Kato CITYRANGE SUPERBOOM PREMIUM MR-130R Manual

■CRANE
Description Rough terrain crane with maximum lifting capacity 13 ton
●Crane specifi cation
5.3 m Boom
9.04 m Boom
12.78 m Boom
16.52 m Boom
Maximum rated lifting
20.26 m Boom
capacity
24.0 m Boom
3.6 m Jib
5.5 m Jib
Rooster
5.3m ― 24.0m
Boom length
3.6m ― 5.5m
Fly jib length
24.8m ( Boom )
Maximum rated lifting
height
30.3m ( jib )
Main winch 118m / min. ( at 5th layer )
Hoisting
line speed ( winch up )
Auxiliary winch 103m / min. ( at 3rd layer )
Main winch ( Parts of line; 8 ) : 14.75m / min. ( at 5th layer )
Hoisting hook speed
( winch up )
Auxiliary winch ( Parts of line; 1 ) : 103m / min. ( at 3rd layer )
Main winch 180m / min ( at 5th layer )
High-speed lowering
Rope speed Auxiliary winch 155m / min ( at 3rd layer )
-7.5° ― 82°
Boom derricking angle
30s / -7.5° ― 82°
Boom derricking time
5.3 ― 24.0m / 65s
Boom extending speed
-1
Slewing speed 2.4min
Tail slewing radius 1,600mm
●Equipment and structure
Box-shaped, 6-section hydraulically telescopic type
( the 2nd and 3rd jib sections at the same time, the 4th, 5th and 6th
Boom type
jib sections at the same time )
2 sections ( 2nd section of draw-out type )
Jib type
Hydraulic stepless tilting type ( offset angles 5° ― 60° )
Boom extension/
Two hydraulic cylinders and wire ropes used together
retraction equipment
Boom derricking/lowering One hydraulic cylinder of direct acting type with pressure-
equipment compensated fl ow control valve
Two units of Single winch, Differential gear reduction type ( built-in
Winch system
negative brake ) with Automatic brake, High/Low speed switching
Main & Auxiliary winches
system and Hydraulic compensated fl ow control valve.
Equipped with Hydraulic motor drive and a planetary gear speed
Slewing equipment
reducer ( built-in negative brake )
Slewing bearing Ball bearing type
Hydraulic H-beam type ( with fl oat and vertical cylinder in single unit )
Type
4,750mm ( Fully extended )
4,300mm ( Intermediately extended )
Outriggers
Extension
3,700mm ( Intermediately extended )
width
2,700mm ( Intermediately extended )
1,640mm ( Fully retracted )
Main winch Diameter: 11.2mm×Length: 132m
Wire rope for
hoisting
Auxiliary winch Diameter: 11.2mm×Length: 65m
●Hydraulic equipment
Oil pump Double variable plunger type, gear and plunger type
Hoisting
Axial plunger type
motor
Hydraulic
motor
Slewing
Axial plunger type
motor
Double acting with integral check and relief valves
Control valve
( With Hydraulic compensated fl ow control valve )
Cylinder Double acting type
Oil reservoir capacity 150L
●Safety devices
ACS ( Automatic Crane System with voice alarm ) ,
Slewing automatic stop system, Working area restriction unit,
Outrigger status detector,
Natural lowering prevention unit for boom derricking/lowering,
Natural lowering prevention unit for boom extension/retraction,
Natural lowering prevention unit for jib derricking/lowering,
Overhoist prevention device, Drum lock device, Automatic winch brake,
Hydraulic safety valves, Outrigger lock pins,
Slewing warning lamp, Hydraulic oil temperature warning device,
Sling rope holding device
●Standard equipment
Air conditioner, Winch drum turning indication device, Working light
( on boom, table and cab )
●Operator's cab
Tilt/telescopic steering wheel,
Full-adjustable suspension seat ( with Headrest and Armrest ) ,
Power window ( with Window close reminder switch ) ,
Hot & cool box, Intermittent front & roof wipers ( with Washer ) ,
Lunch table, AM/FM radio with Clock, Cigarette lighter,
Step lamp, fi re extinguisher, Floor mat
●Optional equipment
ACS external display, Loudspeaker, Door visor, Tangling prevention
unit
ROU GH T ERRAI N CRAN E
SPECIFICATION
13,000kg × 1.7 m ( Parts of line : 8 )
6,000kg × 4.0 m ( Parts of line : 4 )
6,000kg × 4.0 m ( Parts of line : 4 )
5,000kg × 4.5 m ( Parts of line : 4 )
4,700kg × 4.0 m ( Parts of line : 4 )
3,200kg × 5.5 m ( Parts of line : 4 )
1,600kg × 75° ( Parts of line : 1 )
1,000kg × 70° ( Parts of line : 1 )
( Parts of line : 1 )
1,800kg
■CARRIER
●Carrier specifi cation
Maximum traveling speed 49km/h
0.56 ( tan θ )
Grade ability
6.5m ( 2 wheel steer )
Minimum turning radius
( center of extreme outer tire )
3.92m ( 4 wheel steer )
●Engine
Model Mitsubishi 4M50-TLE3A
4 cycle, 4 cylinders, water cooled, direct injection turbo-charged
Type
diesel engine with intercooling
Piston displacement 4.899L
Max. power 129kW at 2,700min
Max. torque 530N･m at 1,600min
●Equipment and structure
Switches between 2 wheel drive ( 4×2 ) and 4 wheel drive ( 4×4 )
Drive system
Engine mounted 3 elements
Torque converter
1 stage ( with lock up clutch )
Transmission Remote mounted full automatic
Number of speeds 4 forward & 1 reverse speed
Front Full fl oating type, with a two-stage reduction gear
Axles
Rear Full fl oating type, with a two-stage reduction gear
Taper - leaf spring ( hydraulic locking device with shock absorber )
Front
Suspension
Taper - leaf spring ( hydraulic locking device with shock absorber )
Rear
Air-over hydraulic disk brake on 4 wheels
Service
( front and rear independent circuit )
Spring applied, electrically air released parking brake mounted on
Brake system Parking
front axle, internal expanding type
Exhaust pipe open/close valve type exhaust brake,
Auxiliary
Auxiliary braking unit for working
Model All hydraulic power steering
Steering
Front 2 wheel steering, rear 2 wheel steering, independent front
Mode
and rear wheel steering ( with automatic rear steering lock system )
Front 275 / 80 R22.5 151 / 148J
Tire size
Rear 275 / 80 R22.5 151 / 148J
Fuel tank capacity 250 L
( 12V-100AH ) ×2
Batteries
●Safety devices
Emergency steering device,
Rear wheel steering lock system ( automatic ) ,
Brake fl uid leak warning device, Auxiliary braking unit for working,
Suspension lock, Engine overspeed alarm,
Radiator coolant level warning device,
●Standard equipment
Aluminum outrigger plate, Electrically stowed side mirrors
●Optional equipment
Rearview camera, Left side view camera, Wheel chock
■GENERAL Dimensions
Overall length 7,440mm
Overall width 1,995mm
Overall height 2,845mm
Wheel base 2,750mm
Front 1,680mm
Treads
Rear 1,680mm
Passenger capacity One person
Gross
approx. 13,765kg
weight
Gross vehicle Front
approx. 6,790kg
mass weight
Rear
approx. 6,975kg
weight
● Stow the hooks in place before traveling.
● Before you use this machine, read the precautions in the instruction manual thoroughly to
operate it correctly.
● KATO products and specifi cations are subject to improvements and changes without notice.
-1
-1
5810010101
