is turned on and no trouble exists.
  • Page 82 Service performed by anyone other than KICKER HOW LONG WILL IT TAKE? KICKER strives to maintain a goal of one week turnaround for all electronics (amplifiers, crossovers, equalizers, etc.) returns. Delays may be incurred if lack of replacement inventory or parts is encountered.
  • Page 83: Garantía | Garantie

    (“a todo volumen”) en todo sentido. La línea de altavoces y amplificadores KICKER es la mejor del mercado de audio de automóviles y por lo tanto representa el “combustible” para vivir a todo volumen en el área de “estéreos de automóvil” de la vida de nuestros clientes.
