Intellimeter IM3 Installation Instructions

INTELLIMETER SINGLE CHANNEL SOLID STATE kWh METER FOR
SUBMETERING
P R O D U C T C O D E : I M 3
INSTALLATION INSTRUCTIONS
Prior to commencing the installation of the
Intellimeter IM3 please note that it is intended to be
connected by a qualified electrical professional as
per the codes and laws of the local governing
entities. Please ensure that all related circuits are
de-energized before beginning the installation or
working on the internal connections and take the
time to read the installation instructions as well as
plan out all of the appropriate connections. If the
device is used, mounted or connected in a manner
that is not specified by Intellimeter or local
electrical code, the protection provided by the
equipment may be impaired.
MARKINGS
Indicates danger of an electric shock
hazard, make sure all related circuits are
DANGER de-energized before proceeding.
ELECTRIC SHOCK RISK
Please consult manual before opening enclosure and ensure that all circuits are de-energized
before handling
If ambient temperature of the installation environment under normal conditions reaches more than
40° C(104° F), please ensure that the wire being used is rated for at least 60° C(140° F)
MOUNTING AND DRILLING
The meter should be installed in an adequately ventilated area(as per the temperature ratings) near the
breaker or switch being used for the supply lines that connect to the Voltage terminal leads. Please ensure
that the breaker or switch is appropriately labeled and the mounted enclosure does not impede its
operation. The wire being used must be the appropriate gauge as per the rating of the breaker (15A or 20A
recommended) being used according to code or the breaker manufacturer. There is an optional mounting
kit and 4 optional colored conductors supplied in the enclosure for the ease of using a twist-on wire
connector.
• If replacing or extending the attached conductors, please ensure that the alternate or added conductor is
also certified as per local electrical code requirements.
• If cutting or drilling the wire feedthroughs on site, please ensure that the hardware and installation
methods being used are certified as per local electrical code requirements.
www.intellimeter.on.ca +1.905.839.9199
CONFORMS TO: CSA-C22.2
No 61010-1-12:2012,
UL61010-1 (EDITION 3): 2012
k W h
MODEL IM3
SERVICE TYPE 1/3 PHASE 2/3/4 WIRE
RATED VOLTAGE 120/208/240
RATED FREQUENCY 60Hz
CURRENT ELEMENT (EL) 1,2,3
TEMP RANGE -20 TO 50° C, 0 TO 120° F
METER PULSE WEIGHT
1 kWh
OPERATING POWER
17 VA
SERIAL #
1600002
FIRMWARE #
13
CT RATIO
2000:1
