- Page 1 USER’S GUIDE 1325 Carden Farm Drive | Clinton, TN 37716 | 865-670-3713 | www.iTOOLco.com...
- Page 2 Page 2...
-
Page 3: Table Of Contents
BEFORE OPERATION OF THIS TOOL, READ & UNDERSTAND ALL OF THE INSTRUCTIONS & SAFETY INFORMATION IN THIS MANUAL. CONTENTS Safety First...............4 Important Safety Information..........5 Parts Breakdown...............8 Set Up and Operation............13 Use of a Main Roller............17 Page 3... -
Page 4: Safety First
SAFETY FIRST Safety is essential in the use and maintenance of this tool. This instruction manual & any markings on the tool provide information for avoiding hazards and unsafe practices related to the use of this tool. Observe all of the safety information provided. SAFETY ALERT SYMBOLS This symbol is used to call your attention to hazards or unsafe practices that could result in injury or property damage. -
Page 5: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING Read and understand all instructions and safety information in this manual before operating or servicing this tool. Also read the instruction manual supplied with your drill. FAILURE TO OBSERVE THESE WARNINGS CAN RESULT IN SEVERE INJURY OR DEATH. WARNING - PERSONAL SAFETY HAZARDS Only qualified persons should use this equipment. - Page 6 IMPORTANT SAFETY INFORMATION WARNING ENTANGLEMENT HAZARD Do not operate this tool while wearing loose fitting clothing. Put up long hair and keep it away from the unit. Keep hands away from moving objects or anything that can pinch or crush a hand or body part. FAILURE TO OBSERVE THESE WARNINGS CAN RESULT IN SEVERE INJURY OR DEATH.
- Page 7 DO NOT ALTER CABLE PULLING EQUIPMENT OR ANY EQUIPMENT BOUGHT FROM iTOOLco. Doing so will VOID YOUR WARRANTY. Guards, testing, and safety features are provided for your protection.
-
Page 8: Parts Breakdown
PARTS BREAKDOWN Page 8... - Page 9 PARTS BREAKDOWN Page 9...
- Page 10 PARTS BREAKDOWN Page 10...
- Page 11 PARTS BREAKDOWN Page 11...
- Page 12 PARTS BREAKDOWN Page 12...
-
Page 13: Set Up And Operation
SET UP AND OPERATION Remove both pins from the articulating plates and insert the motor unit into 2"/51 mm. receiver stock. (Fig. 1) Tip motor unit up and insert pin. (Fig. 2) Insert pin (Fig. 3) and then lift and insert main knuckle arm. - Page 14 SET UP AND OPERATION Insert the lower extension and roller. (Fig. 5) Tip puller to upright and collapsed position and replace all pins. (Fig. 6) Loosen center nut and bolt. (Fig. 7) Remove the bolt allowing the unit to pivot. (Fig.
- Page 15 SET UP AND OPERATION Position boom to desired direction and tighten bolts. (Fig. 9) Align the front arm in line with the direction of the pull. (Fig. 10) Place rope between rope guide rollers and begin to pull (Fig. 11) For underground pulls, position extensions to achieve desired pull angle.
- Page 16 SET UP AND OPERATION The front extension foot should be placed as close as possible to the conduit being pulled. (Fig. 13) When ready begin, thread rope tale over the rope engagement roller and pull up on in a steady continuous motion to start the pull.
-
Page 17: Use Of A Main Roller
USE OF MAIN ROLLER When pulling with extensions in use always make sure the rope is engaging the main roller, failure to do so could result in bending the extensions and harm to you. NEVER BYPASS A ROLLER. Failure to do so could cause bending of the extension. Page 17...
