iTOOLco CANNON MVP20K User Manual

20,000 lb. cable puller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Guide
1325 CARDEN FARM DRIVE | CLINTON, TN 37716 | 865.670.3713 |
ITOOLCO.COM © 2022 PROPERTY OF ITOOLCO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CANNON MVP20K and is the answer not in the manual?

Questions and answers

Related Manuals for iTOOLco CANNON MVP20K

Summary of Contents for iTOOLco CANNON MVP20K

  • Page 1 User’s Guide 1325 CARDEN FARM DRIVE | CLINTON, TN 37716 | 865.670.3713 | ITOOLCO.COM © 2022 PROPERTY OF ITOOLCO...

  • Page 2: Table Of Contents

    SET UP AND OPERATION ..........................26 Unpacking the Unit..........................18 Connecting to Skid Steer .........................29 Unfolding the MVP20K..........................34 Installing Front Extension & Brace......................37 Positioning for Pulling ..........................41 Maintenance ............................47 LIMITED WARRANTY: ITOOLCO CANNON MVP20K..................49 MVP20KUG P a g e | 2...

  • Page 3: Safety First

    Hazards that, if not avoided, COULD result in severe injury or death. CAUTION Hazards or unsafe practices that, if not avoided, MAY result in injury or property damage. ITOOLCO CANNON MVP20K USER’S GUIDE 2005C12KUG P a g e | 3...

  • Page 4: Important Safety Information

    FAILURE TO OBSERVE THESE WARNINGS CAN RESULT IN SEVERE INJURY OR DEATH WARNING – PERSONAL SAFETY HAZARDS Only qualified persons should use iTOOLco MVP20K. Wear eye protection and hard hat when using this tool. Do not use this tool while tired or under the influence of drugs, alcohol, or medication.
  • Page 5 Do not exceed load rating of cable puller, rope, or accessories. Always disconnect cable puller before servicing. FAILURE TO OBSERVE THESE WARNINGS CAN RESULT IN SEVERE INJURY OR DEATH. (CONTINUED) ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG P a g e | 5...
  • Page 6 WARNING – TOOL USE HAZARDS (continued) Do not operate cable puller in wet or damp locations. Do not expose to rain. Do not operate in an explosive atmosphere. Some components of the mobile cable pulling package exceed 50 lb. and will require more than one person to lift, transport, or assemble.
  • Page 7 The pulling rope must come in contact with all the sheaves used in the boom system. FAILURE TO OBSERVE THESE WARNINGS CAN RESULT IN SEVERE INJURY OR DEATH. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KKUG P a g e | 7...

  • Page 8: Skid Steer

    SAFE OPERATION SAFE OPERATION Careful operation is your best insurance against an 4. The ROPS/FOPS structure complies with ISO 3471, ISO 3449 and OSHA regulations. accident. 5. The seat belt must be inspected regularly and Read and understand this section carefully, before replaced if frayed or damaged.
  • Page 9 17. Do not modify the machine, otherwise it could lead to unforeseen safety problems. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KKUG P a g e | 9...
  • Page 10 SAFE OPERATION 16-18. Avoid performing any work with the machine when it is 7. Never remove any of the safety features on the machine. on an incline, which could cause it to become A Make sure all safety features, including guards, unbalanced and rollover.
  • Page 11 28. The machine is NOT designed for operation with hanging loads and has no safety features for such circumstances. Never operate in conjunction with a crane or other such device, which could cause serious injury. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KKUG P a g e | 11...
  • Page 12 SAFE OPERATION 4. SAFE LOADING AND TRANSPORT OF THE MACHINE 1. Observe all regulations concerning the transport of the machine on public roads. 2. Use adequately long and robust ramps when loading the machine. Block the ramps and transport appropriately. If towing is required, use proper tow lines and attachment points.
  • Page 13 5 . Securely support the machine with stands or suitable blocking before working underneath. For your safety, do not work under any hydraulically supported devices. They can settle, suddenly leak down, or be accidentally lowered. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KKUG P a g e | 13...
  • Page 14 SAFE OPERATION 1. Always make sure the engine is stopped before performing any maintenance or repairs. A Do not attempt to lubricate or make mechanical adjustments while the machine is in motion or while the engine is running even if stationary. A Always stay clear of moving parts.
  • Page 15 A Avoid any twisting, bending or hitting of hoses that could cause damage to the line. A Make sure any loose connections are secure properly before using the machine. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KKUG P a g e | 15...
  • Page 16 SAFE OPERATION 1. Take care when working around hot and pressurized 3. Always use care whenever handling grease that is components. pressurized. A Always follow the proper procedure to adjust tension. A Always allow the engine to cool sufficiently before performing any maintenance, inspection or repairs A Always loosen the discharge valve for the grease slowly.

  • Page 17: Description And Identification

    DESCRIPTION AND IDENTIFICATION The ITOOLco Cannon MVP20K is a 20,000 lb. cable puller intended to pull medium to large wire through conduit. It sets up in only minutes, and is a dual capstan, multiple speed puller. The Cannon MVP20K does not need to be anchored to the ground, and is easy to set up, transport, and operate.

  • Page 18: Unpacking The Unit

    ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG P a g e | 18...
  • Page 19 MVP20KUG P a g e | 19...
  • Page 20 ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG P a g e | 20...
  • Page 21 MVP20KUG P a g e | 21...
  • Page 22 ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG P a g e | 22...
  • Page 23 MVP20KUG P a g e | 23...
  • Page 24 ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG P a g e | 24...
  • Page 25 MVP20KUG P a g e | 25...

