Summary of Contents for Nolan N-Com basickit N84

  • Page 1 english safety and istructions for use...
  • Page 2 ncom n102 0023 10-07-2007 14:10 Pagina 2 Basic electronic card Scheda elettronica base Read the instructions below for proper assembly and use. Leggi le istruzioni di seguito riportate per il suo corretto montaggio e utilizzo. Basic electronic card Elektronische Schaltkarte Read the instructions below for proper assembly and use.
  • Page 3: Table Of Contents

    The N-Com Basic Kit was designed and built using the latest technologies and the best materials. Long tests and thorough system development have made it possible to achieve the highest sound quality. The N-Com Basic Kit is the basic equipment for one of the communication systems of the Nolan N-Com product line.
  • Page 4: Warnings And Safety

    basickit N84 (044) 10-07-2007 13:22 Pagina 18 ENGLISH 1. WARNINGS AND SAFETY Read this user Manual carefully, as well as the User Manuals for other N-Com kits that you will be using with the N-Com Basic kit. Read the simple rules listed below. Failure to comply with these rules may lead to dangerous situations. Caution: The product cannot be used in official or non-official competitions, motordromes, circuits, racing tracks and similar.
  • Page 5: Appropriate Use

    1.6. Accessories and batteries - Only use the type of batteries, battery charges and accessories approved by Nolan for the specific model. - The use of a type different from the recommended one may lead to dangerous situations and invalidates the warranty.
  • Page 6: Nomenclature

    basickit N84 (044) 10-07-2007 13:22 Pagina 20 ENGLISH 2. NOMENCLATURE FIG. 1 Basic Kit N84 Microphone Foam windshield Flex Cable Loudspeaker Loudspeaker Loudspeaker Connector Audio cables Positioning holes FIG. 2A FIG. 2B Basic Sealing electronic trim card FIG. 3A FIG. 3B...
  • Page 7: Installation

    basickit N84 (044) 10-07-2007 13:22 Pagina 21 ENGLISH 3. INSTALLATION 3.1. Installing the battery (only for Intercom Kit and Bluetooth Kit) FIG. 4 1. Connect the battery cable (Red+Black) to the connector, (Fig. 4). 2. Position the battery in the housing (right side), passing the cable through as shown in the figure (Fig.
  • Page 8 basickit N84 (044) 10-07-2007 13:22 Pagina 22 ENGLISH 3. Remove the Noise Reducers from the cheek pads and tear the precut FIG. 8 plastic inserts (Fig. 8). FIG. 9a 4. Remove both polystyrene cheek pads by gently pulling the tab located in the front of the same cheek pad (Fig.
  • Page 9 basickit N84 (044) 10-07-2007 13:22 Pagina 23 ENGLISH Position the chin guard in its housing inside the helmet (Fig. 12). FIG. 12 8. Take the left side of the Basic Kit (equipped with connector and audio cables) and, looking at the helmet from the outside, insert the positioning FIG.
  • Page 10 basickit N84 (044) 10-07-2007 13:22 Pagina 24 ENGLISH FIG. 17 12. Gently push the front of the cheek pad against the side of the chin guard (Fig. 17). FIG. 18 13. Carefully verify proper final positioning of the cheek pad and of the chin- strap positioning the loudspeaker in the space on the polystyrene cheek pad (Fig.
  • Page 11: Applying The Sealing Trim

    basickit N84 (044) 10-07-2007 13:22 Pagina 25 ENGLISH 3.4. Applying the sealing trim 1. Remove the protective film from the trim and apply the trim around the FIG. 22 10-way connector as illustrated in Fig. 22. Note: Only use the sealing trim included with this kit. 3.5.
  • Page 12: Audio Cables

    basickit N84 (044) 10-07-2007 13:22 Pagina 26 ENGLISH 5. After freeing the 10-way connector from the shell, also remove the right side by unfastening the Basic Kit from the pins on the shell. 6. Gently remove the chin guard and the Basic Kit from the helmet. 7.
  • Page 13: Answering A Phone Call

    basickit N84 (044) 10-07-2007 13:22 Pagina 27 ENGLISH Caution: Cell phones are equipped with their own volume adjustment. Adjust the cell phone volume levels so as to obtain the desired volume prior to using the system while riding. Caution: Listening at a very high volume may distract you from riding your vehicle and create dangerous situations or limit the ability to hear background noises.
  • Page 14: Connection With Multimedia Wire

    “Exclusions and limitations of the Coverage”. 8.2. Exclusions and limitations of the coverage This warranty only covers defects in materials and manufacturing. Nolan shall not be considered responsible for product ®...
  • Page 15: Validity Of The Limited Warranty

    ® availability, coverage, services or range pertaining to the aforementioned system. Whenever the product is used in conjunction with accessories or equipment not supplied by Nolan , Nolan shall not ®...
  • Page 16: Procedure For The Forwarding Of Claims

    This warranty does not have any effect on the customer’s legal rights under the national jurisdiction in force or on the consumer’s rights towards the dealer sanctioned by the purchase/sale contract. This warranty is valid throughout the European territory, and it represents the only express warranty provided by Nolan ®...
