VM-0008ETN Module
Manual
Version V1.1
Archived Date 2023-03-07
Veichi Electric Co., Ltd. provides customers with a full range of technical support, so users can
reach the nearest Veichi Electric Co., Ltd. office or customer service center, or the company
headquarters directly.
Veichi Electric Co.
All rights are reserved by Veichi. Contents are subject to change without notice.
Veichi Electric Co.
Address: 3rd Floor, Chunsheng, Linoya Industrial Park, Tangtou 1 Road, Tangtou Community,
Shiyan, Baoan District, Shenzhen, China.
Service hotline: 400-600-0303
Company website: www.veichi.com
Advertisement
Table of Contents
Related Manuals for Veichi Electric VM-0008ETN Series
Summary of Contents for Veichi Electric VM-0008ETN Series
- Page 1 Manual Version V1.1 Archived Date 2023-03-07 Veichi Electric Co., Ltd. provides customers with a full range of technical support, so users can reach the nearest Veichi Electric Co., Ltd. office or customer service center, or the company headquarters directly. Veichi Electric Co.
-
Page 2: Other Files
⚫ Scan the QR code on the product body to get the manual with mobile phone. ◼ Warranty Statement If malfunctions or damage occur on the product under normal use, Veichi Electric offers 18-month warranty (from the date of shipment from the factory, subject to the bar code on the body, and in accordance with the agreements between parties if there are some). - Page 3 ⚫ Secondary damage to the product caused by force majeure (natural disasters, earthquakes, lightning strikes) factors. The relevant service costs are calculated according to the manufacturer's standards, and if there is a contract, the contract will be handled on a priority basis. Please refer to the Product Warranty Card for detailed warranty description.
-
Page 4: Safety Precaution
Safety Precaution ◼ Safety Statement ⚫ Read and follow these safety precautions before installing, operating, and maintaining the product. ⚫ Follow all safety precautions stated on the product's labeling and in the manual when installing, operating, and maintaining the product for personal and equipment safety. ⚫... -
Page 5: Installation
machine in the external circuits of the programmable controller; ➢ Design external protection circuits and safety mechanisms for output signals related to major accidents for safe operation of the equipment; ➢ The programmable controller CPU may stop all output when it detects an abnormality in its own system;... -
Page 6: Maintenance
➢ Wiring of this product should only be carried out by specialized maintenance personnel with adequate electrical knowledge and training related to electrical equipment; ➢ During wiring, the external supply power to the system must be fully disconnected in advance. Failure to do so may result in electric shock or equipment failure or malfunction;... - Page 7 ➢ Dispose of this product as industrial waste, and the batteries should be handled separately in accordance with local laws and regulations; ➢ Dispose of equipment and products in accordance with industrial waste disposal standards to avoid environmental pollution.
-
Page 8: Product Information
1 Product Information 1.1 Naming Rules and Nameplate Description VM – 00 08 E TN Product information VM: Veichi Flexible Series IO Module IO input channel 00: 0 channel IO output channel 08：8 channels ... -
Page 9: Component Description
Model Description Machine code Application VM-0008ETN series 8-channel VM-series PLC, VM-series digital drain output coupler 1.2 Component Description Interface Function definition Signal Power and Run Module is working properly. indicator (POWER+RUN) indicator (green) Module is abnormal. Flashing Module is in ready or stop state. (green) Error indicator On (red) -
Page 10: Power Specification
analog output Orange: temperature measurement input User See the terminal definition section for details. terminal Specification 1.3.1 Power Specification Item Specification Rated voltage of terminal input voltage 24V DC (20.4V DC~ 28.8V DC) Rated current of terminal input power 2A (typical at 24V) Rated voltage of bus input power 5V DC (4.75V DC~5.25V DC) Rated current of bus input power... - Page 11 controlled by software) Output derating 50% derating at 55° C (output current not exceeding 1A while ON), or 10° C derating when output terminals are all Protection Short circuit protection, overcurrent protection 1.3.3 Software Specification Item Specification Output status mode under fault stop Cleared, keep current values and output according to preset value Preset output under fault stop...
-
Page 12: Mechanical Installation
2 Mechanical Installation Mounting Dimensions 2.1.1 Module Mounting dimension information is shown below in (mm). 2.1.2 Connection Cables... -
Page 13: Rail Installation
2.2 Installation 2.2.1 Inter-module Installation Inter-module assemblies are slide-mounted via the top and bottom rails. 2.2.2 Rail Installation DIN rail mounting is adopted here. When installing, align the module with the DIN rail and press the snap until there is a clear click sound. As shown in the figure below. Note: Push the rail snaps first to open state, place the module onto the DIN rail, press down the top of the snaps with your hand until it is in place. - Page 14 then rotate the DIN rail clamp so that the top end of the DIN rail clamp is hooked to the top end of the DIN rail, and then finally tighten the screws to lock the DIN rail clamp. 2.2.3 Disassembly Push the rail snap with your finger and pull the module out in the direction away from the DIN rail.
-
Page 15: Electrical Installation
3 Electrical Installation 3.1 Cable Selection The wire lug diameters in the following table are for reference only, and can be adjusted according to reasonable calculations based on practical use. Material name Wire diameter PRC standard /mm2 American standard (US) /AWG Tube lug 0.75 If other tube lugs are used, crimp them to the stranded wire, shape and size are required as shown below. -
Page 16: Terminal Definition
3.2 Terminal Definition Left indicator Left signal Left terminal Right Right signal Right terminal indicator... -
Page 17: Terminal Wiring
3.3 Terminal Wiring 3.3.1 Output Terminal Wiring... - Page 18 4 Module Programming Example Veichi Auto Studio with VC5 4.1.1 Create A New Project 4.1.2 Configure EtherCAT Task...
- Page 19 4.1.3 Import the xml File Import the current latest version of VM-RTU-ECT_1.0.0.xml description file and double click to add it to the device:...
-
Page 20: Slot Configuration
4.1.4 Slot Configuration Currently, VC5 requires slot configuration of the device first, and the configuration of the expansion modules and the order must be consistent with the physical object, otherwise an alarm will pop up to indicate that the configuration does not match what is connected. 4.1.5 IO Mapping VC5 default setting is no mapping, so it is necessary to map the registers that will be controlled and monitored to the soft components before actual use, otherwise users can not operate on them. - Page 21 4.1.6 Set Parameters 1.stopmode: failure stop output mode (index number in EtherCAT application: 0x8001+0x40*slot number), each channel corresponds to 1 bit respectively, 0 is hold, 1 is preset value corresponding to output stopvalue. 2.Stopvalue: failure stop output preset value (index number in EtherCAT application: 0x8002+0x40*slot number), each channel corresponds to a 1-bit value respectively.
- Page 22 Simple Commissioning with Beckhoff TwinCAT 4.2.1 Import the xml File Copy the current latest version of the description file VM-RTU-ECT_1.0.0.xml to the TwinCAT installation directory under TwinCAT\3.1\Config\Io\EtherCAT. 4.2.2 Create A New TwinCAT Project Open the TwinCAT software to create a new TwinCAT project, connect the VM-RTU-ECT to the VM-0008ETN and power up and connect it to the Ethernet interface of the PC.
- Page 23 4.2.3 Scan the Devices Ensure that the VM-RTU-ECT and VM-0008ETN are connected for device scanning, and follow the pop-up confirmation to make it run to OP. Note: A new installation of TwinCAT software requires the installation of the real-time NIC driver before this step.
