FUEL CADDY USER MANUAL
Model: JGC35W
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
Advertisement
Related Manuals for VEVOR JGC35W
Summary of Contents for VEVOR JGC35W
- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support FUEL CADDY USER MANUAL Model: JGC35W We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
- Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
- Page 3 1. Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. 2. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. GENERAL SAFETY RULES When using this product, basic precautions should always be followed, including the following;...
- Page 4 This product is intended for fuel transfer only and is not intended to be • used to transport fuel in any vehicle or trailer. Do not modify this product. • A WARNING! CAUTION! ATTENTION! Do not use this product for prop-longed fuel storage. •...
-
Page 5: Structure Diagram
MODEL AND PARAMETERS Model JGC35W Capacity 35 Gallons Fuel Type Diesel,Lubricating Oil，Machine Oil，Gasoline Pump Hand Max. Flow 15 L/100rpm Hose Φ19(Inside Diameter)xL250cm Wheel 2.5"(Front) ; 10"(Back) Material Steel Color Yellow STRUCTURE DIAGRAM 1. Handle 2. Hose 3. Pump 4. Oil gauge 5. - Page 6 COMPONENTS Picture Name and Qty Picture Name and Qty Fuel Tank(x1) Lock Nut(x1) Hose Handle (x1) Clamp(x1) Wheel (x2) Wheel shaft (x2) Oil Gauge Fixing Oil Hose (x1) Nut（x1） Swivel Caster Oil gauge (x1) (x2) Oil Pump and Hose Fitting(x1) handle (x1) Swivel Caster Flat Gasket(x2)
- Page 7 ASSEMBLY Step1：Install the fixed wheels. Screw the wheel shafts(12) into the fuel tank,then put the fixed wheels (3) into the wheel shafts and lock it with gaskets and nuts.(16+17) 16+17 Step2： Unscrew the nuts first,and then install the swivel caster Films(7) and the swivel casters(5),screw the nuts.
- Page 8 Step3：Screw the lock nut(10) into the oil outlet，Wrap not less than 5 circles of raw tape on the outlet, then screw the pump(6) on the outlet and adjust the orientation, and finally lock the pump with the lock nut. Remove the screw on the pump and install the grounding lead(9) on the pump with this screw.
- Page 9 Step5 ： Insert the handle(2) into the tank at the appropriate position, as shown. Step6：Wrap not less than 5 circles of raw tape on the hose fitting(15) and screw it to the pump outlet;then attach the oil hose (4) to the hose fitting(15) and lock it with a hose clamp (11).
-
Page 10: Operation And Maintenance
Step 8. The product is assembled and ready for use. OPERATION&MAINTENANCE 1. Connect the clipper of grounding wire to a good earthing terminal and ensure user safety ; 2. Put the oil to the caddy through the oil inlet. For the first time usage, please eliminate air while noticing the measure showing. - Page 11 - 10 -...