  • Page 26: Set Up And Operation

    The output torque limit dial is set at 1,000 lbs pounds from the factory to raise and lower the booms. This will need to be changed before you begin pulling. Please see further instructions for how to set your output limit. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG P a g e | 26...
  • Page 27 3.) Remove packing material, cutting along tape line as shown. Ensure to cut down the tape line away to avoid puncturing hydraulic lines. 4.) Once Packaging is cut away and T-brace has been taken off of the pallet, remove anchoring points from MVP20K used to stabilize the unit to the pallet during shipping.
  • Page 28 NOTE: When forklifting the MVP20K - pick up unit from either of the capstan sides or from the skid steer attachment side as shown. Caution: Picking from front boom end opposite of skid steer attachment side increases the chance of damaging the hydraulic hoses with forks. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG P a g e | 28...

  • Page 29: Connecting To Skid Steer

    5.) Once removed from shipping pallet, set MVP20k on level ground. 6.) Remove force gauge and foot switch from stored location on tower. MVP20KUG P a g e | 29...
  • Page 30 This will allow extra room for coupling to skid steer. Slight maneuvering of the tower might be needed to ensure pop pins are in locked position. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG...
  • Page 31 8.) Couple skid steer to MVP20k skid plate, ensuring that the plate is fully seated and the coupling arms are fully locked as shown. MVP20KUG P a g e | 31...
  • Page 32 Release pressure valve to make connection of hoses easier. Note: Tie wrap the hydraulic hoses to step as shown here to help keep hoses free of pinch points. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG P a g e | 32...
  • Page 33 11.) Pull pop pins at the base of the control tower and tip the tower towards skid steer back into operating position. Hold the weight of the tower as you do this, ensuring the tower does not drop or slam into position. Once tower is in operating position, ensure pop pins are locked and engaged.

  • Page 34: Unfolding The Mvp20K

    You do not need to reinstall main boom pin once lowered. Note: If main boom is extended all the way down you will NOT have room to unfold pulling head. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG...
  • Page 35 16.) Once folding hinge pin is removed. While lifting the end of main roller, maneuver the folded half of the main boom to be in line with the rest of the boom. While still lifting the main roller, reinsert the folding hinge pin. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG...
  • Page 36 Then insert the pin. The pin should move from behind the folding hinge (closer to the capstans) to in front of it (closer to the main roller). (Collapsed Pulling Position) (Extended Folding Position) ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG P a g e | 36...

  • Page 37: Installing Front Extension & Brace

    NOT stand underneath main roller as you turn it. Keep control of the main roller to prevent it turning to quickly or falling. Once main roller is facing down, re insert pin. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG P a g e | 37...
  • Page 38 19.) Remove main roller adjustment pin and front hydraulic boom pin as shown. This will allow the front outer extension portion to swing freely. Raise main boom to a height that will allow you to insert the front extension. MVP20KUG P a g e | 38...
  • Page 39 21.) Remove pin from front extension as well. 22.) Tip extension, remove silver inner tubing from brace. Insert into main roller outer extension and pin. Tilt and insert extension - re insert pin. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG P a g e | 39...
  • Page 40 24.) Re insert front hydraulic pin by tipping extension forward and aligning pin points. Caution: Do not try to set extensions and pins using power from hydraulics. Doing the adjustments manually limits the potential for injury. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG P a g e |40...

  • Page 41: Positioning For Pulling

    Placing unit for an underground pull. 26.) Position base just in front of conduits so main roller extends above conduit bank to be pulled for an underground configuration. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG P a g e | 41...
  • Page 42 28.) Position base in front of the conduit allowing room for your sheave to rotate. In this example we are using a 24” sheave, so we're positioned about 30” back from the conduit front edge to the picking eye. Next choose what picking eye you want to use. ITOOLCO CANNON MVP20KK USER’S GUIDE MVP20KUG P a g e | 42...
  • Page 43 After you have plugged your foot switch in, plug the control tower into the back of the of the foot switch power cord. Once both the foot switch and tower are plugged in, turn on the Milwaukee inverter. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG...
  • Page 44 Note: If no lights come on, check that the emergency stop is pulled out. Then check that the foot switch is properly plugged in. If they are, check to see power inverter is on and the battery is charged. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG...
  • Page 45 Reminder: When looking at the force gauge, the outer set of numbers indicates the large high speed capstan. Meanwhile the inner set of numbers are for the small low speed, high torque capstan settings. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG...
  • Page 46 If the load isn’t moving add two or three wraps around the capstan and apply tension. Repeat as necessary until rope rotation matches the rotation of the capstan while under load. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG...

  • Page 47: Maintenance

    Maintenance of your MVP20K. Following these steps is imperative to the upkeep of your unit. Lube chain daily as shown here. (LPS #2 Lubricant.) Grease rope guides every 100 hours of operation as shown. (Standard axle bearing grease.) ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG P a g e |47...
  • Page 48 Some high flow machines can cause the indicator to pop out and turn red, if this is the case with your machine simply push button back in to reset. After filter is changed push button to reset to a green indication. ITOOLCO CANNON MVP20K USER’S GUIDE MVP20KUG P a g e |48...

  • Page 51: Limited Warranty: Itoolco Cannon Mvp20K

    If the part(s) if found to be defective, iTOOLco will refund freight charges paid by you in retuning the defective part(s) and prepay replacement part(s) freight charges.
  • Page 52 1325 CARDEN FARM DRIVE | CLINTON, TN 37716 | 865.670.3713 | ITOOLCO.COM © 2022 PROPERTY OF ITOOLCO ITOOLCO CANNON 12K USER’S GUIDE 2005C12KUG P a g e | 29...
