VCMS36I - Color Cylindrical Observation Camera
Features
:
- High Resolution Color Camera
- IR LED Low Light Enhancement
- Lightweight/Rugged Aluminum Body.
- Waterproof (IPX7)
- Audio Microphone
- NTSC Signal
Contents:
Camera
Mount Bracket
Black Screws (2x)
Installation and Pin Out:
Specifications
Signal System
: NTSC
Image Sensor
: 1/4" Color C-MOS with automatic electronic iris
Resolution
: 400 Lines
Light Sensitivity
: 0 Lux
Power
: 12VDC / 100mA
Viewing Angle
: 118°(D), 95°(H), 77°(V)
Outer Dimensions : 26.5(W) X 32(D) mm
1.04(W) X 1.26(D) Inch
* Specifications are subject to change without notice.
