Bene Inox 61363 Manual

Model 61363
– 11 chemin de la Pierre Blanche – 69800 SAINT-PRIEST – S.A.S with 240 000 € share capital – SIREN N° 311 810 287
Béné Inox
Tel. N°: +33 (0)4 78 90 48 22 – Fax N°: +33 (0)4 78 90 69 59 – www.bene-inox.com – bene@bene-inox.com
Technical information, illustrations and photographs are provided for information only, they are not contractual. Some may vary according to the tolerances accepted in the profession and the applicable standards. All
instructions for use, disassembly and maintenance are recommendations only. These could also vary depending on product usage conditions, its installation environment and purchaser requirements – of which the purchaser
Manual diaphragm valves 982/985, SMS ends
for welding - EPDM diaphragm
316L stainless steel
alone is responsible for their definition.
Specifications
Dimensions: DN25 to DN100 (1" to 4")
Connection: to be welded
MAP: 10 bar
Ambient temperature:
Fluid temperature: -10°C to +90°C
Material: 316L stainless steel
EPDM diaphragm
Cast-iron body, lower Ra and PTFE
diaphragm etc. on demand.
Range
61
SMS STANDARD
-10°C to +80ºC
61363-B V1124
