- Page 1 I-METER MF SERIES ® INSTALLATION AND USER MANUAL Page 1 Intellimeter Canada Inc. 1125 Squires Beach Road, Pickering, ON, L1W 3T9 • Tel: (905) 839-9199 Copyright 2020 © MF Series Manual...
-
Page 2: Table Of Contents
7. i-meter® MF SERIES COMMUNICATION ........................13 7.1 ModBus Module Connection……………………………………………………………………………………………………………………… 13 7.2 i-meter® ModBus RTU Registers Mapping………………………………………………………………………………………………….. 14 Page 2 Intellimeter Canada Inc. 1125 Squires Beach Road, Pickering, ON, L1W 3T9 • Tel: (905) 839-9199 Copyright 2020 © MF Series Manual... - Page 3 Make sure you have received the right meter as per your order and packing list. INSTALLATION DISCLAIMER INTELLIMETER does not accept any responsibility and will not be liable for any loss or damage or expense of any kind whatsoever and howsoever caused by improper installation of its products, be it indirect, special, incidental or consequential damages (including but not limited to damages for loss of business, loss of profits, interruption or the like).
-
Page 4: Product Description
The i-meter®MF3 is configured for 1 point of metering The i-meter®MF6 is configured for 2 points of metering Note: Any changes to the original configuration will need to be coordinated with Intellimeter Canada Page 4 Intellimeter Canada Inc. -
Page 5: Specifications
U.S. Patent No. 8,049,487 All instantaneous measurements and interval data must be with a wired/wireless communication module. Page 5 Intellimeter Canada Inc. 1125 Squires Beach Road, Pickering, ON, L1W 3T9 • Tel: (905) 839-9199 Copyright 2020 © MF Series Manual... -
Page 6: Installation
Referring to the diagram below, CTs can be embedded in the distribution panel. If the customer has supplied a special compartment for the meter with their electrical panel, Intellimeter will install the meter and have the SPE-1000 field evaluation completed. Otherwise, the meter will be installed in an external enclosure to be mounted near the electrical panel for ease of servicing. -
Page 7: Operation And Trouble Shooting
The arrow on the CT indicates the direction from LINE to LOAD. Similarly, the “H1” is on the LINE SIDE. All Intellimeter milli-Amp current transformers 100:0.8A, 200:0.1A, 400:0.1A and 600:0.1A have self-shorting protection built into the device. They can safely be open circuited while under load. - Page 8 Note: Colour sequence may vary depending on the country and region. Rule #3: When the metering system is tested at Intellimeter’s factory, the CT’s are assigned to a meter and to a specific element of that meter. The CTs are recommended to be installed and used only with the meter and element that they have been tested with.
-
Page 9: Steps To Operate The Meter
Step 2: Connect all CTs to CT Inputs according to Figures below; Step 3: Power the meter ® i-meter MF3 wiring diagram Page 9 Intellimeter Canada Inc. 1125 Squires Beach Road, Pickering, ON, L1W 3T9 • Tel: (905) 839-9199 Copyright 2020 © MF Series Manual... - Page 10 ® i-meter MF6 series wiring diagram Page 10 Intellimeter Canada Inc. 1125 Squires Beach Road, Pickering, ON, L1W 3T9 • Tel: (905) 839-9199 Copyright 2020 © MF Series Manual...
-
Page 11: Configuration
1 2 3 L2 L3 k VAh 1 2 3 L1 L2 L3 0 0 0 L1 L2 L3 Page 11 Intellimeter Canada Inc. 1125 Squires Beach Road, Pickering, ON, L1W 3T9 • Tel: (905) 839-9199 Copyright 2020 © MF Series Manual... - Page 12 Line 2 – Phase B Current – System Frequency Line 3 – Phase C Current – System Frequency Page 12 Intellimeter Canada Inc. 1125 Squires Beach Road, Pickering, ON, L1W 3T9 • Tel: (905) 839-9199 Copyright 2020 MF Series Manual...
-
Page 13: I-Meter® Mf Series Communication
(8N1). The communication parameters and ModBus ID may be changed through the ModBus registers. 7.1 ModBus Module Connection RJ45 Connection Page 13 Intellimeter Canada Inc. 1125 Squires Beach Road, Pickering, ON, L1W 3T9 • Tel: (905) 839-9199 Copyright 2020 MF Series Manual... -
Page 14: I-Meter® Modbus Rtu Registers Mapping
57600 bps; 7 = 115200 bps. The Baud Rate takes effect after power cycling. Firmware Version: V4.64 (the same firmware as the i-45) Hardware Version: 101-1357 REV-A Page 14 Intellimeter Canada Inc. 1125 Squires Beach Road, Pickering, ON, L1W 3T9 • Tel: (905) 839-9199 Copyright 2020 MF Series Manual... - Page 15 1. Active Phases - 41100: 0x0001 - Meter uses phase A; 0x0002 - Note Meter uses phase B; 0x0004 - Meter uses phase C. Page 15 Intellimeter Canada Inc. 1125 Squires Beach Road, Pickering, ON, L1W 3T9 • Tel: (905) 839-9199 Copyright 2020 MF Series Manual...
- Page 16 Active Phases - 41100: 0x0001 - Meter uses phase A; 0x0002 - Note Meter uses phase B; 0x0004 - Meter uses phase C. Page 16 Intellimeter Canada Inc. 1125 Squires Beach Road, Pickering, ON, L1W 3T9 • Tel: (905) 839-9199 Copyright 2020 MF Series Manual...
- Page 17 , Meter 1) UINT16 0.01% 47001 THD (V , Meter 1) UINT16 0.01% Note The THD is for reference only Page 17 Intellimeter Canada Inc. 1125 Squires Beach Road, Pickering, ON, L1W 3T9 • Tel: (905) 839-9199 Copyright 2020 MF Series Manual...
- Page 18 Please visit us @ https://intellimeter.ca or call us @ 905-839-9199 if you need any further assistance Page 18 Intellimeter Canada Inc. 1125 Squires Beach Road, Pickering, ON, L1W 3T9 • Tel: (905) 839-9199 Copyright 2020 MF Series Manual...
