ETI SOLID GSX LXN250 Series Mounting Instructions

SWITCH TO A SAFE FUTURE
LXN250 X-Y
Mounting instructions
GB
Montage anleitung
DE
Navodilo za montaźo
SI
Instrukcje montażu
PL
Upute za montaźu
HR
Montaźni návod
CZ
Navod na montaź
SK
Szerelesi utmutato
HU
Montavimo instrukcija
LT
Инструкция за монтаж
RU
Montāžas instrukcija
LV
Paigaldusjuhend
EST
LXN250 1-12 PHN1 LXN250 2-12 PHN1
001321800 001321802
No. Code No Name
1 -- LXN250
2 001338469 EH-TX-1-S
3 001338470 EH-TX-AL
4 001336932 PHN1 D2.5-W1
5 001336934 PHN1 D2.5-W2
6 001336936 PHN1 D2.5-W3
7 001336938 PHN1 D2.5-W4
8 001336982 PHN-BEL-D2.5
9 001101715 UCH-2
10 001102166 U400
11 001338605 WP-A 12
12 001338308 EP-B
13 001338900 BL-WP 2
14 001338901 BL-WP 3
15 001338102 UA-B
16 001338103 UA-B-WD
17 001338104 UA-S
18 001338130 BL-UA 2
19 001338131 BL-UA 3
20 001338132 BL-UA 4
21 001338160 BU-PM
22 001338161 BU-WD
23 -- PM-G
24 001338864 WD-K 12
25 001341800 UD-B60-H P1
26 001341802 UD-B60-H P3
27 001341803 UD-B60-H P4
28 001101683 LG-V SET
29 001101685 LG-V5 SET
30 001341151 LG-V6-B SET
31 001341153 LG-V6-D SET
32 001341650 LG-B60-H P1
33 001341651 LG-B60-H P3
34 001341652 LG-B60-H P4
35 001696006 L-BBS-60/3
36 001696007 L-BBS-60/4
37 001342181 L-WP-B60/3
39 001342182 L-WP-B60/4
A24.07 981029309
LXN250 3-12 PHN1
001321804
Page No. Code No
1-3, 5, 7 40 001341700
4 41 001341702
4 42 001341704
6 43 --
6 44 --
6 45 --
6
6
7
7
8, 9
10
11, 12
11, 12
13, 20, 21, 23, 24
14, 23
15, 21, 24
16, 21, 24
29, 35, 40
29, 35, 40
17, 21
18, 24
19-21
22-24
25
26
27
28
28
29
29
30
30
30
31
32
31
32
LXN250 4-12 PHN1
001321806
1
2
3
4
5
6
7
8
Name Page
LG-B60-V1 P3 33, 34, 36
LG-B60-V2 P3 33, 34, 36
LG-B60-V2 P4 33, 35
CP x-1 M 37
CP x-1.5 M 38
CP x-y F 39
SOLID GSX Enclosure system
ETI Elektroelement d.o.o.
Obrezija 5, 1411 Izlake, Slovenia
Phone: +386(0)3 56 57 570
Fax: +386(0)3 56 74 077
e-mail: eti@eti.si
www.etigroup.eu
The enclosure set includ:
x 3 9
M6
x 3
KEY-1333
M6
x 1
M8
10
x 1
M8
KEY-1333-ET
x 8
x 8
x 3
x 8
Code No Type X [mm]
001321800 LXN250 1-12 PHN1
001321802 LXN250 2-12 PHN1
001321804 LXN250 3-12 PHN1
001321806 LXN250 4-12 PHN1
Necessery tools:
Screwdriver PH2
10
13
Hex5
Hex6
Y [mm] Z [mm]
300 1850 250
550 1850 250
800 1850 250
1050 1850 250
1/40
