SERVICE MANUAL
Ver 1.1 2004. 05
Revision History
Revision History
Link
Link
SCHEMATIC DIAGRAMS
SCHEMATIC DIAGRAMS
• For ADJUSTMENTS (SECTION 6), refer to SERVICE MANUAL, ADJ (987622751.pdf).
• For INSTRUCTION MANUAL, refer to SERVICE MANUAL, LEVEL 1 (987622741.pdf).
• This service manual contains information for Japanese model as well.
• Reference No. search on printed wiring boards is available.
The information that is not described in this Service Manual is described
in the LEVEL 2 Service Manual.
When repairing, use this manual together with LEVEL 2 Service Manual.
Contents of LEVEL 2 Service Manual
1. SERVICE NOTE
2. DISASSEMBLY
3. BLOCK DIAGRAMS
4. PRINTED WIRING BOARDS AND
SCHEMATIC DIAGRAMS
5. REPAIR PARTS LIST
DSC-P10/P12
Photo: DSC-P10
PRINTED WIRING BOARDS
PRINTED WIRING BOARDS
OVERALL
POWER
CD-434, SW-386, ST-81,
MS-130
EXPLODED VIEWS
ELECTRICAL PARTS LIST
Canadian Model
AEP Model
Hong Kong Model
Australian Model
Chinese Model
Korea Model
Tourist Model
Japanese Model
REPAIR PARTS LIST
REPAIR PARTS LIST
DIGITAL STILL CAMERA
3
LEVEL
US Model
DSC-P10
UK Model
DSC-P10/P12
E Model
DSC-P10
