Bene Inox 8071 Manual

Model 8071
– 11 chemin de la Pierre Blanche – 69800 SAINT-PRIEST – S.A.S with 240 000 € share capital – SIREN N° 311 810 287
Béné Inox
Tel. N°: +33 (0)4 78 90 48 22 – Fax N°: +33 (0)4 78 90 69 59 – www.bene-inox.com – bene@bene-inox.com
Technical information, illustrations and photographs are provided for information only, they are not contractual. Some may vary according to the tolerances accepted in the profession and the applicable standards. All
instructions for use, disassembly and maintenance are recommendations only. These could also vary depending on product usage conditions, its installation environment and purchaser requirements – of which the purchaser
ASME BPE
Manual CLAMP diaphragm valves
316L stainless steel - PC handle
alone is responsible for their definition.
Specifications
Dimensions: 1/4" to 2" (O.D.)
Connection: CLAMP
Max. allowed pressure:
Temperature: - 10ºC to +150ºC
Material: CF3M die-cast stainless steel body
EPDM + TFM diaphragm
On request:
- SF4 finish
- EN 1.4435 forged body
- EPDM diaphragm
Range
80
PHARMACEUTICAL
& BIOTECHNOLOGY
6 bar
8071-A V0722
