Programming of your new remote control :
1. Open the casing of your new remote control.
2. You will see a black object, the staple (C), normally connected to a single clip (B) (fig 1).
Disconnect it (fig 2). Reconnect it to both clips (fig 3).
3. Open the casing of your receiver. It is located next to your motor.
4. On the receiver circuit board, you will see a row of 20 small programmable switches
numbered 1 to 20 and a row of 4 small programmable switches, numbered 1 to 4. They are
in the ON or OFF position. The positioning of these small programmable switches determines
the system programming code. Please make a note of this positioning in the following table :
1
2
3
4
1
2
3
4
http://www.remotecontrol-express.com
Programming Manual
CAME T152 - T154
5
6
7
8
9
10 11 12 13 14 15 16 17 18 19 20
- TEL : +44 (0) 207 399 7782 - FAX : +44 (0) 207 927 3151
Advertisement
Related Manuals for CAME T152
Summary of Contents for CAME T152
- Page 1 Programming Manual CAME T152 - T154 Programming of your new remote control : 1. Open the casing of your new remote control. 2. You will see a black object, the staple (C), normally connected to a single clip (B) (fig 1).
- Page 2 Programming Manual 5. Press the button you wish to program on your new remote control. 6. Enter your programming code in the following manner : The left button on the remote control corresponds to the ON position of the internal programmable switches.
