Manual diaphragm valves 982/985, DIN ends
for welding - EPDM diaphragm
316L stainless steel
alone is responsible for their definition.
Specifications
Dimensions: DN15 to DN100
Connection: to be welded (DIN Range 2)
MAP: 10 bar
Ambient temperature:
Fluid temperature: -10°C to +90°C
Material: 316L stainless steel
EPDM diaphragm
On request: Cast-iron body, lower Ra, DIN
Range 1 and PTFE diaphragm etc.
Range
62
DIN STANDARD
-10°C to +80ºC
62363-B V1124
