Ecosoft Anthracite Azure 370 Quick Start Up Manual

QUICK START-UP GUIDE
FOR ECOSOFT
ANTHRACITE
WATER SOFTENERS
Ecosoft has already taken care of all the essential settings
for their water softeners. All you need to do now is follow
a few simple steps.
After installing and powering up an Ecosoft Anthracite system, set water
hardness, current time in the Customer menu of control valve.
Use ▲ and ▼ buttons to change setting; «NEXT» button to save and go to
next step; «CLOCK» to save and exit menu; «REGEN» to move back one step.
To proceed, hold «NEXT» and ▲ buttons simultaneously for 3 seconds.
PPM, using ▼ or ▲ . Press «NEXT» to go to Step 3I. Press «REGEN» to exit
STEP 2I. Hardness: Set the amount of hardness as calcium carbonate per
Installer Display Settings.
STEP 3I. Service Water Hardness (PPM): If a mixing valve is installed in the
valve, service hardness needs to be set. Setting range is always less than the
setting in Step 2I. Press «NEXT» to go to Step 4I. Press «REGEN» to return to
previous step.
STEP 4I. Set Day Override to 1 – 28 days or OFF using ▼ or ▲ . Press «NEXT»
to go to Step 5I. Press «REGEN» to return to previous step.
using ▼ or ▲ . The default time is 2:00 a.m. This display will show on 0 if Step 4S
STEP 5I. Time of Regeneration, Hour: Set the time (hour) for regeneration
or Step 3F is set to on 0. Press «NEXT» to go to Step 6I. Press «REGEN» to
return to previous step.
regeneration using ▼ or ▲ . The default time is 2:00 a.m. This display will not
STEP 6I. Time of Regeneration, Minutes: Set the time (minutes) for
appear if Step 4S or Step 3F is set to on 0.Press «NEXT» to go to Step 7I.
Press «REGEN» to return to previous step.
Regen
Download the full version of the manual,
After programming the control valve:
STEP 7. Рour salt into the salt tank of the system
to the level of 1/2 to 2/3 of the tank volume.
STEP 8. Open the water supply to the softener.
STEP 9. After that, it will start the forced regeneration of the system
by pressing the «REGEN» button for 5 seconds. This is necessary for
cleaning the material from impurities and for its stratification.
click here
