Voyager VCMYL35 Installation Manual

VCMYL35 - Color(NTSC) Cylindrical Observation
Features
:
- High Resolution Color 1/3" Camera
- Infra-red LED Assisted Low Light Enhancement
- Lightweight/Rugged Aluminum Body.
- Waterproof Design
- Wide Angle Lens
- NTSC Signal
Contents :
Camera
Locking Nut
Metal Spacer
Rubber Mounting Gasket
Installation and Pin Out:
Specifications
Signal System : NTSC
Image Sensor : 1/3" Color C-MOS(Omnivision OV07940 CLCC)
w/electronic Auto-iris
250K pixels
Light Sensitivity : 0.01 Lux
Power : 12VDC / 100mA
Viewing Angle : 105°(H), 80°(V), 130°(D)
Outer Dimensions : φ 34(W) X 51(D) mm
φ 1.34(W) X 2.01(D) Inch
* Specifications are subject to change without notice.
