- Page 1 70mai Hardwire Kit User Manual Scan the QR code and email Scan the QR code to view us at help@70mai.com the installation video.
-
Page 2: Product Overview
Product functions Type-C connector As an accessory to 70mai in-car devices, this product must be used Power conversion box with the main device. After correctly installed and connected with the main device, 70mai Hardwire Kit will power and transmit ACC signals to... - Page 3 Otherwise, the main device may malfunction. is turned on or off. For such cars, the 70mai hardwire kit is unable to transmit ACC signals to the main device. This may cause certain Precautions functions to be unavailable.
-
Page 4: Installation
Installation Step 1. Locate your fuse box Refer to the vehicle's user manual and locate the fuse box. Notes • M ake sure that the car's engine and power has been turned off before locating or operating the fuse box. •... - Page 5 Step 2. Find the suitable fuses Refer to the vehicle's user manual or use a multimeter to find the fuses in the following specifiacation. 1. The regular electric fuse with an output voltage of 12-30V. 2. The ACC power fuse. •...
- Page 6 Step 3. Connect the power cable and ACC signal cable 1. Wrap the power cable (red) of the hardwire kit around the pin of the removed regular electric fuse. 2. Wrap the ACC signal cable (yellow) of the hardwire kit around the pin of the removed ACC power fuse.
- Page 7 Step 4. Connect the ground wire 1. Connect the ground wire (black) of the hardwire kit to the grounding screw or chassis on the vehicle. 2. Use tool to fasten the screw.
- Page 8 Step 5. Test the connection and ACC signal the driver seat door is opened after the engine is turned off. Some car models will only trigger the ACC power off signal after the engine has Smart rearview mirrors and other smart in-car devices: been turned off for a certain period of time.
- Page 9 For such cars, observe for function on the device or the 70mai app (when the main device is some time after the ACC power is turn off to check if the main device connected to the app) powers off or enters sleep mode.
- Page 10 Step 7. Manage the cable Route the hardwire kit to the location of the main device. If the hardwire kit is too long, tie it up, but do not cut it. Cutting the hardwire kit will affect the power and ACC signal to the main device. Notes: •...
-
Page 11: Specifications
3. The main device couldn't enter parking surveillance mode. • M ake sure the parking surveillance function is enabled in the main Packing list device or the 70mai app (when the main device is connected to the 1. 70mai Hardwire Kit × 1 2. User manual × 1... - Page 12 app). • M ake sure that the hardwire kit cables are well connected with the Constant power Normal recording Normal recording Ground correct fuses. Constant power Comparison table of wire connection and dash cam status ACC power Dash cam status (parking Normal recording Powering off Ground...
- Page 13 EU declaration of conformity The manufacturer hereby, declares that this equipment is in compliance with the applicable Directives and European Norms, and amendments. The full text of the EU declaration of conformity is available at the following internet address: https://help.70mai.asia/1193.html...
- Page 14 Hereby, 70mai Co.,Ltd. declares that the equipment type Midrive UP03 Note: This equipment has been tested and found to comply with the limits is in compliance with Electromagnetic Compatibility Regulations 2016 for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits (S.I.
- Page 15 L'exploitation est autorisée aux deux Service: help@70mai.com conditions suivantes: For further information, please go to www.70mai.com (1) l'appareil ne doit pas produire de brouillage, et Manufacturer: 70mai Co., Ltd. (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, Address: Room 2220, Building 2, No.
