VM-0008ETP Module
Manual
Version V1.1
Archived Date 2023-03-07
Veichi Electric Co., Ltd. provides customers with a full range of technical support, so users can
reach the nearest Veichi Electric Co., Ltd. office or customer service center, or the company
headquarters directly.
Veichi Electric Co.
All rights are reserved by Veichi. Contents are subject to change without notice.
Veichi Electric Co.
Address: 3rd Floor, Chunsheng, Linoya Industrial Park, Tangtou 1 Road, Tangtou Community,
Shiyan, Baoan District, Shenzhen, China.
Service hotline: 400-600-0303
Company website: www.veichi.com
Advertisement
Table of Contents
Related Manuals for Veichi Electric VM-0008ETP
Summary of Contents for Veichi Electric VM-0008ETP
- Page 1 Manual Version V1.1 Archived Date 2023-03-07 Veichi Electric Co., Ltd. provides customers with a full range of technical support, so users can reach the nearest Veichi Electric Co., Ltd. office or customer service center, or the company headquarters directly. Veichi Electric Co.
-
Page 2: Other Files
⚫ Scan the QR code on the product body to get the manual with mobile phone. ◼ Warranty Statement If malfunctions or damage occur on the product under normal use, Veichi Electric offers 18-month warranty (from the date of shipment from the factory, subject to the bar code on the body, and in accordance with the agreements between parties if there are some). - Page 3 The relevant service costs are calculated according to the manufacturer's standards, and if there is a contract, the contract will be handled on a priority basis. Please refer to the Product Warranty Card for detailed warranty description.
-
Page 4: Safety Precaution
Safety Precaution ◼ Safety Statement ⚫ Read and follow these safety precautions before installing, operating, and maintaining the product. ⚫ Follow all safety precautions stated on the product's labeling and in the manual when installing, operating, and maintaining the product for personal and equipment safety. ⚫... -
Page 5: Installation
➢ Design external protection circuits and safety mechanisms for output signals related to major accidents for safe operation of the equipment; ➢ The programmable controller CPU may stop all output when it detects an abnormality in its own system; when some of the controller's circuits fail, output may turn uncontrolled. Please design suitable external control circuits in order to ensure normal operation;... -
Page 6: Maintenance
➢ Wiring of this product should only be carried out by specialized maintenance personnel with adequate electrical knowledge and training related to electrical equipment; ➢ During wiring, the external supply power to the system must be fully disconnected in advance. Failure to do so may result in electric shock or equipment failure or malfunction;... - Page 7 ➢ Dispose of this product as industrial waste, and the batteries should be handled separately in accordance with local laws and regulations; ➢ Dispose of equipment and products in accordance with industrial waste disposal standards to avoid environmental pollution.
-
Page 8: Product Information
1 Product Information 1.1 Naming Rules and Nameplate Description VM – 00 08 E TP Product information VM: Veichi Flexible Series IO Module IO input channel 00: 0 channel IO output channel 08: 8 channels ... -
Page 9: Component Description
Based on the above naming rules and nameplate information, the relevant ordering data for this product is shown in the table below: Model Description Machine code Application VM series 8-channel digital drain VM-series PLC, VM-series 0008ETP output coupler 1.2 Component Description Interface Function definition Signal... -
Page 10: Power Specification
Orange: temperature measurement input User See the terminal definition section for details. terminal 1.3 Specification 1.3.1 Power Specification Item Specification Rated voltage of terminal input voltage 24V DC (20.4V DC~ 28.8V DC) Rated current of terminal input power 2A (typical at 24V) Rated voltage of bus input power 5V DC (4.75V DC~5.25V DC) Rated current of bus input power... -
Page 11: Software Specification
Output indicator lights up when the output is on (software Output action display controlled) Output derating 50% derating at 55° C (output current not exceeding 1A while ON), or 10° C derating when output terminals are all ON Protection Short circuit protection, overcurrent protection 1.3.3 Software Specification Item Specification... -
Page 12: Mechanical Installation
2 Mechanical Installation 2.1 Mounting Dimensions 2.1.1 Module Mounting dimension information is shown below in (mm): 2.1.2 Connection Cables... -
Page 13: Rail Installation
2.2 Installation 2.2.1 Inter-module Installation Inter-module assemblies are slide-mounted via the top and bottom rails. 2.2.2 Rail Installation DIN rail mounting is adopted here. When installing, align the module with the DIN rail and press the snap until there is a clear click sound. As shown in the figure below. - Page 14 Note: Push the rail snaps first to open state, place the module onto the DIN rail, press down the top of the snaps with your hand until it is in place. Install a DIN rail clamp at each end of the main unit or module and when install them, hook the bottom of the DIN rail clamp to the bottom of the DIN rail and then rotate the DIN rail clamp so that the top end of the DIN rail clamp is hooked to the top end of the DIN rail, and then finally tighten the screws to lock the DIN rail clamp.
-
Page 15: Electrical Installation
3 Electrical Installation 3.1 Cable Selection The wire lug diameters in the following table are for reference only, and can be adjusted according to reasonable calculations based on practical use. Material name Wire diameter PRC standard /mm2 American standard (US) /AWG Tube lug 0.75 If other tube lugs are used, crimp them to the stranded wire, shape and size are required as shown below. -
Page 16: Terminal Definition
3.2 Terminal Definition Left indicator Left signal Left terminal Right Right signal Right terminal indicator... -
Page 17: Terminal Wiring
3.3 Terminal Wiring 3.3.1 Output Terminal Wiring... - Page 18 4 Module Programming Example 4.1 Veichi Auto Studio with VC5 4.1.1 Create A New Project 4.1.2 Configure EtherCAT Task 4.1.3 Import the xml File Import the current latest version of VM-RTU-ECT_1.0.0.xml description file and double click to add it to the device:...
-
Page 19: Slot Configuration
4.1.4 Slot Configuration Currently, VC5 requires slot configuration of the device first, and the configuration of the expansion modules and the order must be consistent with the physical object, otherwise an alarm will pop up to indicate that the configuration does not match what is connected. - Page 20 4.1.5 IO Mapping VC5 default setting is no mapping, so it is necessary to map the registers that will be controlled and monitored to the soft components before actual use, otherwise users can’t operate on them. 4.1.6 Set Parameters 1. stopmode: failure stop output mode (index number in EtherCAT application: 0x8001+0x40*slot number), each channel corresponds to 1 bit respectively, 0 is hold, 1 is preset value corresponding to output stopvalue.
- Page 21 4.1.7 Write User Programs 4.1.8 Compile, Download and Run If there are no errors during compiling, download and run it. 4.2 Simple commissioning with Beckhoff TwinCAT 4.2.1 Import the xml File Copy the current latest version of the description file VM-RTU-ECT_1.0.0.xml to the TwinCAT installation directory under TwinCAT\3.1\Config\Io\EtherCAT.
- Page 22 4.2.2 Create A New TwinCAT Project Open the TwinCAT software to create a new TwinCAT project, connect the VM-RTU-ECT to the VM-0008ETP and power up and connect it to the Ethernet interface of the PC. 4.2.3 Scan the Devices Ensure that the VM-RTU-ECT and VM-0008ETP are connected for device scanning, and follow...
- Page 23 Note: A new installation of TwinCAT software requires the installation of the real-time NIC driver before this step. 4.2.4 IO Monitoring and Commissioning As shown in the figure below, scan to a 0008ETP expansion module under the device VM-RTU- ECT coupler for IO monitoring and debugging its input and output.
